Pre-install Air Source System question.

Thermostats, Volumisers, Buffer Tanks, TRVs, Pumps, Piping, Valves, Radiators & Controls

Last Post by Mars 2 years ago

4 Posts

3 Users

1 Reactions

1,914 Views

RSS

EssGeeSee

(@essgeesee)

New Member Member

Joined: 2 years ago

Posts: 2

Topic starter 10/04/2024 12:17 pm [#1482]

Hi.

We have just been approved to have our oil fired CH changed to Air Source.
I am confused as to how the radiator part will work.
it won’t have Smart TRV’s. The guy who inspected our house said “you just turn up and down the rad valves and they get hotter”. But, how does the system know? Is the pump on constantly and a temperature sensor works out in & out temps?

I have used tado for years and would ultimately get our new system ‘smart’. Maybe that’s another subject?

Thanks.

EssGeeSee

Quote

bontwoody

(@bontwoody)

Noble Member Contributor

Joined: 4 years ago

Posts: 1056

10/04/2024 3:39 pm

Hi @essgeesee

Welcome to the forum. Heat pumps work best without zoning or TRV's turning radiators on and off regularly. The way a lot of us use ours is to set up a weather compensation curve and then just set the standard radiator valves so that each room is the correct temperature.

If you havent come across weather compensation before it just means that as the outside temperature becomes colder, the water flow temperature in the radiators becomes hotter. Once set up this produces a constant temperature in the room whatever the outside is doing and there is no need to turn a radiator on and off like a traditional boiler would do.

Hope that helps

House-3 bed partial stone bungalow, 5kW Samsung Gen 6 ASHP (Self install)
6.9 kWp of PV
10kWh DC coupled battery
Blog: https://thegreeningofrosecottage.weebly.com/
Heatpump Stats: http://heatpumpmonitor.org/system/view?id=60

👍

ReplyQuote

EssGeeSee

(@essgeesee)

New Member Member

Joined: 2 years ago

Posts: 2

Topic starter 10/04/2024 4:59 pm

@bontwoody - Resources for ‘weather compensation’, please?

ReplyQuote

Mars

(@editor)

Illustrious Member Admin

Joined: 6 years ago

Posts: 4809

10/04/2024 8:59 pm

@essgeesee here you go: https://renewableheatinghub.co.uk/what-is-weather-compensation-and-is-it-important
