Avoid the Heat Pump Villain: Why Low-Loss Headers and Buffers Can Sabotage Your Heat Pump’s Efficiency

Heat Pump Villian

Heat pumps are becoming increasingly popular as they provide an efficient and eco-friendly way to heat homes, helping us save money and protect the environment. However, to work best, they need the right setup. Sometimes, parts like low-loss headers and buffers, which are supposed to help, can actually reduce the heat pump’s effectiveness. This can lead to less warmth and higher running costs. It’s important to understand why these parts might not always be beneficial and what you can do to get the most out of your heat pump.

The Two Pillars of Heat Pump Prowess

Understanding how heat pumps operate holds the key to optimising their performance. Two fundamental principles guide their efficiency:

1. Low-Temperature Symphony: Think of heat pumps as musicians, capable of raising the temperature of heat, much like conductors orchestrate notes. But here’s the twist: the lower the target temperature, the less energy they need to play their magic. So, aiming for a cosy 20C instead of a sweltering 25C translates to a lighter burden on the system and a lighter burden on your wallet.

2. Flowing River of Warmth: Heat pumps move heat through water flowing through your radiators and/or underfloor heating. Imagine this water as a river, where a smooth, steady current efficiently delivers the thermal energy. Now, picture what happens if you dam the river with restrictions like narrow pipes or sluggish pumps. The flow suffers, and the heat struggles to reach its destination, leaving you feeling chilly despite the pump working overtime.

The Deceitful Decoys

Low-loss headers and buffers are often recommended by many installers and manufacturers as beneficial additions to heat pump systems. They are touted to enhance efficiency and comfort. However, in practice, the benefits they promise may not always materialise as expected. Let’s see why:

Low-Loss Header Trap: These headers aim to minimise heat loss in the pipework, but they often achieve this by reducing the water flow. Remember our river analogy? A constricted header acts like a dam, hindering the smooth flow and consequently, the efficient transfer of heat. This leads to the dreaded high delta T situation – a large difference between the temperature of the water entering and leaving your radiators. It’s like the conductor demanding the orchestra play at full volume while restricting the air to their instruments. The result? Strained performance and disappointing results.

The Buffer’s Misdirection: Buffers are essentially storage tanks for hot water, supposedly providing you with readily available warmth and reducing the heat pump’s workload. But here’s the catch: buffers add complexity and introduce additional heat loss points. They essentially become thermal cul-de-sacs, where some of the precious heat gets trapped and wasted. Additionally, buffers can encourage inefficient on-off cycling of the heat pump, further negating any potential gains.

Beyond the Decoys: A Path to Optimal Performance

So, how do you ensure your heat pump system lives up to its full potential? The key lies in simplicity and a focus on the two core principles we discussed earlier:

1. Embrace the Flow: Ditch the low-loss headers and any other flow-restricting components. Let the water flow freely, like a well-maintained river, ensuring efficient heat transfer throughout your home.

2. Befriend the Low-Temperature Symphony: Ensure your temperature control is managed directly by the heat pump’s controller, as on-off thermostats can be less efficient than a buffer. It’s crucial for the thermostat to be integrated with the system for optimal efficiency, rather than relying on standalone on-off mechanisms.

3. Weather Compensation – Your Wise Companion: Utilise weather compensation, a feature that automatically adjusts the heat pump’s output based on the outdoor temperature. This ensures constant comfort while minimising energy consumption. Think of it as a dynamic conductor, adapting the orchestra’s performance to the changing weather conditions.

4. Delta T – The Fine-Tuning Maestro: Implement delta T control, which fine-tunes the temperature difference between the flow and return water. This further optimises the heat pump’s operation, squeezing out every drop of efficiency. Consider it the musical equivalent of perfect intonation, ensuring a harmonious performance from your heating system.

5. Radiator Harmony: Use thermostatic radiator valves (TRVs) only in bedrooms, allowing weather compensation and the heat pump itself to manage the temperature in common areas. This strikes the perfect balance between individual comfort and overall system efficiency.

6. Hot Water Wisdom: Optimise your hot water production too. Let the heat pump controller handle this task. Think of it as a bonus track in the symphony of energy savings.

Avoiding the Heat Pump Villain

Sometimes, navigating the world of heat pump installation can feel like a quest through a confusing landscape. If you’re still daunted, consider buying my book Bodge Buster.

Manufacturers and even some training bodies might recommend setups that prioritise their own interests over your comfort and efficiency. Remember, you’re the homeowner, the conductor of your heating symphony – a poorly installed system not only strains your wallet but also leaves you in the discomfort of a cold home, bearing the full impact of such shortcomings. Don’t hesitate to question proposed designs, seek information from independent sources, and prioritise simplicity and the two core principles of low-temperature operation and optimal flow.

By taking charge and avoiding the deceptive decoys, you can ensure your heat pump delivers the comfort and sustainability you deserve, turning your home into a haven of warmth and energy efficiency. So, banish the monsters and villains, embrace the flow and let your heat pump play its beautiful low-temperature symphony.

Related posts

Are We Sleepwalking Into Another Race to the Bottom?

Mars

The Ultimate Guide to Heat Pumps: A Comprehensive Resource for Homeowners

Mars

Made in the UK: challenges facing heat pump installers

Alec Morrow

265 comments

JamesPa 23 January 2024 at 09:13


Remember, you’re the homeowner,

Well said!
I (and I suspect many others) have met a fair few installers who don’t seem to accept this!

Toodles 23 January 2024 at 11:00

Thank you Mars, I accept that a LLH may affect the efficiency of the overall efficiency – but how can the average individual who has a system installed with a LLH know whether they would be better off without it? Ripping apart a system that has one such and a secondary pump is a little radical – and is ther any guarantee that the efficiency would improve without these components. Presumably, LLH was a concept with a purpose – is it just to protect the designer and installers? Regards, Toodles.

HughF 23 January 2024 at 11:02

@toodles It is purely there to allow the heat pump to operate without any flow errors… Primary side just sits there running into the header, microbore or TRVs closing don’t have any effect on it.

Toodles 23 January 2024 at 11:18

@hughf If a system doesn’t have any variable restrictions like TRV’s, would such a system be better able to perform to the optimum without an LLH then? My system has carefully adjusted lockshield valves (constant restrictions in other words) but does have one TRV in a bedroom. There is an LLH and secondary pump – I was told this means achieving a Delta T of 5 degrees across the radiators is not crucial as the LLH is acting as an intermediary. Regards, Toodles.

Marzipan71 23 January 2024 at 11:34

Hi @toodles don’t know if you’ve seen them before but there a couple of articles which may be of interest from Protons for Breakfast regarding his system performance before and after removal of the LLH (I have a LLH on my Daikin ASHP) – links here and here

Toodles 23 January 2024 at 11:57

@marzipan71 Thanks very much Marzipan, very interesting indeed. I think that that data excuses my uncertainty of LLH – Good or Bad? Regards, Toodles.

Derek M 23 January 2024 at 19:27

Hi @toodles don’t know if you’ve seen them before but there a couple of articles which may be of interest from Protons for Breakfast regarding his system performance before and after removal of the LLH (I have a LLH on my Daikin ASHP) – links here and here

Having looked at the two articles, I think that the author seems to be arriving at conclusions on very limited data.

I also note with interest that he appears to have failed to appreciate the reason why the IAT increased to 22C after the LLH was removed, the transfer of thermal energy was much improved, so the LWT was now higher than required. Had he lowered the WC curve to lower the IAT, I think that he would achieved an increase in efficiency and higher COP.



JamesPa 23 January 2024 at 11:23


Thank you Mars, I accept that a LLH may affect the efficiency of the overall efficiency – but how can the average individual who has a system installed with a LLH know whether they would be better off without it? Ripping apart a system that has one such and a secondary pump is a little radical – and is ther any guarantee that the efficiency would improve without these components. Presumably, LLH was a concept with a purpose – is it just to protect the designer and installers? Regards, Toodles.

It’s a fair question
There are two approaches to answering it I can think of.
1.  Measure the flow-flow temperature drop across the llh.  For each degree you are losing 2-3% system efficiency.
2.  Plumb in  bypasses for the llh on the flow side and for the secondary pump with a couple of manual diverter valves so you can switch them in and out.  Perform the experiment

Presumably, LLH was a concept with a purpose – is it just to protect the designer and installers?

In most cases it seems, yes.

@toodles It is purely there to allow the heat pump to operate without any flow errors… Primary side just sits there running into the header, microbore or TRVs closing don’t have any effect on it

One might reasonably ask, why is the heat pump designed to register them as errors.  Answer – because the situation shouldn’t occur.
Putting sticking plaster over a red warning light doesn’t make the problem go away.  However it does reduce the liklihood of call outs.  Now who does that help?

HughF 2 September 2024 at 19:56




@toodles It is purely there to allow the heat pump to operate without any flow errors… Primary side just sits there running into the header, microbore or TRVs closing don’t have any effect on it

One might reasonably ask, why is the heat pump designed to register them as errors.  Answer – because the situation shouldn’t occur.

Putting sticking plaster over a red warning light doesn’t make the problem go away.  However it does reduce the liklihood of call outs.  Now who does that help?

On commissioning, I was having a nightmare getting rid of flow errors, I suspected a faulty flow switch so just jumpered it out in the terminal strip. It has been running like that since september.
Turned out to be air in the system. Haven’t had a flow error since 😀


Mars 23 January 2024 at 14:06

Thank you Mars, I accept that a LLH may affect the efficiency of the overall efficiency – but how can the average individual who has a system installed with a LLH know whether they would be better off without it? Ripping apart a system that has one such and a secondary pump is a little radical – and is ther any guarantee that the efficiency would improve without these components. Presumably, LLH was a concept with a purpose – is it just to protect the designer and installers? Regards, Toodles.

Your perspective on the matter is both practical and grounded. The decision to alter a heating system with a LLH and secondary pump hinges on a balance between current system performance and the potential for improved efficiency.

At a personal level, if your system is achieving a SCOP of 3 or more, maintaining a warm house without noticeable inefficiencies or discomfort, then the system can be considered effective. In such a case, the idea of overhauling the system might indeed seem unnecessary.

My own experience echoes a similar sentiment but also highlights the complexities involved. Our system, equipped with four distribution pumps, was designed to efficiently distribute heat throughout. However, in reality, it achieves a SCOP of 2.71, which indicates that it’s not operating at optimal efficiency. This lower SCOP points towards potential inefficiencies, possibly exacerbated by the current configuration with the buffer and multiple pumps.

It’s essential to recognise that LLHs are designed with specific purposes in mind – in theory, they help maintain consistent flow rates, prevent short-cycling of the heat pump and can contribute to system longevity. However, their impact on efficiency isn’t universally beneficial and can vary based on the system’s design and the property’s heating requirements.



Judith 24 January 2024 at 12:07

@toodles
graham hendra wrote an article on why llhs used to be needed and aren’t needed any more
https://www.linkedin.com/pulse/update-ultimate-heat-pump-why-do-we-use-low-loss-header-graham-hendra/ Or at least that’s how I understood the article he’ obviously one of the experts! Been there, done that!

Toodles 24 January 2024 at 13:22

@judith Very interesting, it rather sounds as though the installers need to update their knowledge of modern products then they might take advantage of the latest designs and we could all benefit in the long run. Regards, (and thanks) Toodles.

JamesPa 24 January 2024 at 14:35


@toodles
graham hendra wrote an article on why llhs used to be needed and aren’t needed any more
https://www.linkedin.com/pulse/update-ultimate-heat-pump-why-do-we-use-low-loss-header-graham-hendra/ Or at least that’s how I understood the article he’ obviously one of the experts! Been there, done that!

It’s both very refreshing and somewhat depressing to read this. Assuming I understand it correctly there is an admission that LLHs were added principally to stop tech support calls, with the justification that installers got the set up that would, even then, have worked without a LLH wrong.  I don’t think we have reason to doubt the rationale, although some installers may consider it a bit of a slur.
Then there follows a clear statement that things have changed in the product world, and they are no longer necessary.
There is an element of coming clean (excellent) but also an element of we were doing a bad thing, we knew it, but it was someone else’s fault (not so good).
What is unequivocally good is that its out in the open.

prjohn 23 January 2024 at 11:45

Are all Low Loss Headers bad? Mine was fitted as per Samsung schematics. This I would imagine would remain part of the warranty agreement. The effect on my system seems to be negligible. I did discusses this at a resent service and the engineer comment was “if its not broken don’t fix it". As my efficiency appears to be high, 2288kw/h energy use over a year as opposed to 1700litres (17000kw/h) of oil it seems my system is working OK. Another point is if by removing the LLH increases efficiency could it have an effect on the size of HP fitted? One other point, can a LLH act as a debris trap for older heating system thereby protecting the HP?

Toodles 23 January 2024 at 12:02

@prjohn Ooooh! Mars! Did you consider you might be opening a massive can of worms with this topic?! ;-)))

Mars 23 January 2024 at 12:14

@prjohn Ooooh! Mars! Did you consider you might be opening a massive can of worms with this topic?! ;-)))

Always good to have discussions about topics like this.



JamesPa 23 January 2024 at 13:13



@prjohn Ooooh! Mars! Did you consider you might be opening a massive can of worms with this topic?! ;-)))

Always good to have discussions about topics like this.


And as i point out above, its easy to work out roughly how much its costing.  Measure the flow to flow temperature drop across the llh and reckon on 2-3% loss in system efficiency per degree (if you want to be more precise, refer to the cop vs ft curves in the databook for youe machine).  Add a few 10s of W for the second pump.
If you are happy with this leave the llh in place.  If you are not then remove or bypass it.


Mike H 23 January 2024 at 13:20

@editor Here is a  graph of temperatures taken from my 4 pipe buffer tank ( before it was removed). You can see that Delta T between Buffer in (LWT) and Buffer return (RWT) is similar to the Delta T between Buffer out (to the radiators) and Radiator return (back to the buffer from the radiators). I take that to suggest that the flow rates in the primary and secondary circuits are similar. Nevertheless, there is a 4-5 degC difference between LWT from the Samsung and the temperature of the water going to the radiators. That in itself reduces efficiency and increases costs by around 12%.
Protons for breakfast found that removal of his LLH didn’t make much difference, but I wonder if his LLH was tall and thin as opposed to my buffer tank which was short and stout. There is only a couple of inches between the pipes in my buffer tank, so mixing is inevitable.

Buffer tank temperatures

Buffer tank



Derek M 23 January 2024 at 19:37

@editor Here is a  graph of temperatures taken from my 4 pipe buffer tank ( before it was removed). You can see that Delta T between Buffer in (LWT) and Buffer return (RWT) is similar to the Delta T between Buffer out (to the radiators) and Radiator return (back to the buffer from the radiators). I take that to suggest that the flow rates in the primary and secondary circuits are similar. Nevertheless, there is a 4-5 degC difference between LWT from the Samsung and the temperature of the water going to the radiators. That in itself reduces efficiency and increases costs by around 12%.

Protons for breakfast found that removal of his LLH didn’t make much difference, but I wonder if his LLH was tall and thin as opposed to my buffer tank which was short and stout. There is only a couple of inches between the pipes in my buffer tank, so mixing is inevitable.

Buffer tank temperatures

Buffer tank



A simple remedy would be to re-pipe your buffer to make it into a volumiser in the return leg to the heat pump.



Mars 23 January 2024 at 13:41

Are all Low Loss Headers bad? Mine was fitted as per Samsung schematics. This I would imagine would remain part of the warranty agreement. The effect on my system seems to be negligible. I did discusses this at a resent service and the engineer comment was “if its not broken don’t fix it". As my efficiency appears to be high, 2288kw/h energy use over a year as opposed to 1700litres (17000kw/h) of oil it seems my system is working OK. Another point is if by removing the LLH increases efficiency could it have an effect on the size of HP fitted? One other point, can a LLH act as a debris trap for older heating system thereby protecting the HP?

I’ve probably spent far too much time mulling over this topic. We’ve always had performance issues with the heat pump when temperatures drop. And it’s got nothing to do with the heat pump. If it’s set to deliver 45C water to the heating circuit, it does so without a problem. But this doesn’t translate into a warm, cosy room because the radiators are not receiving the heat they ought to.

To address this issue, our installers have returned multiple times, fitting K3 radiators and installing more distribution pumps. Now we have four distribution pumps, yet the distribution of heat remains sporadic, which is nuts.

Then I came across @heacol who was harping on about buffer tanks and how awful they are. “Yada, yada, yada," I thought at the time. There’s no way that buffers and LLHs can affect heating performance and I gave @heacol a hard time. So I went away and started to do more reading, and it’s fascinating just much these additions do affect heat pump systems.

Buffer tanks did play a crucial role in the evolution of the heating industry. Their introduction was a response to the inherent drawbacks of traditional on-off fossil fuel boilers. These older boilers needed to run at elevated temperatures, often exceeding 80C, to avert heat exchanger corrosion. For the period’s technology, operating at such high temperatures was deemed efficient, and utilising a buffer tank for temperature blending was beneficial. These earlier systems were also designed for lower flow rates, a stark contrast to the higher flow demands from multiple connected circuits. The introduction of buffer tanks helped manage these different needs more efficiently; but this belongs to an era that has since evolved, reflecting a different technological landscape than what we see today with heat pumps.

Because it’s so entrenched in the industry, there’s a common but incorrect belief that buffer tanks significantly assist heat pumps in balancing the load. The actual impact of a buffer tank on load management is quite limited. A buffer tank with a capacity of 100 litres (which is what we have at home) can only store around 1.17kW of energy when heated to a temperature 10C above the needed level. In a system requiring 10kW, this merely equates to a buffer duration of approximately 7 minutes, which is hardly noteworthy. Additionally, the extra effort to raise the temperature by that additional 10C could lead to an increase of as much as 25% in energy costs. And we have multiple distribution pumps trying to pump this water around the system, all of which have running costs too, for not that much effort.

This leads us to a critical point regarding the testing practices of heat pump manufacturers in the UK. While the performance and efficiency numbers they publish are derived from standardised testing conditions for consistency and reliability in comparing various models, the specifics of whether these tests include LLHs and buffer tanks are often not detailed in the general product literature.

According to information I’ve received from sources well-informed about the industry, most of these test setups do not incorporate LLHs or buffer tanks. Despite this, manufacturers frequently recommend their inclusion in actual installations. This discrepancy suggests that the performance results achieved in real-world settings may not align precisely with the published data, as the test conditions under which these figures are obtained do not fully mirror the recommended installation setups.



cathodeRay 23 January 2024 at 13:54

@editor – interesting. If I may also borrow a quote and refer it to @derek-m:

This leads us to a critical point regarding the testing practices of heat pump manufacturers in the UK. While the performance and efficiency numbers they publish are derived from standardised testing conditions for consistency and reliability in comparing various models, the specifics of whether these tests include LLHs and buffer tanks are often not detailed in the general product literature.

According to information I’ve received from sources well-informed about the industry, most of these test setups do not incorporate LLHs or buffer tanks. Despite this, manufacturers frequently recommend their inclusion in actual installations. This discrepancy suggests that the performance results achieved in real-world settings may not align precisely with the published data, as the test conditions under which these figures are obtained do not fully mirror the recommended installation setups.

I think this may be one of the problems encountered when modelling heat pump behaviour based on manufacturer data. The manufacturers quote efficacy (what can be achieved in ideal circs eg in a lab/RCT), whereas in the real world we get effectiveness (what can be achieved in practice, in the real world, where ‘stuff happens’). In medicine, the two are often very different, and I think the same might apply to heat pumps: what the labs predict is not what you get. And that’s before incorporating the PHE throttling effect (which is after all just another what you get in practice effect).

Mars 23 January 2024 at 14:16

@cathoderay, in addition to what you’ve mentioned above, the discrepancy between the performance and efficiency data cited by heat pump manufacturers (and by extension, the MCS) and the actual achievable outcomes in real-world installations is thought-provoking. This situation seems akin to the notable issue observed in the automotive industry, specifically the car emissions scandal, where the performance reported under test conditions did not accurately reflect real-world operation.

The heart of the issue lies in the testing environments and methodologies used by heat pump manufacturers. These tests are often conducted under idealised or controlled conditions that may not fully represent the typical installation scenarios or everyday usage patterns. Consequently, the efficiency and performance figures obtained in these test environments can be significantly higher than what a user might realistically experience.

Given the importance of time and resource efficiency in today’s world, it would indeed be revealing and beneficial if manufacturers could provide more transparency about their testing environments. Understanding the specifics of these test setups, including the conditions and parameters used, could offer valuable insights into how these figures are derived and their applicability to real-world settings.

This level of disclosure would not only aid consumers in making more informed decisions but could also push the industry towards more realistic and practical performance benchmarks. Our heat pump’s performance does not remotely match the numbers the heat pump is capable of according to the manufacturer. It would encourage a move away from idealised figures and towards data that better reflects the varied and sometimes challenging conditions of actual installations.

A call for greater transparency and realism in the performance data provided by heat pump manufacturers is not just about ensuring consumer trust; it’s also about aligning industry practices with real-world applications and expectations. Just as the automotive industry had to confront and adapt to the revelations of the emissions scandal, the heat pump industry could benefit from a similar shift towards greater honesty and clarity in its performance reporting.

Toodles 23 January 2024 at 14:45

@editor Indeed, manufacturers of most devices have their own methods of measurement that do not always relate well to ‘real world’ situations; they provide a rough guide that should be taken with generous pinches of salt I think. OK, the last three days may not be typical of UK winter weather as it has been rather milder than of late. I attach a graph where I have just left in the (what I believe) salient pieces of data for the Daikin heat pump performance. The COP has just exceeded 4 whereas Daikin might have one believe that it might perform with a rather higher figure. There’s is an aspiration – mine was the achieved performance (with a LLH that they probably weren’t employing)! Regards, Toodles.

IMG 0543
JamesPa 23 January 2024 at 14:49


@cathoderay, in addition to what you’ve mentioned above, the discrepancy between the performance and efficiency data cited by heat pump manufacturers (and by extension, the MCS) and the actual achievable outcomes in real-world installations is thought-provoking. This situation seems akin to the notable issue observed in the automotive industry, specifically the car emissions scandal, where the performance reported under test conditions did not accurately reflect real-world operation.
The heart of the issue lies in the testing environments and methodologies used by heat pump manufacturers. These tests are often conducted under idealised or controlled conditions that may not fully represent the typical installation scenarios or everyday usage patterns. Consequently, the efficiency and performance figures obtained in these test environments can be significantly higher than what a user might realistically experience.
Given the importance of time and resource efficiency in today’s world, it would indeed be revealing and beneficial if manufacturers could provide more transparency about their testing environments. Understanding the specifics of these test setups, including the conditions and parameters used, could offer valuable insights into how these figures are derived and their applicability to real-world settings.
This level of disclosure would not only aid consumers in making more informed decisions but could also push the industry towards more realistic and practical performance benchmarks. Our heat pump’s performance does not remotely match the numbers the heat pump is capable of according to the manufacturer. It would encourage a move away from idealised figures and towards data that better reflects the varied and sometimes challenging conditions of actual installations.
A call for greater transparency and realism in the performance data provided by heat pump manufacturers is not just about ensuring consumer trust; it’s also about aligning industry practices with real-world applications and expectations. Just as the automotive industry had to confront and adapt to the revelations of the emissions scandal, the heat pump industry could benefit from a similar shift towards greater honesty and clarity in its performance reporting.


In fairness to the manufacturers I think that most of the critical tests are done to BS/EU standards, and they generally quote the numbers.  The standards themselves will specify the test method/environment.  I cant see why they would include a buffer tank/llh unless its a mandatory part of the installation according to the manufacturer.
How many heat pump manufacturers actually insist on system separation in their installation manual.  From my recollection of when I read most of the manuals (about a year ago so my recollection is now imperfect).  Some show one in a diagram which also includes a backup boiler (so basically an all-options diagram), in this case its clear that some form of separation is required, but is it fair to infer that the same applies when there is no backup boiler.   I think its been more the installation industry that has pushed this approach because it eliminates a potential source of call out.


Derek M 23 January 2024 at 19:50

@editor – interesting. If I may also borrow a quote and refer it to @derek-m:

This leads us to a critical point regarding the testing practices of heat pump manufacturers in the UK. While the performance and efficiency numbers they publish are derived from standardised testing conditions for consistency and reliability in comparing various models, the specifics of whether these tests include LLHs and buffer tanks are often not detailed in the general product literature.

According to information I’ve received from sources well-informed about the industry, most of these test setups do not incorporate LLHs or buffer tanks. Despite this, manufacturers frequently recommend their inclusion in actual installations. This discrepancy suggests that the performance results achieved in real-world settings may not align precisely with the published data, as the test conditions under which these figures are obtained do not fully mirror the recommended installation setups.

I think this may be one of the problems encountered when modelling heat pump behaviour based on manufacturer data. The manufacturers quote efficacy (what can be achieved in ideal circs eg in a lab/RCT), whereas in the real world we get effectiveness (what can be achieved in practice, in the real world, where ‘stuff happens’). In medicine, the two are often very different, and I think the same might apply to heat pumps: what the labs predict is not what you get. And that’s before incorporating the PHE throttling effect (which is after all just another what you get in practice effect).

That is precisely why when modelling heating systems, not just the heat pump data should be part of the overall equation. It is also necessary to incorporate the effect from additional equipment and the limitations of the overall system design.



Derek M 25 January 2024 at 13:00

@editor – interesting. If I may also borrow a quote and refer it to @derek-m:

This leads us to a critical point regarding the testing practices of heat pump manufacturers in the UK. While the performance and efficiency numbers they publish are derived from standardised testing conditions for consistency and reliability in comparing various models, the specifics of whether these tests include LLHs and buffer tanks are often not detailed in the general product literature.

According to information I’ve received from sources well-informed about the industry, most of these test setups do not incorporate LLHs or buffer tanks. Despite this, manufacturers frequently recommend their inclusion in actual installations. This discrepancy suggests that the performance results achieved in real-world settings may not align precisely with the published data, as the test conditions under which these figures are obtained do not fully mirror the recommended installation setups.

I think this may be one of the problems encountered when modelling heat pump behaviour based on manufacturer data. The manufacturers quote efficacy (what can be achieved in ideal circs eg in a lab/RCT), whereas in the real world we get effectiveness (what can be achieved in practice, in the real world, where ‘stuff happens’). In medicine, the two are often very different, and I think the same might apply to heat pumps: what the labs predict is not what you get. And that’s before incorporating the PHE throttling effect (which is after all just another what you get in practice effect).

You are indeed correct, because in the real World installers include buffer tanks, LLH’s or PHE’s that are not normally required.

The other point to remember is that they are testing the heat pump, not a heating system.



cathodeRay 23 January 2024 at 13:15

There are low loss headers, damned buffers, and then there are plate heat exchangers. The usual Freedom wording for Freedom based Midea (and Samsung?) systems/installations appears to consider these one and the same, the point being hydraulic separation, not how it is achieved (though how a two pipe buffer achieves this is beyond me unless they have to be four pipe buffers). This is from the Freedom Midea installation manual:

“Every system must have hydraulic separation between the primary (heat pump) and secondary (heating circuit) pipe work.
This can be via a buffer tank, low loss header or plate heat exchanger. If you install the unit without hydraulic separation, you will void the warranty."

I’m pretty sure GH wrote that. It is useful, insofar as it hints at why they are essential (at least as far as keeping your warranty): the system “must have hydraulic separation between the primary (heat pump) and secondary (heating circuit) pipe work". That just leaves the question: why must it have hydraulic separation?

Moving on, and this is I think what @toodles is getting at (as well as pointing out that changing the system by ripping bits out is disruptive), there is also a valid question as to whether in some way the the devices might also have benefits to the end user. Less glycol in my PHE setup is one possibility, no ex radiator crud flowing through the heat pump is another. There may be others.

That said, I am clear in my mind that my current PHE setup almost certainly throttles my system significantly when heat demand is high, though I do note @marzipan71’s links to posts showing the removal of a LLH (not a PHE) appears to have made no difference.

I just want to be sure that removing my PHE won’t (a) make no difference (as in @marzipan71’s links, though in that case it was a LLH) and (b) cause unwanted effects.

Incidentally, no reply yet from Freedom to my email asking about the details of my PHE.

Mike H 23 January 2024 at 13:25


2-3% loss in system efficiency per degree

And it is like compound interest, not just additive.

cathodeRay 23 January 2024 at 15:07

How many heat pump manufacturers actually insist on system separation in their installation manual.

See my earlier quote (1:15pm) from the Freedom Midea Installation Manual (from 2022). The word used is ‘must’ (have hydraulic separation). I rather suspect if there is an equivalent Freedom Installation Manual for Samsung heat pumps, it may well say the same thing, or something very similar.

JamesPa 23 January 2024 at 15:15

Thats from Freedom, what does the OEM actually say
Here is the system diagram from page 4 of the Midea manual.  No buffer tank, LLH or PHE in sight.


iancalderbank 23 January 2024 at 15:23

I think the difference between testbed and realworld here vs others is that in say cars, you could never get the MPG advertised (although now there are more realistic test standards that give usable (ish) numbers).
But in this case the HP testbeds are all openloop (its not a secret) and you CAN get those numbers if you build a real world system that way.  if you build with a buffer or llh or phe you will get a few % off parity at best, if it is engineered well (or you get lucky). If not, then a lot of % off. clearly we have both ends of that spectrum here, some are happy (ish), some are unhappy.
I also studied lots of vendor schematics and documents, and publications and youtubes from people who know what they are talking about . none of them say “you must have a buffer/llh/phe". the only reason the situation that has come about with them still being put in by default, is, as far as I can tell, is as a legacy of the earlier installer “rules of thumb" where they were all paranoid about getting flow rate issues causing the HP to error, so they’d mitigate that with one of these devices, and somehow its stuck. Only certain installers (plus most/all of the DIY’ers) are confident enough to go against this.
Take a look at the heatpumpmonitor.org system list, set “hydraulic separation" to on in the display, and sort by COP. The distribution isn’t perfect, and there are plenty of other reasons why one system can perform better than another as we know,  but there is still a significant bias towards those with LLH/Buffer being lower down the list and those with None being higher. QED.
the other issues mentioned as reasons to keep these devices , aren’t. dirt – use a suitable low resistance filter. freezing – antifreeze valves.
the only reasons IMO to keep / put in those devices in a domestic setup are if

its already in, your system is performing reasonably well and the cost/hassle of removing it for a slightly better performance isn’t worth it
you have more complex system than usual which genuinely requires hydraulic separation . e.g. multiple heat sources. A real “buffer tank" (i.e. a big one , capable of storing a lot of heat) has a use case here as well, if one heat source is uncontrolled.

JamesPa 23 January 2024 at 15:34

Spot on IMHO and my studying, like yours, of manuals, posts and the various other info available.


cathodeRay 23 January 2024 at 15:37

Thats from Freedom, what does the OEM actually say

Here is the system diagram from page 4 of the Midea manual.  No buffer tank, LLH or PHE in sight.

This is a variation on efficacy vs effectiveness. That’s what Midea say in their ‘ideal’ manual. In the real world, stuff happens, Freedom offer training courses and provide installation manuals, and that is what the installers use. Why wouldn’t they? Freedom are a major supplier, surely they know what they are talking about?

You will have to ask Freedom why they varied the spec from the Midea manual.



Derek M 25 January 2024 at 13:51

Thats from Freedom, what does the OEM actually say

Here is the system diagram from page 4 of the Midea manual.  No buffer tank, LLH or PHE in sight.

This is a variation on efficacy vs effectiveness. That’s what Midea say in their ‘ideal’ manual. In the real world, stuff happens, Freedom offer training courses and provide installation manuals, and that is what the installers use. Why wouldn’t they? Freedom are a major supplier, surely they know what they are talking about?

You will have to ask Freedom why they varied the spec from the Midea manual.



I suspect the problem relates to the fact that as far as I am aware TRV’s still have to be installed on heating systems, which was the norm with gas and oil boilers.

Heat pumps work much better without TRV’s or on – off type controls, but many are still included, because that is how it was always done for the past umpteen years.

So to prevent their ‘trained’ installers getting loads of call-outs because of low flow when the TRV’s started shutting down, Freedom decided it was necessary to insist on hydraulic separation, rather than produce correctly designed systems and train the installers correctly.

Maybe if they start loosing business due to all the free publicity they are getting then they may start doing their job correctly.



cathodeRay 23 January 2024 at 15:40

Spot on IMHO and my studying, like yours, of manuals, posts and the various other info available.

But it is just unrealistic to expect most people in the real world to do this. And there is a related question, should they be expected to do it?

iancalderbank 23 January 2024 at 15:52


But it is just unrealistic to expect most people in the real world to do this. And there is a related question, should they be expected to do it?

no of course end users shouldn’t be doing this. Installers should. Installers should be MADE to put in systems that perform properly and held liable (not paid) if they don’t (perform properly).
In your case, freedom put their own rules around the system, in to protect themselves from “low flow" callbacks. plus someone underspecced the PHE. So you’ve ended up with a system design that would have worked within a few % if it was well engineered, but its NOT well engineered (the aforementioned PHE). Bizarrely you might have actually done better with an LLH! This is all unfortunate obviously for you and you have my sympathy, but doesn’t change my view on the bigger picture.


cathodeRay 23 January 2024 at 15:57

Take a look at the heatpumpmonitor.org system list, set “hydraulic separation" to on in the display, and sort by COP. The distribution isn’t perfect, and there are plenty of other reasons why one system can perform better than another as we know,  but there is still a significant bias towards those with LLH/Buffer being lower down the list and those with None being higher. QED.

Interesting, I’ve just done what you suggest, but I don’t think it gets near a QED threshold, and as we all know, and you say (‘plenty of other reason’),  association isn’t causation.

I can absolutely see how a PHE (which is what I have) throttles output, it can only transfer what it can transfer, and is the throughout is less than that needed, then the system is throttled. But I am not sure that it necessarily impairs efficiency.

iancalderbank 23 January 2024 at 16:23


 But I am not sure that it necessarily impairs efficiency.

It does. I do not claim to be the world authority on PHE’s but if you read the public explanations of how they work, full efficiency running a HP across a PHE is physically impossible in the context of what we’re talking about – you can’t get the output hot to exactly the same temperature as the input hot. you can move all the heat energy, but it’ll always be degraded a bit on the output side. which must have cost you some efficiency in the HP.
whereas a straight piece of pipe doesn’t have any system loss just a tiny bit of thermal (but we’re assuming both systems are well insulated so that negates).
It gets harder to engineer, the smaller the DT, the bigger PHE you need. The issue with yours is more that its undersized. if it had been sized right we’d probably not be having this debate, the few % inefficiency would be a non-issue because your house would be warm.



cathodeRay 23 January 2024 at 16:42

It does

I’m still sure about this, I think we might be mixing up throughput with efficiency. Consider the PHE as a form of obstruction: it restricts throughput. Even if the heat pump can produce 11kW, and the PHE can only throughput 8kW, then you have, in effect, my situation, with the heat pump reacting by only producing 8kW. A bit like trying to blow down a very small bore pipe. Your lungs can produce enough airflow to blow out candles six feet away, but the small bore pipe restricts the flow, and you only can only blow out one candle three feet away. But does that mean your lungs are now less efficient? Less capable, certainly, but less efficient? I can imagine something similar with a heat pump: its output is restricted, but it can still produce that lower output efficiently.

comes with the requirement to bend yourself double in a confined space, whilst being looked down upon by a sector of the British public.  Not the greatest incentive for a bright young graduate.

Nicely put.

iancalderbank 23 January 2024 at 16:54


I’m still sure about this, I think we might be mixing up throughput with efficiency. Consider the PHE as a form of obstruction: it restricts throughput. Even if the heat pump can produce 11kW, and the PHE can only throughput 8kW, then you have, in effect, my situation, with the heat pump reacting by only producing 8kW. A bit like trying to blow down a very small bore pipe. Your lungs can produce enough airflow to blow out candles six feet away, but the small bore pipe restricts the flow, and you only can only blow out one candle three feet away. But does that mean your lungs are now less efficient? Less capable, certainly, but less efficient? I can imagine something similar with a heat pump: its output is restricted, but it can still produce that lower output efficiently.

and I am still sure also. we just need to be clear we are talking about the right things:

 your system has a throughput problem, because of the undersized PHE.
 because it has a PHE in it, it has an efficiency loss due to the temp drop across the PHE. Thats physics, it can’t not be there. But that isn’t your main issue because that problem is almost entirely masked by the first one.

Any system with a PHE (or llh, or buffer) in it will have problem #2. To varying levels depending on the quality of the engineering. In some systems its awful. In some , its acceptable.
An open loop system would also have a throughput problem if the pipes were too small and it wouldn’t work properly. that’d be equivalent to problem 1 above. But it would never have the “efficiency loss due to enforced temperature drop" problem (2).


cathodeRay 23 January 2024 at 16:12

plus someone underspecced the PHE

I’m pretty sure this was Freedom. In effect, as I understand it, they supply an installation kit, and the installer installs what is in the kit. I’ve mentioned this before, I am pretty sure I asked my installer at installation time how the PHE was sized, and I think – it’s two years ago now – that his reply was Freedom supply a generic one, large enough to cover most installations.

I do wonder if part of the problem is that heat installation as done in this country seems to be largely done as a trade, and trades persons don’t as a rule get involved with serious (engineering) design, only basic stuff, which heat pumps definitely are not. This creates a vacuum into which suppliers can step: here’s our half day training course, we’ll have you up to speed in no time, we’ll even give you a kit of parts and an installation manual, and Bob’s your uncle. Add in a gutless toothless regulation system, and before you know it, we have what we have.

Again, it is back to the real world. Most car mechanics don’t have degrees in physics, and neither do most heat pump installers (so do, I know). It would take a huge effort to change that, and off the top of my head, right now I can’t see a way to do it.



JamesPa 23 January 2024 at 16:27




I do wonder if part of the problem is that heat installation as done in this country seems to be largely done as a trade, and trades persons don’t as a rule get involved with serious (engineering) design, only basic stuff, which heat pumps definitely are not. This creates a vacuum into which suppliers can step: here’s our half day training course, we’ll have you up to speed in no time, we’ll even give you a kit of parts and an installation manual, and Bob’s your uncle. Add in a gutless toothless regulation system, and before you know it, we have what we have.

Agree.  Doubly so with retrofits, where system design in the context of the specific house is the key to an implementation which is effective, cost effective, and efficient.  Of course there are good suppliers as well as good installers, but sadly not sufficient at present.

Again, it is back to the real world. Most car mechanics don’t have degrees in physics, and neither do most heat pump installers (so do, I know). It would take a huge effort to change that, and off the top of my head, right now I can’t see a way to do it.

I don’t think you need a degree in physics (although it probably helps), but you do need engineering skills to do the system design and problem solving.  Many plumbers are essentially fitters, very skilled at what they do but not able to do the engineering.  Unfortunately the system engineering and problem solving associated with plumbing, which I think is inherently interesting, comes with the requirement to bend yourself double in a confined space, whilst being looked down upon by a sector of the British public.  Not the greatest incentive for a bright young graduate.


Freedom are a major supplier, surely they know what they are talking about?

An interesting assumption, to say the least!  But lets suppose its true, you still have to question what they optimise for.

Posted by: @cathoderay
↑

 But I am not sure that it necessarily impairs efficiency.



It does. I do not claim to be the world authority on PHE’s but if you read the public explanations of how they work, full efficiency running a HP across a PHE is physically impossible in the context of what we’re talking about – you can’t get the output hot to exactly the same temperature as the input hot. you can move all the heat energy, but it’ll always be degraded a bit on the output side. which must have cost you some efficiency in the HP.
whereas a straight piece of pipe doesn’t have any system loss just a tiny bit of thermal (but we’re assuming both systems are well insulated so that negates).
It gets harder to engineer, the smaller the DT, the bigger PHE you need. The issue with yours is more that its undersized. if it had been sized right we’d probably not be having this debate, the few % inefficiency would be a non-issue because your house would be warm.


If there is a temperature drop flow-flow across the PHE/buffer/LLH it must impair system efficiency because it requires you to increase the flow temperature from the heat pump to achieve the necessary flow temp at the emitters.  System efficiency drops with increased flow temperature, its in the thermodynamics and the manufacturers data tables.

iancalderbank 23 January 2024 at 17:36


I don’t think you need a degree in physics (although it probably helps), but you do need engineering skills to do the system design and problem solving.  Many plumbers are essentially fitters, very skilled at what they do but not able to do the engineering.  Unfortunately the system engineering and problem solving associated with plumbing, which I think is inherently interesting, comes with the requirement to bend yourself double in a confined space, whilst being looked down upon by a sector of the British public.  Not the greatest incentive for a bright young graduate.

agree. I’ve always thought a mandatory qualification for a plumber is to be wiry, with very strong but thin arms. had one once who was my build (flanker) and he always sent his scrum-half build apprentice into the tight spots.  very skilled fitters as you say. But none of them was ever what I’d call a heating engineer, always at a loss when I wanted to discuss detailed system design . They would rely on vendor supplied information… which is where the likes of Freedom, Midsummer, Joule etc come in . The conjoining of it with the role of bathroom fitter doesn’t make for an interesting path for an technical graduate either.
digressing but I’ve pondered several times if there’s a way to combine my engineering/physics/system design skills with those of the young plumber down the road who is merrily servicing / fitting combi’s all day every day. can’t think of a way that actually works though.


JamesPa 23 March 2024 at 22:04

Yes, I get that, but how large is that loss percentage-wise? The throttling effect reduces say 11kW to 8kW – a 27% reduction. I suspect the blockage is the main problem, not the agreed but possibly not very large drop in efficiency. Again, I am distinguishing between throughput on the one hand and efficiency on the other.

As stated upthread about 2-3% per deg C, but if you want an accurate number check your systems data tables.

Throttling is a different phenomenon which may (will) cause a further loss in efficiency also because water is being recirculated through the heat pump without doing anything useful and you cant get owt for nowt.  However I dont have a figure for this effect.



cathodeRay 23 January 2024 at 16:49

An interesting assumption, to say the least!

It was a rhetorical question (? at the end), not an assumption!

If there is a temperature drop flow-flow across the PHE/buffer/LLH it must impair system efficiency because it requires you to increase the flow temperature from the heat pump to achieve the necessary flow temp at the emitters.

Yes, I get that, but how large is that loss percentage-wise? The throttling effect reduces say 11kW to 8kW – a 27% reduction. I suspect the blockage is the main problem, not the agreed but possibly not very large drop in efficiency. Again, I am distinguishing between throughput on the one hand and efficiency on the other.

JamesPa 23 January 2024 at 16:53

reposted because it got out of sequence somehow



Yes, I get that, but how large is that loss percentage-wise? The throttling effect reduces say 11kW to 8kW – a 27% reduction. I suspect the blockage is the main problem, not the agreed but possibly not very large drop in efficiency. Again, I am distinguishing between throughput on the one hand and efficiency on the other.

As stated upthread about 2-3% per deg C, but if you want an accurate number check your systems data tables.
Throttling is a different phenomenon which may (will) in addition cause a further loss in efficiency because water is being recirculated through the heat pump without doing anything useful and you cant get owt for nowt.  However I don’t have a figure for this effect and as you say its probably not the main downside of throttling.


cathodeRay 23 January 2024 at 17:43

But that isn’t your main issue because that problem is almost entirely masked by the first one.

Which is the point I was trying to make using lay language. The throttle effect (at 11 down to 8 kW) is around 27%, the efficiency losses are (much?) less. Taking @jamespa’s 2-3% per degrees C (between primary in and secondary out, I presume, which most of the time was between 1 and 2 degrees last time I took measurements) then the efficiency losses are say 2.5-5%.

An open loop system would also have a throughput problem if the pipes were too small

This is the same as my blowing through a small bore pipe analogy. It is not a loss as such, or an efficiency question, but rather simply a failure to deliver.

I do get it, but in my non-physics trained mind I see two problems (as you do) but conceptualise them slightly differently: the first, and more important problem is an obstruction to flow, the second is efficiency losses that arise from the heat pump having to work harder to get the same water temp at the rads.

Still no reply from Freedom Heat Pumps on details of my PHE.

iancalderbank 23 January 2024 at 18:09


Which is the point I was trying to make using lay language. The throttle effect (at 11 down to 8 kW) is around 27%, the efficiency losses are 2.5%….

ok, we’re in violent agreement 🙂

This is the same as my blowing through a small bore pipe analogy.

amusing complete off topic… I happen to be Bass Trombone player in my leisure time. you can get a lot of energy down a small pipe if done right 😉



JamesPa 23 January 2024 at 17:51


digressing but I’ve pondered several times if there’s a way to combine my engineering/physics/system design skills with those of the young plumber down the road who is merrily servicing / fitting combi’s all day every day. can’t think of a way that actually works though.

To some extent you are doing that by contributing to this forum.  I have also wondered the same (but am enjoying being retired too much to want to commit at the present time).  There are a couple pf people out there who are doing exactly that, albeit doing some plumbing as well, but trying to find ways to outsource this bit.
In general building we have Structural engineers, Architects and Builders.  They manage to work together.  The customer often contracts separately with them (for very good reason).
MCS mandates that your contract for the design and installation is with a single person (just saying!).

cathodeRay 23 January 2024 at 18:09

can’t think of a way that actually works though.



It may take two separate people.  In building we have Structural engineers, Architects and Builders.  They manage to work together.  The customer often contracts separately with them (for very good reason).  MCS mandates that your contract for the design and installation is with a single person (just saying!).

I think it’s called market forces, the efficiency of markets, or whatever those who work in the field that makes astrology look reputable call it these days. There’s nothing to stop firms that have an engineering department and a fitting department providing both sides of the equation – I’m not sure you really need the added complexity of multiple contracts – except that the engineering department is an unnecessary expense if Freedom et al are willing to step in provide a quasi-engineering department, in the form of their spreadsheet, along with their training, handy videos and installation kits.

I can’t think of another household or other purchase that requires potentially a lot of engineering input at the design stage, and then a considerable amount of fitting work to be done at the installation stage. Maybe the industry needs to think about new ways of working, though I have to add that in medicine any medical report that has new ways of working in the title usually means new ways of putting your feet up.

cathodeRay 23 March 2024 at 22:04

you can get a lot of energy down a small pipe if done right

I’m sure that is absolutely right!

Alec Morrow 23 January 2024 at 19:59

Really it’s system dependent, as we learn how few KWS we really need there are going to be proportionately bigger pipe layouts that the heat pump pump can’t cope with..1200 lph just won’t satisfy a system need 1800 lph

And it’s a brave person who poo poos system designs from manufacturers, and it’s cynical to think global manufacturers add things unnecessaryily. But I will grant you this, the very same manufacturers are doing a piss poor job educating installers and the public..

Derek M 23 January 2024 at 21:43

Hi Everyone,

It is strange how the same issues seem to pop up on the forum, it must be well over one year ago when CR and I were discussion the problem of having a PHE installed in his system, and my suggestion that he should consider having it removed.

Judith 24 January 2024 at 09:15

@derek-m and all
We are at the getting to grips with quotes etc stage. When our extension is finished (and only then, and if we can face more disruption) in the spring we’re going for a ashp install. Neighbours have recommended their installer but looking at their web site (and our neighbours) they also install large buffer tanks (possibly piped as 4 port can’t recall, need to go round again) plus a llh for their ufh.
So how do you prevent an installer putting in all of the extra stuff, other than going with someone else.
I realise from this forum and others that an open system is best, with obvious essentials like having large enough emitters. I have used Heatpunk to size up our house and my results compare well with our gas bill, so know what is involved.
Similar question how do you stop the installer using the huge mcs defaults on leakage loss when our blower door rate are below 1ach?

JamesPa 24 January 2024 at 10:11


@derek-m and all
We are at the getting to grips with quotes etc stage. When our extension is finished (and only then, and if we can face more disruption) in the spring we’re going for a ashp install. Neighbours have recommended their installer but looking at their web site (and our neighbours) they also install large buffer tanks (possibly piped as 4 port can’t recall, need to go round again) plus a llh for their ufh.
So how do you prevent an installer putting in all of the extra stuff, other than going with someone else.
I realise from this forum and others that an open system is best, with obvious essentials like having large enough emitters. I have used Heatpunk to size up our house and my results compare well with our gas bill, so know what is involved.
Similar question how do you stop the installer using the huge mcs defaults on leakage loss when our blower door rate are below 1ach?

You can try arguing with the installer.  In my experience this will work with some, but many will take no notice.  Basically its a sellers market so many don’t care about anyone who argues (in fact they probably actively want to discourage them).  You will quickly find out which category any given installer fits into.
You can ask the manufacturer the specific question via their technical support line, and you may well get an answer or even a set of approved system diagrams.  I found Vaillant, Mitsubishi, Grant, Cool Energy to be very helpful, Daikin pretty much said ‘ask your installer’ (even when I escalated) and Samsung haven’t responded to any technical query I have posed.  One individual reported an extensive (and successful) conversation with Vaillant about some non standard requirements/simplifications that the installer had vetoed.   Obviously if you can get answers from the OEM, the installer should listen.
You can read the installation/technical guides to see what they say and use that to challenge your installer.
Other than that its find another installer.


Similar question to all
i understand some ashp manufacturers insist on a llh/ 4 port buffer. Who are they so that they can be ignored, together with their installers?

From memory – Mitsubishi, Daikin, Vaillant, Cool Energy, Midea dont.  Samsung shows a buffer in an ‘example system diagram’ which includes just about everything under the sun (including a backup boiler – which is why the buffer is needed in that diagra,).  I’m not sure they actually insist on one, its possible that this is ambiguous, which leaves it open to interpretation.  Grant is a funny, I don’t think the manual for the underlying unit from Chofu does, but Grant then set out some installation guidance/requirements (basically install it as if it were a gas/oil boiler) – you will need to check how these are implemented in practice.  I don’t know about Panasonic, Hitachi, Viesmann or sundry others, my front runners quickly came down to Mitsubishi, Samsung, Daikin or Vaillant.
In your situation I would be tempted to specify when asking for quotes that a quote with an LLH, Buffer or PHE in the primary will not be considered.  That might put off those who otherwise will waste your time.  I did similar.

Derek M 25 January 2024 at 12:22

@derek-m and all

We are at the getting to grips with quotes etc stage. When our extension is finished (and only then, and if we can face more disruption) in the spring we’re going for a ashp install. Neighbours have recommended their installer but looking at their web site (and our neighbours) they also install large buffer tanks (possibly piped as 4 port can’t recall, need to go round again) plus a llh for their ufh.

So how do you prevent an installer putting in all of the extra stuff, other than going with someone else.

I realise from this forum and others that an open system is best, with obvious essentials like having large enough emitters. I have used Heatpunk to size up our house and my results compare well with our gas bill, so know what is involved.

Similar question how do you stop the installer using the huge mcs defaults on leakage loss when our blower door rate are below 1ach?

Hi Judith, welcome to the forum.

I suppose that you could politely ask them to explain in great detail why there is a need for a buffer tank or low loss header, or anything else that you feel may be superfluous to requirements.



Judith 24 January 2024 at 09:41

Similar question to all
i understand some ashp manufacturers insist on a llh/ 4 port buffer. Who are they so that they can be ignored, together with their installers?

Judith 24 January 2024 at 15:36

I don’t see any aspects of “doing a bad thing”, LLH are a good engineering solution to some identified problems, namely emitter sizes (and hence total system volume) too low and on-off thermostats.
i hear people regularly say, “, I’m not changing my radiators” or “I love my Hive/Tado and I’m not parting with it”. In which case hydraulic separation is essential. Until the customer learns the cost/benefits.
Or the pricing system changes so like the Netherlands gas is more than electricity per kWh (by taxation). Not efficient use of resources though.

JamesPa 24 January 2024 at 15:50


I don’t see any aspects of “doing a bad thing”, LLH are a good engineering solution to some identified problems, namely emitter sizes (and hence total system volume) too low and on-off thermostats.

Sorry on my reading it does.  I quote …
“So when you are in a low load condition you get this issue:… The flow slows down and the unit trips out on low flow alarm."
“In the really old days 2010-2013 we solved this with a bypass, if the flow dropped the bypass opened to allow a short circuit to maintain flow rate. It was OK but the installers refused to set it up correctly, quite rightly they thought the unit would cope. They were wrong."

“When I was a tech support engineers I got fed up with literally thousands of calls about low flow alarms so we made a solution. So in 2013 we decided to use a low loss header or plate heat exchanger to stop this problem, its a good solution but its expensive and it reduces system efficiency. But at least the unit runs without fault."
The first part says that there was a solution which didn’t compromise both performance and cost a lot, but installers wouldn’t use it.
The second part says that this forced them to adopt a different strategy even though they know it cost a lot and would compromise performance.  Also it falls into the category of covering over the red light with a sticking plaster!
The strange thing for me is that even my gas boiler system has a bypass in it, so I struggle to understand why installers ‘wouldn’t set one up correctly’ with a heat pump.
Don’t misunderstand me, I fully understand why it was done, and its great that its out in the open.  Its just disappointing that the reasoning has been less than transparent for so many years (so far as I can tell based on what I have read and what people say here and elsewhere), and that the practice still persists as ‘mandatory’ according to some.


i hear people regularly say, “, I’m not changing my radiators” or “I love my Hive/Tado and I’m not parting with it”. In which case hydraulic separation is essential. Until the customer learns the cost/benefits.

Thats fair enough, as long as the cost of retaining it is declared.  Customers should be able to make choices, and they should of course be informed ones.     For the same reason I should be allowed to retain my vented 140l cylinder if I wish to, but most installers will absolutely insist on ripping it out.

Marzipan71 25 January 2024 at 11:06

Hi all – following this thread with interest if a little over my head at times…I took a look at my Daikin Altherma manuals (2020 install) and the attached show the recommendations for a set up with a single type of emitter (ie rads) and the set up for multiple emitter types (eg rads and UFH). I have the latter. They talk about the necessity for a ‘balancing bottle’ in this multiple emitter scenario. Not able to find much about ‘balancing bottles’ but it looks a bit in schematic like my (assumed) LLH. I run both my emitter type zones (rads and UFH) at the same temp under a WCC so the multiple temp set points is irrelevant to me. Are these ‘balancing bottles’ equivalent to a LLH?

Capture 1

Capture 3

Capture 2

Capture 4
JamesPa 25 January 2024 at 13:25

@marzipan71
In the diagram they look and are piped like a buffer tank (an LLH is, in effect, just a small buffer tank afaik).  So far as I can tell from the schematics you posted the ‘balancing bottles’ appear only in the scenario where the are multiple types of emitter run at different flow temperatures

Marzipan71 25 January 2024 at 14:05

Thanks @jamespa – the flow in the manual is a bit confusing but in Capture 3 Daikin seem to also recommend/ mandate a ‘balancing bottle’ in the scenario where an old gas or oil boiler is replaced with this particular Daikin HT model irrespective of whether there are different flow temps (I think – the Daikin manuals are not the clearest) – ‘When replacing an old gas or fuel oil boiler by a air to water heat pump system (EKHBRD*): please always check the specifications of the pump of the old unit [and] if the external static pressure of that pump is higher than the external static pressure of the air to water heat pump system, please install an additional pump with higher external static pressure in combination with a balancing bottle.’ I had to look up external static pressure which tells you where my level of understanding is.


Capture 3



JamesPa 25 January 2024 at 14:40


Thanks @jamespa – the flow in the manual is a bit confusing but in Capture 3 Daikin seem to also recommend/ mandate a ‘balancing bottle’ in the scenario where an old gas or oil boiler is replaced with this particular Daikin HT model irrespective of whether there are different flow temps (I think – the Daikin manuals are not the clearest) – ‘When replacing an old gas or fuel oil boiler by a air to water heat pump system (EKHBRD*): please always check the specifications of the pump of the old unit [and] if the external static pressure of that pump is higher than the external static pressure of the air to water heat pump system, please install an additional pump with higher external static pressure in combination with a balancing bottle.’ I had to look up external static pressure which tells you where my level of understanding is.

— Attachment is not available —



Basically what this is saying is that, if the water pump contained within the heat pump isn’t strong enough for the job (because your heating system has too much resistance), then you will need a secondary pump.
I’m not actually a plumber, but I would have thought/hoped that there might be a way of putting another pump inline, without a buffer, to this job.


iancalderbank 25 January 2024 at 17:39


I’m not actually a plumber, but I would have thought/hoped that there might be a way of putting another pump inline, without a buffer, to this job.


there is, but if you read up on pump curve hydraulics as I’ve been doing the last few weeks, the maths is painfully non linear. you need rapidly increasing head to get the job done, and the pump cost goes up rapidly the more head you need.
I was looking at my own single loop system, I get 28l/min from 8.9m of head on a 9.5m head pump (UPMM). 10kw at DT5 heats my house perfectly well, but my heat pump can take up to 42l/min and I’d like to improve performance where I can. If I was to put in a second identical 9.5m head pump, whether in parallel or in series, I’d gain as little as 1% flow rate, a pointless change of course. To get it done properly I’d need about 12m head which is one serious pump (e.g. UPMXL). ÂŁ700 or so. so the answer in my case, time and money better spent on improving  the pipework for a lower head loss – which I have a couple of places to go at, come the summer.
whereas the my system setup as a buffered split would almost certainly run fine with two 6m pumps or maybe 8m at most. cheaper mass market screwfix circulating pumps, much “safer" in that there would be no need to worry about flow rate for the installer. but less efficient.
The “Balancing bottle" in the above seems just another name for a buffer/LLH (not heard that name before).
It’s actually the same question I was asking the other day on the “new generation of HT heatpumps" thread. A new fangled HT heatpump is (to me) only an option for “straight boiler swap", if it can run at DT20 without having to worry about flow rate issues. (thats ignoring , for the point of this discussion only, all HT efficiency issues). If it needs DT5 same as any other heat pump we know and love/hate, then all the flow rate issues come right back, and so people start talking about adding a buffer/LLH to mitigate , and back round in a circle we go.


Derek M 25 January 2024 at 18:28

I don’t see any aspects of “doing a bad thing”, LLH are a good engineering solution to some identified problems, namely emitter sizes (and hence total system volume) too low and on-off thermostats.

i hear people regularly say, “, I’m not changing my radiators” or “I love my Hive/Tado and I’m not parting with it”. In which case hydraulic separation is essential. Until the customer learns the cost/benefits.

Or the pricing system changes so like the Netherlands gas is more than electricity per kWh (by taxation). Not efficient use of resources though.

System volume problems are much better solved by installing a volumiser, which is similar to a buffer tank, but without the possibility of mixing and efficiency reduction.



Mars 25 January 2024 at 17:12

I think this may be one of the problems encountered when modelling heat pump behaviour based on manufacturer data. The manufacturers quote efficacy (what can be achieved in ideal circs eg in a lab/RCT), whereas in the real world we get effectiveness (what can be achieved in practice, in the real world, where ‘stuff happens’).

Based on several conversations I’ve had this week, there is an indication that significant information may be released in February which could call into question the accuracy of heat pump manufacturing and efficiency data. If this turns out to be the case, it could lead to serious legal ramifications for both private companies and government entities.

JamesPa 25 January 2024 at 17:30

Interesting. Is the research which led to this sponsored by the fossil fuel industry I wonder?
Obviously we all need the facts, but there is a big war going on here between the vested interests and the human race.  I get the impression that the vested interests are beginning to get a little concerned.

Mars 25 January 2024 at 17:40

@jamespa, it is not the fossil fuel industry. To my understanding it’s a heat pump insider whistleblower. Wonder if it’ll be enough (or significant enough) to have an ITV drama next time this year.

JamesPa 25 January 2024 at 19:19


@jamespa, it is not the fossil fuel industry. To my understanding it’s a heat pump insider whistleblower. Wonder if it’ll be enough (or significant enough) to have an ITV drama next time this year.

 Maybe not on a mainstream channel!  Perhaps 5 minutes on rip-off Britain.


JamesPa 25 January 2024 at 19:03


It’s actually the same question I was asking the other day on the “new generation of HT heatpumps" thread. A new fangled HT heatpump is (to me) only an option for “straight boiler swap", if it can run at DT20 without having to worry about flow rate issues. (thats ignoring , for the point of this discussion only, all HT efficiency issues). If it needs DT5 same as any other heat pump we know and love/hate, then all the flow rate issues come right back, and so people start talking about adding a buffer/LLH to mitigate , and back round in a circle we go.


I confess I see the HT heat pump question is a bit of a side issue.  The question really is, do ‘lt’ heat pumps have any advantages ove HT ones.  The answer, so far as I am aware is yes, they are cheaper (for now – but I suspect its unlikely to last) and (if the HT is r290) have fewer placement constraints.  But that’s about it.  Unfortunately they tend also to be noisier and uglier as well as the refrigerant having a higher gwp, not because of anything to do with the temperature they are capable of reaching, just because manufacturers combine several developments in one go and don’t always retrofit improvements to earlier models.   So far as I can assess they are no more efficient at any given OAT/LWT combination than HT ones.
So whilst I agree that aggressive marketing of ‘HT=straight boiler swap’ is misleading, it’s equally misleading to push LT pumps on the basis that running at HT is a bad idea.  You don’t have to drive a car at 120mph just because it can reach that speed and nobody would rubbish a Porsche because it can (but is not forced to) be driven at well above the legal speed limit!
As it happens I am more or less certain to end up with an HT pump, running at 45C, because there isn’t an ‘LT’ pump which fits the physical, aesthetic and noise requirements.  Is there any reason to suppose ‘LT’ pumps will exist at all in say 5 years?

Toodles 29 January 2024 at 16:53

At the risk of being drummed out for heretical thoughts ( ;-))) ) No, I’m sure I wouldn’t be, … would I?! Suppose this LLH is losing some efficiency – where is the loss taken place and where is the wasted energy going please? If the loss is in the form of heat that doesn’t make it across the interior of the LLH, does it radiate into the surrounding area? In my case, this will be the airing cupboard where such heat will be ‘always useful’, (harking back to the topic of uninsulated pipe runs within the home again!). If the unharnessed energy is being deflected back out into the return pipe-run to the heat pump outside, I can see that this might well be wasted heat though. Regards, Toodles.

JamesPa 29 January 2024 at 17:05


At the risk of being drummed out for heretical thoughts ( ;-))) ) No, I’m sure I wouldn’t be, … would I?! Suppose this LLH is losing some efficiency – where is the loss taken place and where is the wasted energy going please? If the loss is in the form of heat that doesn’t make it across the interior of the LLH, does it radiate into the surrounding area? In my case, this will be the airing cupboard where such heat will be ‘always useful’, (harking back to the topic of uninsulated pipe runs within the home again!). If the unharnessed energy is being deflected back out into the return pipe-run to the heat pump outside, I can see that this might well be wasted heat though. Regards, Toodles.

The principal reason that LLH reduces efficiency is if there is a temperature drop flow to flow across it (which there almost inevitably is unless it is particularly well set up).  This means that the heat pump operates less efficiently, because it must operate at a higher flow temperature to achieve the same temperature at the emitters.  Part of the reduction in efficiency will be that the compressor (which is usually outside) has to work harder, and part of the loss will be that not as much energy is extracted from the outside air.  So no, the ‘lost’ efficiency does not result in an increased radiation into the house (nor is it the case that a ‘loss’ of energy takes place in the LLH, albeit that it is the cause of the reduced efficiency – the reduction in efficiency occurs even if the LLH is lossless)
There will also of course be some actual loss of energy from the system at the LLH, due to convection.  Depending on the location of the LLH that might get radiated into the house.  This can be ignored if the LLH is within the heated envelope, and generally is ignored in these discussions.


Derek M 29 January 2024 at 17:10

At the risk of being drummed out for heretical thoughts ( ;-))) ) No, I’m sure I wouldn’t be, … would I?! Suppose this LLH is losing some efficiency – where is the loss taken place and where is the wasted energy going please? If the loss is in the form of heat that doesn’t make it across the interior of the LLH, does it radiate into the surrounding area? In my case, this will be the airing cupboard where such heat will be ‘always useful’, (harking back to the topic of uninsulated pipe runs within the home again!). If the unharnessed energy is being deflected back out into the return pipe-run to the heat pump outside, I can see that this might well be wasted heat though. Regards, Toodles.

If you have any more heretical thoughts then please let me know, so that I can send the Inquisitor round. 😋

The loss isn’t actual thermal energy as such, the loss is due to reduced efficiency (lower COP). Because of possible temperature reduction from primary circuit to secondary circuit, the LWT may have to be higher to ensure the heat emitters receive the required quantity of thermal energy.

To produce a higher LWT the compressor has to work harder, using more electrical energy, and in turn the heat pump absorbs less free energy from the OAT.

The overall thermal energy supply to the home should be approximately the same, just less free energy and more expensive energy.



Toodles 29 January 2024 at 18:46

@derek-m Just for ‘fun’, I placed strips of matt black insulting tape on the four pipes to and from the LLH and used my IR thermometer to obtain these approximate readings; I measured the four points a number of times to attempt to obtain steady readings and my best attempts tend to suggest the following temperatures.
Input to LLH from heat pump: 29.8 deg. C
Output to emitters: 29.0 deg. C
Return from emitters: 28.0 deg. C
Return to heat pump: 28.8 deg. C
Do these readings look as if they may be true? I’ll take another set of readings another day when time permits (don’t get older if you can help it, you spend more time than you might like draining the NHS facilities!) meanwhile without placing ‘proper’ sensors on the pipes, I’m not sure I can increase the accuracy. I wonder if there is also room to improve the Delta T by adjusting the secondary pump? Regards, Toodles.


Derek M 29 January 2024 at 19:24

I can’t remember ever having used an IR thermometer, but then I’ve always had access to what I would term correct test equipment. I do believe that one of the other forum members found difficulty getting accurate readings using an IR thermometer. What is the specified operating range and tolerance?

The actual readings obtained could be appropriate for a mild day like today, but again without other values to compare it is difficult to know for certain.

The DT does look low, but again without comparing with values measured during colder weather conditions, I cannot say for certain.

Without further data, I would suggest that you just monitor, without making changes, especially if you are warm and it is not costing you an arm and a leg to operate.

I keep advising people not to grow older, but they will insist upon doing so. 🙄



iancalderbank 30 January 2024 at 13:00

@toodles I’ve tried IR with black tape, doesn’t work very well . Other forum members have had good results for very little spend with a set of these from amazon. tape them tightly to the pipes, pipe insulation over the top to isolate from ambient.

Toodles 30 January 2024 at 20:39

@iancalderbank Oh Ian, I couldn’t see a link or any product details – please could you detail the goods again? My current attempts have been with a non-contact IR Thermometer with a spec. Of  0 ~ 550 C. +/- 1.5 %. Probably indicative but the tape covered pipe might be causing all sorts of errors I would imagine. Regards, Toodles.

Toodles 30 January 2024 at 20:46

@derek-m The system seems to be working well, we are warm and at approx. 450-500 W/h in this present warm weather, I feel all is goodness and light. (COP shows as 4.5 plus), when it was – 6 or -7, the COP was approx. 2.6 I think. As Ian has mentioned, an alternative means of measuring the actual LLH adjoining pipe temperatures would be better though. Regards, Toodles.

iancalderbank 31 January 2024 at 12:50

@toodles I put a link in the word “these" in the previous post. this type of thing. others on here have used them successfully.

Toodles 31 January 2024 at 15:01

@iancalderbank Thank you Ian, Regards, Toodles.

Toodles 1 February 2024 at 17:07

@iancalderbank Amazon delivered the four thermometers today; shame that there was not insulating material interposed between the contact and the button cells; flat cells in three of them and a faint glow only from the other! Did extended battle with Amazon help line / suppliers site and now await replacements. Ho-hum more grey hairs (well, actually, they are white already) and time I won’t get back!;-) Regards, Toodles.

AllyFish 3 February 2024 at 21:06

@toodles You were unlucky. I got the same 4 digital sensors over a year ago and all batteries are still going strong. Great devices across the low loss header to check primary and secondary flow and return temperatures. Make sure the sensor is touching the pipe and well insulated. Cable tie sensor to pipe, and then cable tie insulation completely over it. They would probably benefit from heat sink compound, but my memory of that stuff from my apprenticeship days is it ruins clothes instantly!

Toodles 4 February 2024 at 16:45

@allyfish I had a reply from the supplier, requesting a photo or video the the product!!! I sent a phot of the four displays; one was readable, one was feint and the other two were blank. I asked if they didn’t trust me? Anyhow, I orderedmsome LR44’s that should arrive today so that I can put the ‘kit’ together. Perhaps the supplier will send me another 4 units, I doubt they sell the cells anyway! Regards, Toodles.

Toodles 9 February 2024 at 12:19

I purchased some LR44 button Cells and powered up the 4 sensors; I laid the four probes close together and placed a Govee thermometer on either side of this bundle of sensors. The Govees both indicated the same temperature and I left the whole caboodle for 5 days occasionally comparing the readings on all four sensors to the Govees. I found that two of the sensors were consistently 0.1 degree C low and 0.1 degree C high and the others were 0.9 and 1.1 degrees C lower than the Govees. The four displays were then taped into a little ‘block’ and the probes taped onto the LLH pipes and covered with insulation. I left the probes to settle for an hour and then read (as per the photo) the results. Top left and bottom left are the heat pump flow and return; the top right and bottom right are the flow from LLH to emitters and return respectively. The left hand displays are both within 0.1 degree of Govee reference and the right hand pair are 0.9 and 1.1 degrees of reference. Outside temperature (according to Daikin Onecta app) was 13 degrees C and heat pump and secondary pump are noth working. Any comments welcomed but I’ll see what results show when OAT becomes more winter-like. (One other thing, supplier has not supplied replacement button cells so have reported them to Amazon)  Regards,, Toodles.

IMG 5811



Derek M 9 February 2024 at 12:35

@toodles

So applying the correction factors which you have established, the LWT is 37C and the RWT is 34.8C, giving a DT of 2.2C in the primary circuit. On the secondary side of the LLH the flow temperature is 36.7C and the return temperature is 34.5C, again indicating a DT of 2.2C.

The temperature drop across the LLH is only 0.3C, so I would assess that your system is operating in quite an efficient manner.



Toodles 9 February 2024 at 13:13

@derek-m 😊 Toodles.

Toodles 6 March 2024 at 17:00

@derek-m Hello Derek, I have left the system running with the thermometers in place for a few weeks now; glancing at the readings from time to time indicates that the varying OAT’s for a constant IAT show that the differential is fairly consistent. The displays are: Top Left = Flow to LLH. Top right = LLH flow out to rads, Bottom right = Return from Rads and Bottom Left = Return from LLH to ASHP. With the correction factors of the two right hand displays being 1 degree C. lower when all sensors were bunched together for several days, I am applying a +1 degree to these two thermometer readings; though I know these are not super-accurate devices, I think they probably provide a reasonable indication of the trends of changing temperature at the 4 points. I seem to have an average drop of 0.2 – 0.3 degrees across the input from the flow to the output of the LLH and 0.3 – 0.6 degrees C. across the return to the LLH and the return to the ASHP.
From time to time, I notice a dynamic ‘blip’ from time to time where one display or the other might indicate perhaps a 1 degree difference but this is short lived usually. I even noticed a difference of 4 degrees momentarily where the flow into the LLH exceeded the reading on the flow out to the rads; this lasted about 30 seconds or so and I have no idea why this should happen.
I don’t know the make of LLH as no label is visible but it is approx. 46 cm. Tall and 17 cm. wide.
Observations welcomed please!. Regards, Toodles.

IMG 5834



Toodles 6 March 2024 at 17:37

I suspect that the image was subjected to some filesize reduction so here is a close up of the displays. Toodles.

IMG 5834



Derek M 6 March 2024 at 19:42

I believe that the temperature readings indicate that your system is quite well balanced, in that the flowrate into the LLH is slightly greater than the flowrate out to the radiators.

This is probably the optimum achievable situation, since the slight mixing that is taking place within the LLH is at the return flow end. Slight mixing of the return flow should not have a detrimental effect on heat pump operation and overall efficiency.



Toodles 7 March 2024 at 09:27

Thank you Derek, at least it is only a little ‘Devil’ then! Regards, Toodles.

Mars 20 March 2024 at 08:49

Many of you may be aware of my growing skepticism towards certain elements of the heat pump, and one aspect I find particularly perplexing is the position held by both manufacturers and installers of heat pumps. This confusion was further compounded following my participation in an online discussion involving a group of installers and a representative from one of the leading heat pump manufacturers. The debate quickly escalated, especially around the topic of buffer tanks, reaching a point of intense contention. Interestingly, the manufacturer chose to remain notably silent as the installers, who were divided in their opinions, engaged in a heated exchange.

The crux of the debate revolved around whether buffer tanks could be installed efficiently and effectively by installers in general. The conversation revealed that integrating a buffer tank with a low temperature heat pump system, along with managing all related components, is a complex process. It became evident that a significant number of installers in the UK lack the necessary skills and training to execute such an installation successfully. Prompted by this realisation, I questioned why the industry doesn’t move away from using buffer tanks altogether to avoid the complications associated with their installation.

This query led to an unexpected direct message from a high-ranking official within the manufacturing company, asserting their unequivocal support for the use of buffer tanks and their desire for these components to be incorporated into installations, regardless of the efficiency of the installation process. Needless to say, this was a private exchange, and a position they didn’t want to express publicly.

This admission was startling and left me perplexed about the overarching objectives of the heat pump industry. It begs the question: why are we installing advanced heat pump systems only to undermine their performance with suboptimal installations? Surely, the ultimate aim should be to ensure that we are installing the most efficient systems possible, rather than settling for setups that significantly impede their functionality.

Toodles 20 March 2024 at 09:51

@editor Mars, as you might know, we have an LLH (which fortunately seems to be running with relatively low losses to the efficiency 😉). I am not about to rip out the LLH to extract a little more efficiency though! The majority of installers seem to opt for an LLH or a Buffer Tank by default as a ‘rear covering’ exercise don’t they? I had a long conversation with the director of the installers and he seemed to view the situation as a positive addition as it removed the necessity to achieve such a delicate setting of the Delta T performance from the secondary circuit that fed the emitters. I think our system is running well, but there is always the nagging feeling …’Might my Air Source Heat Pump run more efficiently if I had the LLH removed?’ Regards, Toodles.

JamesPa 20 March 2024 at 10:51

The cynic in me says this is about reducing call-outs & guaranteeing adequate volume for defrost.  From a customer POV, as well as having the potential to be poorly installed, a buffer increases cost and takes up space which many may not have.
It would be worth, IMHO, pressing them on the question of whether they mean ‘buffer tank’ or ‘volumiser’.  The latter at least has less potential for poor installation.


Abernyte 20 March 2024 at 13:11

Is there also a danger in the terminology that is being used ie low loss header, buffer and volumiser. Not all LLH’s act as buffers, correctly specified and installed they operate perfectly correctly as a hydraulic separator. It very much depends on where on the LLH the ports are positioned.
Are we in danger of vilifying an entire class of products?

Derek M 20 March 2024 at 13:22

Is there also a danger in the terminology that is being used ie low loss header, buffer and volumiser. Not all LLH’s act as buffers, correctly specified and installed they operate perfectly correctly as a hydraulic separator. It very much depends on where on the LLH the ports are positioned.

Are we in danger of vilifying an entire class of products?

As far as I am aware there would be no problem with a LLH or buffer tank, if the primary and secondary flowrates can be balanced to ensure that no mixing of the flow and return takes place. Obviously balancing the flowrates becomes problematic if the heat pump controller is able to vary the primary flowrate, without the necessary adjustment also being performed on the secondary, thereby unbalancing the system.

Having an additional water pump that may not be necessary is also a possible waste of electrical energy.



JamesPa 20 March 2024 at 13:38



Is there also a danger in the terminology that is being used ie low loss header, buffer and volumiser. Not all LLH’s act as buffers, correctly specified and installed they operate perfectly correctly as a hydraulic separator. It very much depends on where on the LLH the ports are positioned.
Are we in danger of vilifying an entire class of products?

As far as I am aware there would be no problem with a LLH or buffer tank, if the primary and secondary flowrates can be balanced to ensure that no mixing of the flow and return takes place. Obviously balancing the flowrates becomes problematic if the heat pump controller is able to vary the primary flowrate, without the necessary adjustment also being performed on the secondary, thereby unbalancing the system.
Having an additional water pump that may not be necessary is also a possible waste of electrical energy.


True, but it appears they are frequently not balanced.
My questions to @abernyte (or anyone else) is:
In a domestic installation of a ‘normal’ scale (say up to 6 bedrooms/300 sq m) with either radiators or UFH but not both

what value does a LLH add?
what value does a buffer add that a volumiser doesn’t add?

The application of Occams razor is generally a good principle so until we identify the value add then there is no argument for their presence.


JamesPa 20 March 2024 at 13:22


Is there also a danger in the terminology that is being used ie low loss header, buffer and volumiser

Agreed

Not all LLH’s act as buffers, correctly specified and installed they operate perfectly correctly as a hydraulic separator. It very much depends on where on the LLH the ports are positioned.

Surely an LLH suffers from mixing of flow and return to the same extent, probably more because its smaller, than a buffer does, and like a buffer needs to be set up properly to function without degrading efficiency (which seems to be where many installations go wrong).
Can you explain why ‘hydraulic separation’ is needed in a typical domestic central heating system.  I totally understand why extra volume may be needed, but not hydraulic separation.  if you are doing something complex with a back up boiler or a rather large system then maybe, but in a typical house what value does it add?


Abernyte 20 March 2024 at 13:43

The default setup on a Mitisubishi Ecodan solar thermal ported pre plumbed cylinder has a LLH.  My installer, who was one of the highly experienced “better" class of installer when queried regarding this said that the LLH in question has the flow injection plume above the return fitting outlet (not opposite as some seem to have) and as such would operate as a thermal separator to allow the primary and secondary pumps to operate efficiently at different variable speeds.
Since installation the system operates with a flow temp rarely above 35C and has been a resounding success as a heating system. Not a scientific recommendation I admit but I see no reason to doubt his explanation …so far!

JamesPa 20 March 2024 at 13:52


The default setup on a Mitisubishi Ecodan solar thermal ported pre plumbed cylinder has a LLH.  My installer, who was one of the highly experienced “better" class of installer when queried regarding this said that the LLH in question has the flow injection plume above the return fitting outlet (not opposite as some seem to have) and as such would operate as a thermal separator to allow the primary and secondary pumps to operate efficiently at different variable speeds.
Since installation the system operates with a flow temp rarely above 35C and has been a resounding success as a heating system. Not a scientific recommendation I admit but I see no reason to doubt his explanation …so far!

Which simply begs the question – why do I want primary and secondary pumps in the first place (which incidentally must be balanced for the LLH to work without impeding system efficiency).  For the avoidance of doubt I’m talking about a typical fairly simple domestic setup where a heat pump replaces a gas boiler (ie 95% plus of real world scenarios).  Why would I have a second pump, a low loss header/buffer etc.  None of this appears in your typical CH system.  What value do they add.
You may not know I accept, but until someone tells us then the best assumption is no value at all and, since they clearly add trouble and cost, thats a good argument to leave them out.


Toodles 20 March 2024 at 13:58

@abernyte I suspect that arrangement might be similar to the one in our airing cupboard. The flow is the top left pipe and the return is the lower left. The top right is the flow to the secondary pump thence to radiators and the lower right is return from the radiators? Regards, Toodles.

IMG 5834
Abernyte 20 March 2024 at 14:03

Yes other than Mitsubishi use a 35mm LLH

JamesPa 20 March 2024 at 14:11


Yes other than Mitsubishi use a 35mm LLH

But why (bother with a secondary pump and llh) in a typical domestic install?
Does anyone actually know a reason that stands up to scrutiny?  I am not trying to be difficult, I genuinely want to know?  @abernyte, @editor, @derek-m any ideas or is this another appendix from heat pump history that needs to be surgically removed?

Derek M 20 March 2024 at 14:25

Yes other than Mitsubishi use a 35mm LLH

But why (bother with a secondary pump and llh) in a typical domestic install?

Does anyone actually know a reason that stands up to scrutiny?  I am not trying to be difficult, I genuinely want to know?  @abernyte, @editor, @derek-m any ideas or is this another appendix from heat pump history that needs to be surgically removed?

The only reason of which I can think, is that it would be to allow system designers to accommodate ‘smart’ thermostats and TRV’s into their designs, without suffering ‘low flow’ problems.



JamesPa 20 March 2024 at 14:35




Yes other than Mitsubishi use a 35mm LLH

But why (bother with a secondary pump and llh) in a typical domestic install?
Does anyone actually know a reason that stands up to scrutiny?  I am not trying to be difficult, I genuinely want to know?  @abernyte, @editor, @derek-m any ideas or is this another appendix from heat pump history that needs to be surgically removed?

The only reason of which I can think, is that it would be to allow system designers to accommodate ‘smart’ thermostats and TRV’s into their designs, without suffering ‘low flow’ problems.


Wow that’s inventive but I’m sure you agree that it can be discarded as a legitimate reason.
Perhaps we ought to ask why should they be included rather than trying to argue that they should be omitted.  No system designer worth their salt includes components without a reason.


Derek M 20 March 2024 at 15:04

Yes other than Mitsubishi use a 35mm LLH

But why (bother with a secondary pump and llh) in a typical domestic install?

Does anyone actually know a reason that stands up to scrutiny?  I am not trying to be difficult, I genuinely want to know?  @abernyte, @editor, @derek-m any ideas or is this another appendix from heat pump history that needs to be surgically removed?

The only reason of which I can think, is that it would be to allow system designers to accommodate ‘smart’ thermostats and TRV’s into their designs, without suffering ‘low flow’ problems.



Wow that’s inventive but I’m sure you agree that it can be discarded as a legitimate reason.

Perhaps we ought to ask why should they be included rather than trying to argue that they should be omitted.  No system designer worth their salt includes components without a reason.



Which is why I have spent the past three years trying to convince forum members that they should have their poorly designed systems corrected to make them operate more efficiently.



Gary 20 March 2024 at 17:07


The only reason of which I can think, is that it would be to allow system designers to accommodate ‘smart’ thermostats and TRV’s into their designs, without suffering ‘low flow’ problems

I think you are both correct, its because systems aren’t designed, they are plumbed in by people who don’t understand system design but attend a manufacturer’s installation course.  So the additions of these components are their to mitigate any system design and it will function in any given scenario, not optimally but it will function.

JamesPa 20 March 2024 at 17:12



The only reason of which I can think, is that it would be to allow system designers to accommodate ‘smart’ thermostats and TRV’s into their designs, without suffering ‘low flow’ problems

I think you are both correct, its because systems aren’t designed, they are plumbed in by people who don’t understand system design but attend a manufacturer’s installation course.  So the additions of these components are their to mitigate any system design and it will function in any given scenario, not optimally but it will function.

I fear you are right.  However the reason suggested (which is very plausible) is the equivalent of dressing a dirty wound instead of first cleaning it up because the patient complains about the sting of the antiseptic, except that if you did the latter you would likely get struck off.


Judith 21 March 2024 at 22:37

Naive input here:
I understand that LLH are supposed to act as impedance transformers (when set up right), giving the option of a higher delta T across the radiators in the secondary circuit. Hence the pump requires a dT of 5C but that isn’t enough to give enough heat output from the radiators. So for the considerable proportion of potential users who don’t want very big radiators (or any changed) then the LLH allows a larger dT say 10-15C and the colder water is mixed back in the return path.
This requires a higher flow in the primary circuit than the secondary afaik and everything set up right.
I only know what I’ve read, I’ve not installed or designed an ASHP system.
Clearly for the customer preference of not changing radiators there is a potentially much higher installation and component cost and ongoing consumption cost.
Please don’t trash me if I’ve misunderstood what I’ve been reading.

Derek M 22 March 2024 at 00:34

The quantity of thermal energy that can be emitted from a radiator is primarily dependent upon the Average Water Temperature (AWT) within the radiator the Indoor Air Temperature (IAT), and the standard heating capacity for the size and type of radiator, which is normally specified at DT50.

So if the Leaving Water Temperature from a heat pump going into a radiator was say 45C and the Return Water Temperature from a radiator was 40C, then the AWT would be approximately 42.5C.

A single panel type 11 radiator of size 1200mm x 600mm has a specified DT50 of 1141W, while a double panel type 22 radiator of the same size has a specified DT50 of 2051W, almost double the thermal energy output.

If a LLH is installed between the heat pump and the radiator, the maximum temperature of the water entering the radiator can be no greater than the LWT from the heat pump, so the only way to increase the DT across the radiator would be to reduce the secondary flow rate so that the water spends more time passing through the radiator. The net effect would be to actually reduce the thermal energy output of the radiator, since the AWT would also be reduced. If the flow temperature going into the radiator is 45C, but the return temperature coming out of the radiator is 35C, giving a DT of 10C, the AWT will now be 40C, not 42.5C.

I have attached a radiator heat output calculator which can be used to estimate the thermal energy output of different size and type of radiators under different operating conditions. The yellow highlighted cells can be varied with the results appearing in the green highlighted cells.



JamesPa 22 March 2024 at 08:20

@judith
Derek has explained it technically, just to add for the avoidance of doubt – it simply is not true to suggest that adding a LLH can overcome a  requirement (if it exists) to upsize radiators when switching to a HP.  If someone told you this then they were either deliberately deceiving you or didn’t understand it themselves, or both.  However it’s easy to see why the misunderstanding could occur so you don’t need to feel bad about it!
The only circumstance I can think of where some form of ‘tweaking’ of deltaT at the emitters might overcome the need (if it exists) to upsize radiators is where the required upsizing is very marginal.  If you can run the secondary circuit very fast, the deltaT across the emitters reduces, in the limit to near zero.  This will increase the average temperature of the emitters by no more than 2.5C, which will increase their heat output by about 15% at a typical flow temperature of 45C.  I cant actually work out if, or whether, you could get this to work in practice, because it implies that the deltaT at the heat pump is also near zero (and thus the rate of flow must also be fast).  The heat pump may, or may not, be OK with this.  You are going to get a lot of noise from your CH system if you attempt this, and pipe erosion, so Im not suggesting that its a sensible idea, just that it doesn’t immediately violate the laws of thermodynamics.


Judith 22 March 2024 at 10:26

@derek-m and others
i think I’m getting there, so can I try this out…..?
There are too many dTs in this game. Derek rightly corrected me on average flow temp through the rads, so to get back up to the same average flow temp the input flow temp (LWT) has to be increased. Hence one of the sources of inefficiency in the ashp/llh combination
BUT on a boiler system with a higher LW temp say 60C the dT across the rad is a smaller proportion of the dT to the room (thus showing too many dT!😉) and anyway with a boiler the LWT -efficiency curve is not as severe.
Does this make sense?

Mars 22 March 2024 at 08:37

Please don’t trash me if I’ve misunderstood what I’ve been reading.

Users should never hesitate to ask questions on our forums – this isn’t Facebook 😉

JamesPa 22 March 2024 at 10:47

Pretty much but worth unpacking for absolute clarity


There are too many dTs in this game

Yes!

Derek rightly corrected me on average flow temp through the rads,

Exactly,  Heat loss from rad to room is dependent on average flow temp through the rads.  The DT across the rads will be driven by this and flow rate not the other way round.


so to get back up to the same average flow temp the input flow temp (LWT) has to be increased. Hence one of the sources of inefficiency in the ashp/llh combination


If there is a reduction in flow temperature (flow to flow) across the LLH then yes.  If the LLH is perfectly set up the reduction in flow temperature will be small, so possibly no material inefficiency.  But frequently it isnt perfectly set up and anyway, in the absence of a concrete reason (and in most domestic setups there isnt a concrete reason), why bother with the LLH because it costs money and is the source of problems.

BUT on a boiler system with a higher LW temp say 60C the dT across the rad is a smaller proportion of the dT to the room (thus showing too many dT!) and anyway with a boiler the LWT -efficiency curve is not as severe.

The key is that LWT (and thus the average emitter temperature) is higher, although in a modern system possibly not by that much, if at all.  The latest BRs require the design to be at FT=55.  If you persist with the typical  20C deltaT flow to return, the average rad temp will actually be 40C, a bit lower than the 45/5/40 combination used frequently for an ASHP, but in practice essentially the same.
However typical practice until recently (and I suspect still in the vast majority of cases) is to set (or rather leave) a boiler FT at ~75 which does lead to higher average rad temp.  Actually this very likely also causes quite a severe efficiency hit because its entirely possible/likely that the boiler wont condense because the return temp is too high – you can tell because a boiler that isnt condensing will have plumes of water vapour emitted from the flue – which you see all the time!  Thats worth, I believe, ~10%.  However almost nobody takes any notice of the efficiency of gas powered central heating systems.  One might, very cynically, argue that the market actively distracts them from doing so by providing lots of ‘controls’ with various degrees of smartness that purport to improve efficiency but may not do so by anything like as much as we are led to believe.
Just like an ASHP, one of the best tips for getting greatest efficiency (and comfort) from a gas boiler is to turn down the flow temperature to as low as you can consistent with the house being sufficiently warm!

iantelescope 23 March 2024 at 13:40

@editor

Heat Pumps …………Short Cycling

Older Heat Pumps
1) In all older Heat Pumps the Power was controlled  and regulated  by binary state , ON-OFF Cycling.

Modern Heat Pumps
2) In Modern Heat Pumps the Power is Continuously controlled by an inverter.
3) Modern Heat pumps revert to binary state Cycling when the power required drops below a Minimum Value.
4) Cycling will be more apparent  when the required power is at a minimum during Spring and Autumn.
5) Cycling can, however, appear at any time of the year on any Heat Pump.

Cycling time
6)  When an Inverter Power Controlled Heat Pump is operating below the minimum Inverter Power the Heat Pump is cycling.
7)  The time taken during cycling is made up from a positive ON Time Pulse or Run Time followed by a negative OFF Time .

Run Time
8) The positive ON TIME,( RUN TIME ) period is determined by the time taken to heat the Volume of Water within the pipe system to a set Temperature.

OFF Time
9) The Negative OFF TIME period is the time taken for the Pipe Water Temperature to fall to the required pipe Water Temperature.
10) The pipe Water Temperature is determined by a Thermostat.

Cycle Time
11) The Total Cycle Time = Run_TIME + OFF TIME.

Pipe Water Volume ?
12) The Cycle Period is determined by the Volume of Water within the Pipes.

MCS Calculation of the Volume of a Buffer Tank?
Please see the Explanation , given by the MCS into the Required Buffer Tank Volume .

Buffer sizing 11


Conclusions
A) Buffer TANKS MAY, SOMETIMES, be Necessary !

Buffer warning 1


B) Buffer Tanks come at a potential cost !

Buffer Warning 2


ian

















JamesPa 23 March 2024 at 14:20

As far as I am aware short cycling can be cured just as effectively by a volumiser as opposed to a buffer tank.  Volumisers dont depend on accurate control/setup, they are just passive.  @editor, @iantelescope, @derek-m .  Am I wrong?
I can see that buffer tanks may be required if you want to combine two heat sources simultaneously (if its either/or zone valves will suffice.


Derek M 23 March 2024 at 15:02

If my understanding is correct, volumisers and buffer tanks may be primarily required to help with the defrost cycle. Once this additional volume of water has been brought up to temperature I believe that it will have little effect in reducing cycling (short or otherwise).

Think about what is happening. The heat pump initially supplies thermal energy to heat up the additional volume of water contained within a volumiser or buffer tank, but this volume of water will not emit much thermal energy during the heat pump off period, so no longer present a heat demand when the heat pump restarts.

I believe the location of the LWT and RWT sensors is the more important factor, since they are the devices affecting when the heat pump starts and stops.

If the LWT and RWT sensors are located in the heat pump unit outside, then it is likely that they will cool down much quicker than if they are located within the thermal envelope of the home.

My own home heating system has a temperature sensor located on one of the radiators, which in conjunction with the controller, initiates the starting and stopping of our heating system. This varies the frequency of operation from approximately 4 times per hour during sub-zero weather conditions to once every 2 or 3 hours when the weather is milder.



JamesPa 28 April 2025 at 20:56

Doesn’t the effect on cycling depend on how the water pump is controlled.  If the pump (secondary in the case of a buffer tank, only in the case of a volumiser) continues to operate after the heat pump has switched off then the volumiser/buffer tank will cool and the energy will be given up to the house.  This will increase the period of the cycles but of course wont and cant change the mark-space ratio.  If on the other hand the water pump switches off when the heat pump switches off, then I agree with what you say.

My comment above still broadly stands, but in extended fashion given yours ie:

As far as I am aware short cycling/lack of stored energy for defrost  can be mitigated just as effectively by a volumiser as opposed to a buffer tank (with appropriate water pump control).  Volumisers dont depend on accurate control/setup, they are just passive.  @editor, @iantelescope, @derek-m .  Am I wrong?

iantelescope 24 March 2024 at 12:41

@editor

All Modern Heat Pumps will Cycle when operating BELOW the Minimum Inverter Power .

Here is a detailed graph of the Power my Heat Pump consumed during the evening of 23-March-24.



Cycle time 23 03 24

The Cycling Time, Run_Time ( Mark *) + OFF_Time ( Space *) = ~ 10.12 Minutes.
Here is a more detailed Graph of the Power consumed during the evening of 23-March-24, showing the Run Times.

Run Time 23 03 24

The instantaneous RUN Time is , here, ~5.0 Minutes.

Here is the FFT of the Power consumed during the evening of the 23-March-24 , showing the Cycling Frequency.


3 24 00

The Frequency Maximum , here provides an Average Cycling Time of 9.96 Minutes.
The First Harmonic of the Cycling Frequency provides a Check, giving a 5.03 Minutes.

The RUN TIME CALCULATION **
My Heat Pump has a 50 Litre Buffer Tank   fitted Across the output ports of my Heat Pump.

When Operating Below the Minimum Inverter Power of 2.5 Kw my Heat Pump is Cycling.

The Energy input into the Buffer Tank , when operating at the Inverter Minimum Power , kWh = Minimum_Power ( kW )  X Run_Time (Seconds)
The Energy Input Heats 56 Litres of Water to the Temperature Difference Across the Buffer, Delta_T .
The Energy Required to Heat 56 Litres of water to a Temperature of Delta_T is:
Energy Required to Heat 56 Litres of Water to ~4C = 4.18 X 50 X  4

Therefore, the 2.5 kW Minimum Power X Run_Time = 4.18 X 50 X 4

Therefore,  Run _Time ( Seconds ) = (4.18 X50 X 4 ) /2.5  Seconds.
OR
Run_Time = (4.18 X 50 X 4 ) /(2.5 X 60 ) Minutes.

My Calculated Run_Time is Therefore , 5.57 Minutes
My Instantaneous Measured Run Time is ~5.00 Minutes.
My Average Cycle Time ( from FFT ) is 9.96 Minutes.
My Average Run_Time ( from FFT ) is 5.03 Minutes.

Is my Heat Pump STILL Short Cycling ?


* Sorry to use the Electrical Mark to Space Ratio  Terminology
** Check the MCS Calculations in :

Buffer sizing 11






















iantelescope 24 March 2024 at 14:55

@editor
All Modern Heat Pumps use an Inverter to control Heat Pump Water Power.

All modern Heat Pumps have a Minimum Power BELOW which the HEAT PUMP WILL REVERT to  Cycling.

The DECC, in 2012, produced a Report on the Effects of Cycling on the Heat Pump COP:

The DECC Report was produced at a time when Heat Pumps with Inverter Power control  were in their infancy.
The Report is however still useful when operating an Inverter Heat Pump BELOW it’s Minimum Inverter Power.
The Reports Recommendations are shown in the following :

Recommend 11

Recommendations:
1) Recommended that Air Sourced Heat Pumps should be designed for a Minimum Run Time of 6 Minutes.
2) Run Times of ~ 8 Minutes gave COP Values close to the “Catalogue" Steady State Values.
3) 4 Pipe Buffer Tanks show a promising method of achieving the required Minimum Run Times without the need for “Excessive Buffer Volumes".

The Buffer here used was a Buffer fitted Across the Output ports of the Heat Pump :

Buffer Calculation DECC 2

Note also the Calculation of the Size of Buffer required:

Buffer Calculation DECC 3

Further note that these calculations are for an older control system, but , none the less valuable in the demonstration of a Buffer Tank fitted Across the Heat Pump Water output.

Also note the , by present standards, Very Poor COP that were achieved.

ian









Derek M 23 March 2024 at 17:02

@jamespa

You are indeed correct, it may depend upon what the water pump(s) are doing.

I know that some of the heat pump controllers continue to run the water pump for a number of minutes after the compressor and fan(s) have stopped, and may also periodically operate the water pump for several minutes to equalise the water temperature around the heating system.

From observing my own heating system, it takes approximately 4 minutes to heat the radiators to the temperature calculated by the controller, after which the boiler and water pump is stopped. During colder weather conditions the required radiator temperature may be in the 40C to 45C range, and it may only take 10 to 15 minutes for the radiator temperature to reduce by approximately 5C, at which point the boiler and water pump is restarted. During milder weather conditions the radiator temperature may only need to be in the 30C to 35C, so it may then take 30 to 60 minutes for the radiators to cool sufficiently for the boiler and water pump to be restarted.This keeps the IAT at 21C +/- 0.2C under all conditions.

The point I was trying to make is that the location of the LWT and RWT sensors is very important, particularly if the water pump(s) do not run continuously when the heat pump is no longer producing thermal energy. Continuously operating the water pump to prevent the LWT and RWT sensors cooling too quickly probably would reduce the cycling frequency, but would use more electrical energy and may also transfer thermal energy from indoor to outside. I’m not certain if any controllers operate in this manner. It would be interesting to see how the different heat pumps control their water pumps and also the actual location of the LWT and RWT sensors, and the effect this may have upon the frequency at which cycling takes place.

As I have stated previously, one possible way to reduce cycling frequency could be to set the WC curve such that it causes the IAT to start to increase before the heat pump reaches the point when frequent cycling is likely to occur, and then use a room thermostat to start and stop the heat pump rather than the LWT and RWT sensors.

HughF 27 March 2024 at 11:56

@derek-m The carel controller in my ASHP allows me to specify three pump modes: Normal, Demand, Continuous…
Normal – pump shuts off when setpoint is reached. Use this when driving a buffer tank.
Demand – pump will ‘sniff’ for a bit to see if the water in the circuit has dropped below the setpoint. No idea when you’d use this mode.
Continuous – pump runs whenever the call-for-heat is active. Compressor/fan come on as required under the control of the PID in the heat pump.
I use mine in continuous mode as I only have the single pump and I don’t have room stats.

iantelescope 28 March 2024 at 08:45

@editor
Design & Measurements of Heat Pump Performance?

Wall Thermal Conductivity, U  ……………abuse ?
Given my own experience, where my “installer" Altered the Wall Thermal Conductivity to justify the use of a particular Heat Pump Can I again ask the Question :

Why are Thermal Wall Heat Conductivities NOT Measured ?
Measurement would require the use of a standard Electric Fire attached to a Power Meter with TWO Thermometers , One indoor, the other Out Side.
From Experience, measuring U is  far more accurate and Untainted by  installer behaviour.

Measurement of the Performance of Heat Pumps?
Heat Pump Performance should be measured with an in -Water Power Meter !
Heat Pump Performance , COP should be Measured at the Start of the Piping System AND NOT at the Heat Pump itself.

Design
Heat Pump Systems should be designed with a Thermal Software e.g. H2x .

Measurements against the design?
Having completed a Software design the Performance MUST be tested against the Design!
Any deviations between the Design and Performance will bolster customer Confidence.

ian
p.s. As William Thomson, Lord Kelvin ,  said " if ye canny Measure it …..ye don’t understand it"












iantelescope 29 March 2024 at 11:54

My Heat pump REAL COP ( that measured at the start of the Radiator pipe circuit ) and Heat Pump COP ( as shown by the Heat Pump itself ) are for 28/29 March:

COP REAL COP 29 03 24

My REAL COP is therefore , circa 2.2 , while my Heat Pump COP is circa 2.9.
The Difference between My REAL COP and the Heat Pump COP is reflected in the Energy loss between the Heat Pump and my house:

losses 29 03 24

The Average Loss is therefore  circa 26% without using the HOT WATER TANK.
“Short Cycling" is shown in the FFT of the Heat Pump Power consumption :

3 29 00

With the Peak representing a Cycle Time of circa 10.11 minutes.
Peak Frequency = 157 Hz on a run of 95274 Seconds duration  gives a Wavelength of ~95274/157 Seconds , or ~10.11 Minutes.

The Run Time is shown in the following :

3 29 24

With the RUN Time here of 4.5 Minutes.

Conclusions:

1) With the DECC Report recommending a Minimum 6 Minute RUN TIME My Heat Pump is “SHORT CYCLING".
2) With the DECC Report recommending a Minimum 16 Minute CYCLE TIME My Heat Pump is “SHORT CYCLING".

iantelescope 31 March 2024 at 14:26

Measuring Cycle and Run Times on a Heat Pump

I record the Power Consumed by my Heat Pump on a Daily basis.
For example , on 30 th March I get:

3 30 10

Clearly, my Heat Pump is suffering from  “Short Cycling". The Question is “How Much"?
I can examine the “Short Cycling by taking the Fast Fourier Transform :

3 30 00

But , again , the “Short Cycling " , although much more prominent , with a peak at ~150 Hz , is still very Noisy!.
Also, the Run Time component of the cycle time is completely lost in the Noise!
Using the FFT as a filter for the Cycle Time gives:

3 31 24

Now a beautiful Noise free Sinusoid giving the exact Cycling Time as 10.12 Minutes!
On using the FFT as a filter for the RUN TIME  :

3 31A 24

Again a Beautiful Noise free Sinusoid giving the exact RUN TIME as 4.3 Minutes.

All Graphical work was performed using “SCILAB " on a LINUX PC.

Many congratulations to “Dassault " in France for rebuilding Scilab after a absence of Three Years!

Scilab will , probably work on “Windows" , probably!

iantelescope 1 April 2024 at 12:29

Is my Heat Pump Too SMALL for Winter AND TOO BIG for Spring?

My Heat Pump does Not supply ENOUGH Power HEAT DURING Winter .

1 28 11

Notice the HEAT PUMP is permanently ON , Controlled by the Inverter.

My Heat Pump does Supplies TOO MUCH Power  IN Spring!.

3 25 10

Notice the HEAT PUMP is “Short Cycling" , Controlled under Cycling !.

The RANGE of the Inverter , between Minimum Inverter Control and Maximum Inverter Power is TOO SMALL!

The Solution Would be to provide a Backup Electric Immersion  Heater inside my Volumiser Tank.

Why Do Manufacturers NOT Provide the MINIMUM AND MAXIMUM INVERTER POWER?

iantelescope 3 April 2024 at 08:47

Heat Pumps:  Hypothermia & Bankruptcy
Having spent ~ÂŁ14k on a Heat Pump I am now , a 76 year old , Am I Now faced with Heat Pump Hypothermia ?:

Body Temperature C

My “Installer" has now been STUCK-OFF for the THIRD TIME with the NIC making the comment that
" YOU ARE NOT GOING TO LIKE THIS ……………………BUT NOTHING CAN BE DONE “

The NIC have said that they are “Sorry"  but that they have exhausted their efforts by the application of Further SANCTIONS against my “installer".
My Blood pressure is , on average, over the Winter 155/84 as  shown in the following graph:

BloodPressure Temperature 2024

I am paying ~ÂŁ165 per month for the running costs of this Heat Pump !.
I am paying ~ÂŁ42 per month for the “loan " repayment for a  “Drawdown " Payment for this Heat Pump!
Heat Pumps:  Hypothermia & Bankruptcy


iantelescope 5 April 2024 at 11:58

Frenchmen, Germans and Blushing Heat Pump “Engineers!"

Over the past two years, visiting “Engineers" have produced the most extraordinary comments .

A visiting French Samsung “Engineer" produced the following classic:
Only the Germans REALLY Understand How Heat Pumps work!"

A visiting Blushed to the roots of his hair saying to his colleague :
" Perhaps you cannot set the Water Temperature because of what is being  displayed on the Front Screen !"
The Blushing “Engineer" had previously been found to have falsified my house  Energy requirements to justify the installation of the wrong heat Pump.

Another “Engineer" said that :
“WE will Repair and , if necessary replace your Heat Pump IF YOU AGREE TO THE REMOVAL OF ALL METERING". I Declined the offer.

A visiting NIC “Engineer" said that “I , the user, should NOT INTERFERE WITH THE SETTINGS INSTALLED BY MY INSTALLER “.

A Visiting TRIO OF ENGINEERS , including a NIC Engineer succeeded in completely stopping my Heat Pump when trying to simultaneously set the Water Temperature using “Weather Compensation " AND Explicitly set the water Temperature  using the Heat PUMP Field bit settings" :
" Long Silence …….." followed by the comment that " You, ( ME The USER ) HAVE INTERFERED WITH The Settings of the previous French Heat Pump “Engineer".
I reset, the , now faulty, Heat Pump about 30 minutes after the Trio left with their tails between their legs.

Finally, A visiting Father & Son pair of “Engineers" :
Father , Shouting : “ I have never, in 30 Years experience with Heat Pumps ever installed a buffer Tank……."
Son , Quietly : " I am well aware that fitting a Buffer Tank is used to reduce the excessive “Short Cycling" that you clearly have experienced , my only comment would be the Size and position of the Buffer/Volumiser tank".

Why Do some, ( MOST !) “Heat Pump Engineers" , have such a low opinion of themselves , their industry,  and their fellow competitor “Engineers"?

Mars 14 May 2024 at 16:08

It’s a bad day for buffer tanks. @heacol is officially the Head of Domestic Heat Pump Design Net Zero at British Gas. He’s tasked with getting BG engineers to improve design and installation quality. It’s a big move on Brendon’s part, and hopefully, one that will lead to a speedier transition to higher ASHP installation quality on a mainstream basis.

iantelescope 14 May 2024 at 22:01

I have been watching, with interest, the rebuild and replacement of a five year old Heat Pump on the Skillbuilder site.
The Results of the rebuild demonstrate How a heat pump should be installed!
The Skillbuilder channel has never given the cost of replacing the Heat Pump and the hot water tank, but the cost must have been substantial.
So , competent Heat Pump installers are available……………………………but unaffordable.
My own Heat pump has finally reached a COP of 4.5 ……………………but I DO NOT NEED A heat pump in these Temperatures.
As the NIC have repeatedly said of my Heat Pump …………………………NOTHING CAN BE DONE!
Abandon hope all ye who enter here!

Mars 13 June 2024 at 12:06

A light-hearted, funny video that highlights the divide that exists in the world of heat pump installations as two titans clash over the industry’s most contentious issue – buffer tanks.

IvanOpinion 17 June 2024 at 17:23

An interesting experiment on LLHs.

JamesPa 2 September 2024 at 19:56

Interesting, but the question remains, why bother with a buffer in a typical domestic installation.  Granted if you have another source of heating it might help with combining the two, but by far the majority of installations don’t.
It comes back surely to – if there isn’t a positive reason to fit it, then don’t – a comment which applies to almost any component of any system.  Not only is it wasteful of resources and money but it may (and does in the case of heat pumps) introduce unexpected and undesirable effects.  Furthermore if you don’t know why a component is there, how on earth can you spec it?

Mars 25 September 2024 at 08:17

As expected, after publishing the buffer tank Homeowners’ Q&A episode below, we received a lot of pushback, comments, emails and DMs from pro-buffer installers. Needless to say we invited plenty of pro-buffer installers and they all declined.

The best-performing ASHP on heatpumpmonitor.org, installed by Damon Blakemore, doesn’t use a buffer tank, and many of the top 50 systems also skip them. Damon has always told me that buffers often aren’t sized correctly, and secondary pumps are rarely set up properly, which stems from poor design. The approach many installers take seems to be fixing problems rather than optimising performance.

Manufacturers include buffers to minimise volume and shift any flow issues to the secondary side, which avoids warranty problems. However, secondary pumps aren’t factored into SCOP figures when buffers are used, which skews performance data.

JamesPa 25 September 2024 at 09:03


As expected, after publishing the buffer tank Homeowners’ Q&A episode below, we received a lot of pushback, comments, emails and DMs from pro-buffer installers. Needless to say we invited plenty of pro-buffer installers and they all declined.

Stick to your guns (which I’m sure you will).  Buffer tanks are, in most domestic cases, for the benefit of installers not homeowners.  That being the case some installers will always argue for them, just as the fossil fuel industry will continue to argue that climate change isn’t a problem/doesn’t exits/isn’t caused by human beings/can be solved by hydrogen boilers…
Both are wrong for provable scientific reasons and their reason for claiming what they do is apparent for all to see (not that this is any excuse at all for spreading disinformation).
Keep up the good work!

AlanB 9 October 2024 at 16:06

Hello All. Thought I’d throw in my experience. When we had our ASHPs installed in 2011, it came with a largish buffer tank, for all the usual reasons such as instant hot water when the heating stats called for it.
After around 6 years in, after reading up on efficiency, I decided to remove the buffer tank. I reasoned that the system was wasting lot of energy simply keeping the buffer tank up to temp. A fact confirmed by our Plumber, who is experience with ASHP systems as it happens. Our system is quite large, so surely there was enough water buffering in the pipework with out the need for buffer tank, we opined.
So, we duly removed the buffer and made some tweaks to the pipework as necessary token the system flowing.
Results were staggering. Roughly 25% drop in energy input required to give same heat output. I have measured this over several years to eliminate a mild one off winter.
So no Buffer or LLH in our system seems to be the answer.
Hope this helps.
Cheers
Alan

Judith 10 October 2024 at 07:26


Hello All. Thought I’d throw in my experience. When we had our ASHPs installed in 2011, it came with a largish buffer tank, for all the usual reasons such as instant hot water when the heating stats called for it.
After around 6 years in, after reading up on efficiency, I decided to remove the buffer tank. I reasoned that the system was wasting lot of energy simply keeping the buffer tank up to temp. A fact confirmed by our Plumber, who is experience with ASHP systems as it happens. Our system is quite large, so surely there was enough water buffering in the pipework with out the need for buffer tank, we opined.
So, we duly removed the buffer and made some tweaks to the pipework as necessary token the system flowing.
Results were staggering. Roughly 25% drop in energy input required to give same heat output. I have measured this over several years to eliminate a mild one off winter.
So no Buffer or LLH in our system seems to be the answer.
Hope this helps.
Cheers
Alan

Thats great to read!
Have you any detailed figures? Is the benefit more in shoulder season or in the coldest periods for example?


JamesPa 9 October 2024 at 16:21


After around 6 years in, after reading up on efficiency, I decided to remove the buffer tank. I reasoned that the system was wasting lot of energy simply keeping the buffer tank up to temp. A fact confirmed by our Plumber, who is experience with ASHP systems as it happens. Our system is quite large, so surely there was enough water buffering in the pipework with out the need for buffer tank, we opined.
So, we duly removed the buffer and made some tweaks to the pipework as necessary token the system flowing.
Results were staggering. Roughly 25% drop in energy input required to give same heat output. I have measured this over several years to eliminate a mild one off winter.
So no Buffer or LLH in our system seems to be the answer.

Thanks for sharing this and very pleased to hear the result.  Well done for having the courage.

Its worth being aware that there are (at least) two reasons why removing a buffer tank saves energy, and its not necessarily heat loss from the tank that is the major contribution:
1. You aren’t having to replace the heat lost from the buffer tank – however if the buffer tank is inside the heated envelope the energy isn’t really ‘lost’, and anyway with a well insulated buffer tank it should be no more than 1-2kWh/day
2. A buffer tank, unless very well set up, results in a temperature drop between the flow from the heat pump and the flow to the emitters because flow and return mix in the tank.  This means that the heat pump must operate at a higher flow temperature to get the same flow temperature at the radiators, and that means it is less efficient (lower COP) by very roughly 3% for each degree drop.
The latter is a function of the thermodynamics of heat pumps so doesn’t apply to fossil systems, which may be why some heating ‘engineers’ don’t understand it!
It is possible to set up a sufficiently tall buffer tank to avoid the flow and return mixing, and thus circumvent (2), but there are far too many reports where this has not been done (or is not even possible given the equipment/wiring used)



samiebon1 4 November 2024 at 07:36

Hi all,
Trying to jump on an existing thread before creating a new one.
We’re looking at getting an ASHP installed and im having the buffer/no buffer deliberation.
Currently looking at a 5kW Vaillant and our system volume is ~200L.
Installers are speccing buffers and one even said because of the new R290s you MUST have a buffer – I can’t see this anywhere in research. Is this a thing, and if not any tips on how to push back?
(Bonus: this ‘experienced’ installer said that the unit doesn’t have to be >1m from the boundry is the fan isn’t pointing at it. It’d help… but I dont think they’re right)


Mars 4 November 2024 at 08:50

@samiebon1, there’s a lot here that raises red flags with this installer’s advice, and I’d strongly recommend considering other options. This setup sounds like it could lead to complications down the road. Is this installer a one-man operation or a small company?

@judith is spot-on about low-loss headers. After nearly two months of behind-the-scenes conversations with installers we’ve interviewed for the podcast, I can confidently say buffer tanks are rarely needed. In retrofit setups, volumisers can sometimes be appropriate, but that’s typically where it ends. So, no need to second-guess your decision. I don’t think this installer is right for you.

Where are you based?

samiebon1 4 November 2024 at 09:16

@editor @jamespa Thanks both. The installer is part of a company (not one man band) and sounds experienced but the things they’re saying are a bit… odd.
They haven’t said volumiser, only buffer. I think i’ll push back a bit when they say Buffer (i’m an engineer so have some form of competence!). I’ve got a couple of companies coming to survey so will challenge and update you all!

Edit: Based in Manchester, England.

JamesPa 4 November 2024 at 09:02

Hi all,
Trying to jump on an existing thread before creating a new one.
We’re looking at getting an ASHP installed and im having the buffer/no buffer deliberation.
Currently looking at a 5kW Vaillant and our system volume is ~200L.
Installers are speccing buffers and one even said because of the new R290s you MUST have a buffer – I can’t see this anywhere in research. Is this a thing, and if not any tips on how to push back?
(Bonus: this ‘experienced’ installer said that the unit doesn’t have to be >1m from the boundry is the fan isn’t pointing at it. It’d help… but I dont think they’re right)


Check whether by ‘buffer’ they mean 2port volumiser (the key feature being 2 port).  That’s ok.  It’s typically 20-50l..  Vaillant do put a volumiser on most if not all of their  system diagrams and sofaik it does no harm.  It can go in flow or return (there are arguments both ways)but not between the two.  Anything else – avoid.

Assuming you are in England then the 1m from boundary rule applies.  I think it does elsewhere but would have to check to be certain.



Majordennisbloodnok 4 November 2024 at 09:11

Assuming you are in England then the 1m from boundary rule applies.  I think it does elsewhere but would have to check to be certain.

…and any attempt to suggest otherwise is most certainly a red flag until proven to be a valid piece of advice. As @editor said as well, what the potential installer has told you is rather screaming of “proceed with caution" at the very least.



Toodles 4 November 2024 at 09:11

@samiebon1 Sounds like some rowlocks are being bandied about to me…. Toodles.

Judith 4 November 2024 at 08:20

You need to use Heat Geek, BG or Octopus to be certain of no buffer. You may get a volumiser (smaller tank in series) depending on your system. Don’t give in to LLH brigade!
One company who normally install buffers were willing to do a lower temperature system without one once the ‘estimating engineer’/salesman spoke to the boss. But we reasoned why go with a company with little experience of the design.

samiebon1 4 November 2024 at 15:01

An update after I had some more interaction with those potential installers:
One had said the buffer was needed not technically but to cover manufacture warranty as thats how they specify the design (which made sense but would value other’s experience/input).
The other installer, when I challenegd on buffer and said the size of my heating system (~200L) he fully accepted that a buffer wasn’t needed.
Both however are still a bit lessay fair about the 1m distance and have only said it needs to have the fan pointing away. Makes technical sense and might be something along the lines of what I hear the MCS are looking to remove from requirements… but current guidance/requirments still says 1m.

Mars 4 November 2024 at 23:10

@samiebon1, I can confirm that not installing a buffer won’t void the warranty. This comes directly from Vaillant, who do not require a buffer or volumiser but simply recommend meeting minimum system volume requirements.

JamesPa 4 November 2024 at 15:29



Both however are still a bit lessay fair about the 1m distance and have only said it needs to have the fan pointing away.

. Makes technical sense and might be something along the lines of what I hear the MCS are looking to remove from requirements… but current guidance/requirments still says 1m.

This a matter of law not an MCS decision or even guidance.  End of unless you want to apply for planning permission.

https://www.legislation.gov.uk/uksi/2015/596/schedule/2/part/14/crossheading/class-g-installation-or-alteration-etc-of-air-source-heat-pumps-on-domestic-premises



One had said the buffer was needed not technically but to cover manufacture warranty as thats how they specify the design (which made sense but would value other’s experience/input).

You mention it’s a Vaillant.  As it happens I was looking at their their standard plumbing diagrams yesterday and certainly the one I looked at shows a 2 port volumiser (but not a buffer tank).  What I’m not sure is whether the text clarified the conditions under which it’s necessary (basically if you haven’t got sufficient system volume). Unfortunately installers appear to have a habit of assuming that if it’s in the diagram it’s necessary, which is not always true.

Vaillant tech support are very helpful so you / your installer could ask the question.

Don’t accept a 3 or 4 port buffer, there are definitely diagrams in the Vaillant approved set that have only a volumiser so you are being given bs if they say a 3 or 4 port is necessary to cover manufacturers warranty.  If they insist look elsewhere.

Mars 14 December 2024 at 22:10

I have posted these on the forums before, but have been asked by someone on YouTube how a volumiser differs from a buffer tank visually so reposting here as part of the definitive buffer tank thread.

System Separator

buffer

volumiser
ASHP-BOBBA 14 December 2024 at 22:45

@editor has anyone ever posted on the forum, I had a system installed, they did not fit a buffer but it turns out it needed one so the installer returned and fitted it?


Mars 14 December 2024 at 22:47

@editor has anyone ever posted on the forum, I had a system installed, they did not fit a buffer but it turns out it needed one so the installer returned and fitted it?

No, there has never been a case along these lines. There are, however, quite a few where the opposite has occurred. Buffer fitted with poor system efficiency; the buffer was then removed and the systems have run much better.



ASHP-BOBBA 14 December 2024 at 22:35

I wonder if CIBSE have an opinion on or a definition on when to use a buffer, low loss header or volumiser


ASHP-BOBBA 14 December 2024 at 22:37

Just thinking out load as in the Uk standards of excellence, approved codes of practice abd other forms of engineering standard often are derived from organisations such as CIBSE, BESA and so on

Mars 14 December 2024 at 22:54

@ashp-bobba, after years of conversations with numerous heat pump engineers and industry experts, it’s clear that there’s a significant gap in meaningful, authoritative guidance on best installation practices. Unfortunately, no governing body currently provides comprehensive standards that ensure optimal system performance. This may change in 2025 with the announcement of Flexi-Orb’s scheme, which looks very interesting (and promising).

The real advancements in installation practices have come from experienced engineers like @damon, @heacol, @patrickvito, @ken-bone, etc. who’ve consistently demonstrated that open-loop systems outperform buffered systems in both efficiency and reliability. Their work has been instrumental in driving improvements, but it also highlights the need for broader industry standards to raise the bar for everyone.

ASHP-BOBBA 14 December 2024 at 23:06

@editor I am aware, open loop, less pumps, slow and steady heat generation has proven more efficient, the clever engineering in ASHP is the inverter tech and compensation partnership, anything that restricts this take away some of that.


Mars 14 December 2024 at 23:00

@ashp-bobba I think we’ll see a different approach to buffers in the years ahead. Volumisers are a different story.

Neil, from Grant UK, stated quite categorically in our latest video that Grant don’t mandate buffers:

ASHP-BOBBA 14 December 2024 at 23:11

@editor I think these podcasts are great. I did watch this one yesterday I think. Lets see if the MI drop buffers in their schematics as options in the future. Yes volumiser will be needed for defrost on low volume systems. Perhaps they will drop the rule with split / duel zones on buildings over 150m2. All manufacturers also still allow for duel zones in their controls at the moment. Not open loop if you shut a zone down.



ASHP-BOBBA 14 December 2024 at 23:15

@editor Can you do a podcast on standards of training, whats available, how engineers get trained, where they come from, what level they get trained to, how engineers will get trained in the future, when to use and not to use some components and so on. That would be very interesting to see what the specialist say.



Mars 14 December 2024 at 23:20

@ashp-bobba we actually touched on that in yesterday’s recording that will go live on New Year’s Eve. Spoiler alert: there are very few options out there to train low temperature heating installers, but work is going on behind the scenes to improve standards.

ASHP-BOBBA 14 December 2024 at 23:28

@editor I will keep an eye out for that podcast, thank you.
Just a side note relevant to buffers, rails separators and volumisers. I may not be correct about all of them but I seem to remember that most ASHP manufacturers can provide full solutions so the ASHP and a pre-plumbed cylinder, if I remember correctly most pre-plumb cylinders come with 3 pumps, primary for the ASHP through a 3 port then connected to a rail / low loss header or the plate exchanger for DHW, heating pump on the other side of the header and a hot water pump from a plate. This in effect means most pre-plumbs come set up in one form or another as a low loss header / rail separator and a plate heat exchanger.
Not all are the same but many are. Perhaps these will not be popular in the future.

JohnR 15 December 2024 at 09:49

My system has one of the Telford Tempest cylinders with a 50 litre buffer tank in the bottom. It seems to work very efficiently (claimed COP of about 6 when 6C outside but a 28C heating flow temperature must be a key factor) and enables my 7kW Arotherm+ heat pump to run intermittently when it’s warmer than about 7C outside and the house needs some heat but not a lot. I haven’t seen any info about what’s inside the buffer tank but suspect that there may some form of baffle between the heat pump circuit (pipe connections on left side) and the radiator circuit (pipe connections on right side). It’s the same water in both circuits and both run as similar temperatures but the tank enables each circuit to run at its own flow rate as well as increasing the overall flow volume. The top title implies that having a buffer tank may be adversely affecting the efficiency of my system but I struggle to see how and why.

Mars 15 December 2024 at 11:34

The top title implies that having a buffer tank may be adversely affecting the efficiency of my system but I struggle to see how and why.

A properly installed buffer tank system can be efficient, but the challenge lies in the skills and knowledge of the installer. In the UK, many installers struggle to correctly balance flow rates before and after the buffer, leading to energy losses and reduced efficiency.

This is why many of the country’s top installers (that deliver highly-efficient systems) are moving towards open-loop, buffer-less systems. These systems deliver significantly higher efficiency, provide more uniform heat distribution, and eliminate the need for circulation pumps. Circulation pumps not only increase running costs but are also not accounted for in COP/SCOP calculations, further skewing perceived efficiency. Our buffered system has four circulation pumps because it’s been so appallingly designed and fitted.

iantelescope 16 December 2024 at 14:56

@editor  Why, oh why, are these system NOT Mathematically designed? In Electrical engineering many circuits are designed using P-SPICE Software. In electrical/Electronic engineering SPICE software calculates the behaviour and performance of an Electrical/Electronic circuit using precise mathematical models. Why are heat pumps NOT properly, mathematically designed?
These disputes about Buffer tanks, volumisers could be settled in the flash of a PC! Does anyone know of an affordable Mathematical design software?

ASHP-BOBBA 16 December 2024 at 16:22

@iantelescope They say its as a result of the combi birth and delta T changing from 11 to 20! as tech got better it required less flow so all of the existing pipework in building was instantly over sized, oversized pipework is completely fine for systems, also over sized rads (with new TRV tech at the time no longer mattered as TRV’s would stop the oversized boiler from overheating the oversized rad in the room) and so on, the combi sizing chart also helped, hello Sir would you like 6lts, 7lts 11lts or even 13lts of 55 deg hot water flow? This means you will get a 20kW, 24kW, 32kW or a 36kW boiler respectively. So now you have a heating boiler oversized by 8 times the requirement just to do the hot water. From that date all new engineers generally got told the water is what matters heating will always be fine.
Now hydraulics matter, friction matters, emitters matter, pressure matters and effectively the whole design matters more than ever. I think they need to make a rule if you cannot design it or get it designed then you should not install it.
Does make you wonder if there is a whole gap in the market for ASHP designers, nice little business running around designing systems correctly.
I wonder if the big 6 (meaning power companies) design accurately and can still offer the av install ÂŁ2000 less than your av smaller companies and supervise all of the sub-contractors they use to install to design when they don’t have enough engineers of their own. Just a thought.





JamesPa 16 December 2024 at 15:20

These disputes about Buffer tanks, volumisers could be settled in the flash of a PC! Does anyone know of an affordable Mathematical design software?

PSPICE I think, it seems highly likely that a heat pump system, including the house, can be described in electronic terms.  Cant see the average plumber doing this though.  Its more a ‘suck it and see’ trade.

In all seriousness I think its becoming increasingly clear that in the vast majority of domestic situations its actually fairly easy with the exception of the first bit – determining the loss.  However once you have done that,

  • Put in a heat pump of adequate size, a diverter valve and if you must a new DHW tank.
  • Roughly estimate system volume and if there is doubt put in a volumiser.
  • Dont put in a buffer, LLH, heat exchanger of any type.
  • Use pipe sizes according to heat geek cheat sheet or similar unless its a mansion or a silly route.  Prefer swept bends over elbows.  If any existing pipes are undersized assess risk and (probably) suck it and see unless its an obvious fail
  • Set up WC and radiator balance as best you can and give homeowner some simple instructions how and when to tweak.
  • If homeowner doesn’t want to tweak then set up WC as best you can, erring on the high side, and layer the system thermostat, not a third party one, on top to give fine control.

Obviously the above (and the associated works) has to be done properly, but I don’t think it merits much simulation in the vast majority of cases.

How many plumbers actually calculate the index circuit when replacing a boiler?  Boiler manufacturers know this which is why they supply boilers with circulation pumps adequate for the majority of realistic situations.

ASHP-BOBBA 16 December 2024 at 17:13

@jamespa Fair point, its good to know better standards and designs are getting covered under the MCS schemes. Perhaps once it all starts to come together things will get better.

iantelescope 16 December 2024 at 23:44

Questions for the Pro and anti-Buffer tank Zealots!!
Why NOT Design the Heat Pump, pipes and all, before you “try to adjust it with a hammer and a hack saw"!!
Does anyone know if “HeatPunk" Software design package, sold by Midsummer  for heat pump systems is any good ??
Why not Fit your buffer tanks with valves to either use or Not use your buffer tanks.!!

JamesPa 17 December 2024 at 09:24

These are all very good questions.  Unfortunately most people are reliant on installers to do the ‘design’ and decide what valves are (or are not) put in, so don’t have this option.

Those who, like me, had the fortune to ‘lurk’ here for a few months before getting their heat pump installed (not out of choice – it was serendipity) can do/did just this and are thus in a position to reject offers from installers that want to do silly things.

iantelescope 17 December 2024 at 10:26

@jamespa
HEATPUNK Design Software??
Does anyone have any experience with the HEATPUNK Design Software supplied by midsummer ??
Volumisers with Valves??
Volumising tanks can , sometimes, be easily fitted with  valves.
Compare the performance of the System with or without the Volumising tank.
Heat Ex-changers ??
Heat Ex-changers allow the user to match the differing Water Flow rate requirements of the Heat Pump to the Radiator requirements.
For example, on my system, the Heat Pump flow rate cannot be reduced below 14 l/min while the Radiators require 7 l/min to provide an adequate Delta_T across the Radiators.

Flow rate Through the Radiator Circuit , as measured by a “Sharky" water Power/Flow meter is ~7 l/min.

Flow rate


Delta_T across  the Radiator Circuit, as measured by a “Sharky" water Power/Flow meter.

Temperature Difference

Delta_T across the primary ports of my Heat Exchanger, Measured by a pair of DS18B20 Sensors.

Difference Temperature 12100918

Notice the ~5 C Delta_T across the input ports of my Heat Exchanger.
The Heat Pump Water flow rate is 17 l/min .
The Flow rate cannot be reduced below 14 l/Min .
At 14 l/min the Heat Pump faults with inadequate flow rate.
Further observations
Short Cycling may NOT be caused by the Volumiser .
My Short Cycling was principally caused by my thermostat.
Setting my Thermostat for a 20 minute Cycle time solved SOME of my problems.

cycle

The Cycle time is now completely controlled at ~20 minutes.
My Heat Ex-changer has protected the Heat Pump from the Radiator water contamination.

SNV82102


I paid ÂŁ600 to get this stuff Flushed from BOTH my Radiator circuit AND my Heat Pump , just in case!.
I paid a further ~ÂŁ350 to replace the last of my old Radiators.

Judith 17 December 2024 at 18:55

@iantelescope Heat-punk is good for seeing the effect of radiator size, flow temperature and general house heat loss. You put in all house dimensions and it calculates heat loss and hence what size heatpump you need and which rooms might need radiator changes.
It does nothing about pipe sizes since the pipe layout is not asked for, so no recommendations about valve sizes. It relies on the plumber sizing the pipes correctly. It has no knowledge of fluid dynamics at all, and is steady state.
I think your suggestion of a non-linear solver like the spice family is using a sledgehammer to crack a nut,  ditto valves to add 2 or 4 port buffers. Who has the fault analysis technique to know what is needed from the system limits. Neither the homeowner nor the installer.

Mars 17 December 2024 at 21:05

Welcome to the forums.

I am amazed at the breadth of discussion on this topic but have not absorbed everything. There are interesting snippets and some pretty wild theories.

And this is precisely why the heat pump installation landscape is such a mess and we’re getting such varied levels of installations of heat pumps, with and without buffers.

JamesPa 18 December 2024 at 08:38

Occams razor comes to mind here.

In any good system design every component has a purpose. If the purpose has little or no value then the same is true of the component. Furthermore, where there are alternative ways to achieve the same purpose (and that purpose has value), an analysis of the options should be done to work out which of the options is the best (however best is defined which of course is situation dependent). If introducing a component to solve a particular problem causes undesirable side effects, then the undesirability of these side effects needs to be assessed against the desirability of the purpose and an appropriate choice made.

Its also worth bearing in mind that most central heating systems are built by a branch of the construction industry and operated by normal human beings who have little or no interest in their inner workings. This means that the designer must assume that they may not be put together/commissioned in precisely the optimum way for the individual application, or even precisely as designed, and equally one must assume that they may be operated fairly crudely and with little or no understanding (or even interest in understanding).

Multiple zones (with all that implies), buffer tanks/low loss headers, volumisers (which should be distinguished from buffer tanks as they are totally different beasts) all add to system cost and complexity, both for the installer and the homeowner.  All have potentially negative side effects in addition to the ‘purpose’ that they are intended to fulfil, and all have the potential to be mis-installed/misconfigured or operated in a way which largely or entirely defeats their purpose.  That doesn’t mean that they have no application at all, but it does mean that deploying them willy-nilly without thinking through the side effects and risks is a folly.

There is, of course, no one answer.  A long, thin, 8 bedroom mansion with UFH is very different in nature to a 3 bed, essentially cubic, semi with radiators, both in its thermal dynamics and its use and it would not be surprising if these lead to different conclusions.  That said there probably are only a relatively small number of classes of case such that, within any one class, 90% plus of properties will conform.

If we are to move this discussion much beyond ‘be extremely wary of LLHs and buffers because they can sabotage your heat pumps efficiency’,  which is more or less undoubtedly excellent general advice, perhaps we need to talk of these classes and/or identify the exceptions where the general advice is at least reasonably unlikely to apply.

Heatgeek 19 December 2024 at 19:16

@jamespa Invoking Occam’s razor in this context does not help. In engineering, there are right answers and wrong answers, not alternative facts.  Nevertheless, I accept the spirit of the frustration regarding the plethora of confusing solutions and components. I will try and clear some of the fog as I see it.
Regarding LLH, this is used when there is a mismatch of FLOW between primary and secondary water circuits. There is an interesting example from ProtonsForBreakfast early on in this discussion regarding his LLH. His figures and logic are all over the place, nevertheless it is a very good example.

PFB Diagram

He has a 5kW Vaillant HP. From his diagram, it is not possible for the HP to supply 20l/min, nor is it possible for 4l/min flow on the secondary for peak output to give 53C return. Ignoring these figures, let us assume that his 160 sqm house needs 5kW peak at design temperature. The following refers.
The secondary pump has a fixed flow and if a maximum of 5kW output is required with a 10C drop across radiators, then a pump flow of >7l/min must be set (numbers rounded). The valve restriction on rads will force the flow to 7l/min for 5kW. The HP however operates at 5C difference therefore will generate a flow of 14l/min for 5kW (math). Therefore half the flow goes to the rads with a 10C drop and the other half bypasses through the LLH to provide final 5C drop at HP due to the flow mismatch. If the outside temperature halves in value (i.e. half power required), the flow from HP will reduce to 7l/min to maintain 5C Dt for 2.5kW output and no flow will bypass through the LLH due to the 7l/min fixed flow of rads. Drop across the radiator is now 5C.
This is where the design stupidity is exposed. If you now remove the LLH and second pump, flow will still be 7l/min from the HP with 5C drop across the rads. If then outside temperature now doubles, HP flow will double to 14l/min and drop across rads will remain at 5C. This flow is perfectly compatible with the HP so the LLH is superfluous. This is why PFB saw no change in his performance. The designer was applying old fashion thinking of 10C drop necessary across radiators hence the mismatched flows.
Now for water content. Vaillant 5kW requires min. 40l in heating circuit for defrosting (if backup inactivated) which PFB presumably has due to the radiators. A problem arises when the heat requirement falls below the minimum flow requirement of the Vaillant i.e. 2.5kW. PFB requires 55C for his rads at peak output. If this output temperature is fixed on the HP, then cycling sets in when outside temperature dictates <2.5kW heat requirement. The way to overcome this is through Weather Compensation to increase the Dt linearly between the water flow temperature and room temperature to adjust to the lower heat loss to the outside and maintain 5C Dt.
This example suggests an answer to the 90% holy grail. If PFB replaced his downstairs radiators (half the area) with UFH he would need 400m of pipe @ 20mm spacing. This has a water content of 48l so defrost is satisfied, assuming upstairs rads do too. Multiple pipe loops in parallel will accommodate the flow needed. So he can have a directly connected 2 zone system. The downstairs heat loss and spacing would have to be meticulously planned to ensure uniformity. An average house of 120 sqm will require 300m of pipe downstairs with 36l plus the connecting pipe content, so also no problem with content. A house with no insulation would just have say 10kW and double water content so more zones possible.
The problem arises when fine control is wanted in a bigger house as pointed out in my previous post. There is not enough individual zone flow or water for defrost for a single connected zone like a bathroom. The answer is……you’ve guessed it. A BUFFER TANK! A 50l tank in parallel will supply sufficient content and flow in extremis.So these components are not used “willy nilly”. They each have a purpose and do not cause efficiency problems. Only idiot installers abuse their use as seen above. For the average house of 120sqm, a 2 zone simple system with UFH downstairs and correctly rated rads above will suffice with a direct connected HP with Weather Compensation. The most important principle of all is to ensure that the heat loss design is carried out accurately to ensure uniformity of heating.
Water content and flow. That is my view, anyway and I am not an installer.

JamesPa 19 December 2024 at 19:55

@jamespa Invoking Occam’s razor in this context does not help. In engineering, there are right answers and wrong answers, not alternative facts.

I am referring to Occams razor in the sense of cutting out the unnecessary and I explain this in my post.  If its unnecessary (in a particular application) then its unnecessary.  Thats a fact, not alternative.

That said, in my personal experience of engineering, there are often a range of ‘right’ answers with different trade offs (as well as some wrong ones) and the trade offs you choose depend on the circumstances and customer.  A 2CV and a Bentley are both valid solutions to the problem of creating a working car to get you from A to B, appealing to different markets.

In your first example I think you conclude that an LLH/buffer tank is not necessary but that the downstairs rads could be replaced with UFH to give adequate system volume for defrost/to meet the spec of the heat pump.  The latter may well be true but it is rather disruptive and expensive unless the work is going to be undertaken for another reason.  A much simpler and cheaper way to solve the problem is to add a volumiser (a 2 port buffer tank if you wish) which has minimal side effects because it is 2 port.  You will  note that, in my post, I draw a distinction between buffer tanks and volumisers for precisely this reason, a volumiser has few side effects.  Of course it only solves one problem, system volume, but if that is the problem to be solved a volumiser is the right choice.

In the second (larger house) variation you suggest adding a 50l buffer tank in order to supply a bathroom as a zone to run on its own.  I would question the wisdom (or utility) of designing a system to do this in the first place but agree that, if you must do this for some reason, its likely that a form of separation will be needed.

Finally you comment that

So these components are not used “willy nilly”. They each have a purpose and do not cause efficiency problems.

Unfortunately the evidence from this forum, over the two years plus that I have been following it, is that buffer tanks and LLHs are used willy nilly by some installers.  Furthermore a badly designed buffer tank/buffer tank with badly designed controls certainly does cause efficiency problems, typically involving a sacrifice of 15% or thereabouts and/or poor heating capacity.  Hence the title of this thread (not my title incidentally)- “Why Low-Loss Headers and Buffers Can Sabotage Your Heat Pump’s Efficiency.".  Many of the instances of poor performance on this forum can be traced to unnecessary buffer tanks /llhs.  Its sad that this is the case, but that is the fact.

As a general reflection on your comments on ‘control philosophy’ it is pretty clear that the benefits (or not) of zoning and setbacks are both variable and themselves the subject of some discussion.  Heat Geek (the website) gives a worked (and very plausible) example where physical zoning increases cost, because the reduced efficiency (due to smaller emitter area=higher flow temperature) outweighs the saving in heat loss.  There are many variables, but I think its fair to say that its far from clear that zoning in a modestly sized, roughly cubic, house with little or no internal insulation may not save much or any money, and may even cost more.  Setbacks are probably clearer, in many cases a modest setback will likely save money, however it is possible to come up with circumstances where this is not the case.  Due care is thus necessary before assuming that trying to finesse which parts of a house are heated at which times is actually beneficial.



Heatgeek 20 December 2024 at 13:39

@jamespa I am reposting this due to my revisions being gobbled up by this site. I have tried to remove the confusion and ambiguity caused by my previous post. I accept the spirit of the frustration regarding the plethora of confusing solutions and components. I will try to provide my own take on this.
Regarding LLH, this is used when there is a mismatch of FLOW between primary and secondary water circuits. There is an interesting example from ProtonsForBreakfast (through @toodles) early on in this thread regarding his LLH. He has done very detailed measurements on his HP system with LLH over 2 winters to evaluate his COP and 1 winter without LLH. He discovered that there was no difference in performance at all. Why, one might ask? His initial figures and logic in his diagram are all over the place, nevertheless it is a very good example to analyse.

PFB Diagram

He has a 5kW Vaillant HP. From his diagram, it is not possible for the HP to supply 20l/min, nor is it possible for 4l/min flow on the secondary for peak output to give 53C return. Ignoring these figures, let us assume that his 160 sqm house needs 5kW peak at design temperature. The following refers.
The secondary pump has a fixed flow and if a maximum of 5kW output is required with a 10C drop across radiators, then a pump flow of >7l/min must be set (numbers rounded). The valve restriction on rads will force the flow to 7l/min for 5kW. The HP however operates at 5C difference therefore will generate a flow of 14l/min for 5kW (math). Therefore half the flow goes to the rads with a 10C drop and the other half bypasses through the LLH to provide final 5C drop at HP due to the flow mismatch. If the outside temperature halves in value (i.e. half power required), the flow from HP will reduce to 7l/min to maintain 5C Dt for 2.5kW output and no flow will bypass through the LLH due to the 7l/min fixed flow of rads. Drop across the radiator is now 5C.
This is where the design stupidity is exposed. If you now remove the LLH and second pump, flow will still be 7l/min from the HP with 5C drop across the rads. If outside temperature now doubles, HP flow will double to 14l/min and drop across rads will remain at 5C. This flow is perfectly compatible with the HP so the LLH is superfluous. This is why PFB saw no change in his performance. The designer was applying old fashion thinking of 10C drop being necessary across radiators hence the mismatched flows.
Now for water content. Vaillant 5kW requires min. 40l in heating circuit for defrosting (if backup inactive) which PFB presumably has due to the radiators. A problem arises when the heat requirement falls below the minimum flow requirement of the Vaillant i.e. 2.5kW. PFB requires 55C for his rads at peak output. If this output temperature is fixed on the HP, then cycling sets in when outside temperature dictates <2.5kW heat requirement. The way to overcome this is through Weather Compensation to increase the Dt linearly between the mean water flow temperature and room temperature to adjust for the lower heat loss to the higher outside temperature and maintain 5C Dt.
This example suggests a possible answer to the holy grail of a generic use case which could satisfy 90% of average houses as posed by @jamespa. If PFB had implemented a UFH system downstairs (half the area of 160 sqms i.e. 80 sqms) he would need 400m of pipe @ 20mm spacing. This has a water content of 48l so defrost is satisfied, assuming upstairs rads do too. Multiple pipe loops in parallel will accommodate the flow needed. So he can have a directly connected HP with a 2 zone system. The downstairs heat loss and spacing would have to be meticulously planned to ensure uniformity. An average house of 120 sqm will require 300m of pipe downstairs with 36l plus the connecting pipe content, so also no problem with content. A house with no insulation would just have say 10kW and double water content so more zones possible
.The problem arises when fine control is wanted in a bigger house as pointed out in my previous post. There is not enough individual zone flow or water for defrost for a single connected zone like a bathroom or bedroom. The answer is……you’ve guessed it. A BUFFER TANK! A 50l tank in parallel will supply sufficient content AND flow in extremis.So these components are not to be used “willy nilly”. They each have a purpose and do not cause efficiency problems in my view. Only idiot installers abuse their use as seen above. In summary, for an average house of 120sqm, a 2 zone simple system with UFH downstairs and correctly rated rads above will suffice with a direct connected HP with Weather Compensation WITHOUT LLH or Buffer Tank. Some argue that LLH is required even if there is full flow-through without diversion due to the need for an HP overrun bypass. Not idiotic, but it is infinitely more expensive than a cheap automatic bypass valve across the flow lines. Therefore in my view there is absolutely no need for a LLH unless there is flow mismatch. The most important principle of all is to ensure that the heat loss design is carried out accurately to ensure uniformity of heating.
Finally, a volumizer provides increased water content for defrost but it is in series with flow so a large one will cause hysteresis and will not provide a water bypass flow path. A buffer tank is better for both content and bypass flow if connected 2 pole across the flow pipes where needed as per my previous post. The push and pull of the pumps will cause flow to largely bypass the tank without mixing. A buffer should only be needed exceptionally.
Water content and flow are paramount. That is my view, anyway, and I am not an installer.

JamesPa 20 December 2024 at 14:03

therefore in my view there is absolutely no need for a LLH unless there is flow mismatch.

Agree, and if there is a flow mismatch the question is ‘why’ and can it be eliminated using something without undesirable side effects.  In most cases the answer will be yes (or that the flow mismatch arises only because of the LLH).

Finally, a volumizer provides increased water content for defrost but it is in series with flow so a large one will cause hysteresis and will not provide a water bypass flow path.

A correctly sized volumiser will bring the system volume up to the figure required to satisfy the defrost requirement, and thus will have no more hysterisis than is necessary for that purpose.  Obviously if its oversized it will have more, but if your installer cant properly size a volumiser then they surely cant properly design and fit a buffer in a way that does not cause significant degradation of performance.  A buffer connected from flow to return has the potential to short circuit the heating system altogether, and indeed we have seen this in posts on this forum.  A volumiser fitted either in the flow or in the return is fool proof which is an important feature in practice, it seems.  A pressure activated release valve can be fitted if deemed necessary (I have yet to hear a convincing argument for this which does not simply mask a problem, but I grant it does depend on the details of both the heat pump and the system.)

A buffer should only be needed exceptionally.

Agreed, hence the whole thrust of this thread.  Unfortunately buffers, it seems, are fitted more often than ‘exceptionally’.

So these components are not to be used “willy nilly”.

Absolutely agreed that they are not to be, unfortunately the evidence is that they are!



My personal view is that we are ‘in transition’.  There has been an unfortunate history of fitting buffers/LLHs principally to avoid the risk of call outs due to low flow (which is masking the problem not solving it) and the need to do so has become to an extent embedded.  There was a point where fitting a buffer was more or less the default for many installers, and there are probably some where it still is.

More recently the problems they cause have been recognised and so the previous practices are being called out and some who used to advocate them admitting the reasons and changing their position.   Its going to take a while before we get to the point where buffers etc are not ‘fitted willy-nilly’ and for that period the public need to be warned, to the extent that this is possible.

Mars 20 December 2024 at 21:01

Next year, we have another episode of our podcast dedicated to the buffer tank. It’s going to be a real in-depth plunge, and I’m assembling a really competent panel to get definitive answers and examples.

JamesPa 20 December 2024 at 21:33

Next year, we have another episode of our podcast dedicated to the buffer tank. It’s going to be a real in-depth plunge, and I’m assembling a really competent panel to get definitive answers and examples.

That will be fun!



Mars 20 December 2024 at 21:47

@jamespa Yes, it should be fun, depending on your definition of the word. 😂 I was aiming for a really balanced discussion. Ironically, every installer I know who strongly advocates for buffers has declined to join, including over 15 Aira engineers. That’s a strong message in itself.

JamesPa 20 December 2024 at 21:52

@jamespa Yes, it should be fun, depending on your definition of the word. 😂 I was aiming for a really balanced discussion. Ironically, every installer I know who strongly advocates for buffers has declined to join, including over 15 Aira engineers. That’s a strong message in itself.

That’s a shame as I was looking forward to the fireworks, but as you say it’s a strong message which needs to be heard.



iantelescope 21 December 2024 at 12:21

@editor
My Heat Pump consumes 40% more Energy than the Gas  boiler it replaced
Having kept my Gas consumption records before switching to a Samsung Heat Pump I can compare  Energy Consumption between Gas Boiler and Heat Pump.
The  Energy consumed on Sept,Oct, and Nov 2024 by my Heat Pump was 42% ,33% and 37% of the Energy consumed by my Gas Boiler between Sept and Nov 2021.
With Electricity costing 3.8 times the Cost of Gas the Heat Pump becomes uneconomic.
My Heat Pump is consuming  ~40% more Energy than the Gas boiler it Replaced. ( and that’s before the energy Increases !!)
Can anyone supply the name of an affordable Software Design package for Heat Pumps comparable to SPICE in Electrical Engineering.
Definitive mathematical solutions using differential equations ……………….. competent modelling !!
With definitive mathematical answers ,I will then decide if Buffer tanks, Heat Ex-changers , Volumisers are useful or not!

Judith 21 December 2024 at 13:53

Perhaps you should sort out /have someone else sort out your system and then you’ll will know what matters. I know several posters here have told you what to do.
Then you can model it knowing some data points. Until then it is GIGO.
Our system is running a cop in region of 5 and the cost is considerably lower than our gas previously. So yours is demonstrated to be poor. Just fix it, modelling not needed.

JohnR 21 December 2024 at 15:44


@editor
My Heat Pump consumes 40% more Energy than the Gas  boiler it replaced
 Having kept my Gas consumption records before switching to a Samsung Heat Pump I can compare  Energy Consumption between Gas Boiler and Heat Pump.
The  Energy consumed on Sept,Oct, and Nov 2024 by my Heat Pump was 42% ,33% and 37% of the Energy consumed by my Gas Boiler between Sept and Nov 2021.

With Electricity costing 3.8 times the Cost of Gas the Heat Pump becomes uneconomic.

Shouldn’t the headline be My Heat Pump costs 40% more to run than the Gas boiler it replaced
The heat pump energy input (kWh, I assume) is only about 40% of the gas consumption but the big difference in unit cost between electricity and gas makes electricity more expensive (unless you get on a heat pump friendly tariff). Add in an annual heat pump service at ~ÂŁ250 and the situation will look even worse.


iantelescope 21 December 2024 at 23:37

@johnr
Running costs:
Yes John , I stand corrected again .You are of course perfectly correct …..forgive my anger ……….
I meant to say that My Heat Pump costs 40% more to run than the Gas boiler it replaced.
This 40% figure excludes the fuel increases !!
Building Heat Pump costs
Again ,you are perfectly correct in pointing to the building costs of circa ÂŁ16000 .
The Scottish Govt having repaid some ÂŁ3000 MY up front Building costs are currently ~ÂŁ13000 !!!
Service costs:
Because of the extensive Sawing , hammering and general abuse of the  Pipe Work I  have had BOTH of my pipe circuits Flushed  at a costs of ~£600.
Further damage has been done by 18 months of “Short Cycling " caused by my Heat Pump being wrongly adjusted for a 10 minute cycle .
The 10 minute cycle was originally attributed to the Water Volume in the primary circuit being insufficient.
Further damage has undoubtedly been caused by running the Primary Water circuit with an “insufficient WATER VOLUME" .
The Water Volume was increased by my Installer advised by Samsung when fitting a 50 L “Volumising tank" .
The Justification for the 50l tank was later modified to that of reducing the build up of ICE on the fins of the Heat Pump itself.
Measurements: Lets get numerate!
COP has a limited meaning ………….what Should ALSO be measured is the REAL COP !
REAL COP is the Ratio of Energy available at the start of the Radiator Circuit , kWh ,to the total input Energy, kWh.
 REAL COP =   Energy available at the Start of the Radiator circuit / Total Input Energy:


cop

Here the Blue line represents the COP at the Heat Pump Output . Here an average of 3.06 over the last two or more months !!
Here, the RED line represents the REAL COP at the Start of the Radiator circuit.: Here an average of 2.4 over the last two  more months !!
A REAL COP of 2.4 is totally uneconomic when the ratio of Electrical Energy to that of Gas is 3.8 :1 !!
The king is in the altogether …………………Heat Pumps have many unspoken problems.

Sandy 22 December 2024 at 16:36

@editor Will Brendon Uys be on the panel? I understand he is head of design within British Gas and I’ve seen videos with him in advocating against buffers in most situations, so I’d be interested to why they are still being included in quotes without any obvious reason.
I had BG do a quote in the past couple of weeks which I have accepted, but only after asking for the buffer to be removed. It’s a single zone house, 22mm copper pipework between floors, 15mm to radiators and enough volume for defrost, so no reason that I can see for a buffer.
The initial reason I was given was that Vaillant require a buffer but after I pointed out that plenty of Vaillant’s are installed without one the surveyor (who was very good otherwise, no complaints there) quickly removed it and I saved just under ÂŁ600 and a huge amount of space in a cupboard.

Mars 22 December 2024 at 22:32

@sandy Brendon will almost certainly be on it, unless there’s a scheduling issue. He’s been driving change at BG, but interesting what you’ve mentioned about your recent quote… glad to see to the buffer was removed though. Well done for flagging this.

cathodeRay 21 December 2024 at 08:11

every installer I know who strongly advocates for buffers has declined to join, including over 15 Aira engineers. That’s a strong message in itself

Very telling!

JamesPa 21 December 2024 at 08:42

@mars – have you considered ’empty-chairing’ the buffer tank advocate.  It would send a very powerful message throughout the video without you having to repeat it.

fillib 11 January 2025 at 00:00

Great to see the discussion! We had an ASHP with a buffer tank installed by BG and after quite some time of complaining about our low efficiency they actually came back (Brandon himself 😀) and re-piped the 40l 4-port buffer as a simple volumiser and removing the secondary circulation pump completely. So it’s an open loop now.
Without the buffer, the efficiency was significantly improved. The SCOP was 2.4 and I think is currently on track for something around 3. Still not exactly great and I am still puzzling about this, but I think definitely the right thing to do to “remove" the buffer (i.e. to re-pipe as a simple volumiser).
Many thanks to BG and Brendon for actually coming back and changing the pipework! 👍
Hoping now to solve the remaining conundrum (very low dT=low heat transfer and suboptimal COP), hopefully with some help in the forum, but I will post that in another thread.
In my experience the buffer tank definitely was holding back the efficiency and was absolutely not necessary. See comparison of COP (heating only) before and after the change from buffer to volumiser.




JamesPa 11 January 2025 at 10:54

Great to see the discussion! We had an ASHP with a buffer tank installed by BG and after quite some time of complaining about our low efficiency they actually came back (Brandon himself 😀) and re-piped the 40l 4-port buffer as a simple volumiser and removing the secondary circulation pump completely. So it’s an open loop now.
Without the buffer, the efficiency was significantly improved. The SCOP was 2.4 and I think is currently on track for something around 3. Still not exactly great and I am still puzzling about this, but I think definitely the right thing to do to “remove" the buffer (i.e. to re-pipe as a simple volumiser).
Many thanks to BG and Brendon for actually coming back and changing the pipework! 👍
Hoping now to solve the remaining conundrum (very low dT=low heat transfer and suboptimal COP), hopefully with some help in the forum, but I will post that in another thread.
In my experience the buffer tank definitely was holding back the efficiency and was absolutely not necessary. See comparison of COP (heating only) before and after the change from buffer to volumiser.




Can I just say well done!, (a) for persuading BG to come out and do what (it seems) so many need done to their systems and (b) for collecting the data to prove that it worked!  This isnt the first time I have seen removal of a buffer reported, but it is the first time Ive seen it reported and done by one of the ‘big ones’ and accompanied by evidence of the effect.



fillib 24 April 2025 at 00:07

I have an update. While the buffer to volumiser change (and removal of the extra circuation pump) was certainly a good thing, it seems that our main issue was simply the oversized heat pump. The installer (BG) now thankfully also swapped the 7kW for a 5kW ASHP (also Vaillant aerotherm plus) and our COP so far jumped up massively. See graph with the daily heating COP for different outdoor to indoor T differences. green: 7kW and buffer, red: 7 kW and vollumiser, yellow: 5kW and volumiser. The flow rate of that 7kW unit was high, so there was also a big difference between the ASHP side and the circulation pump side on the buffer, so probably lots of mixing. Perhaps with the lower flow rate of the 5kW unit, the buffer configuration would not have been an issue, however it would have still been completely pointless in our case, and simpler is better.
Many thanks to British Gas, for actually sorting this out for us! I am overall very happy with their support.
THe ASHP has been really great to set up and provided very comfortable heat, and now finally we also have the good  efficiency to save loads of CO2 emissions. I would boldly project that we might get a SCOP around 4 now.
We replaced our gas boiler, which wasn’t too old and was still working, so it could be argued we shouldn’t have swapped it, but we had a few recurring issues with leaks and defect parts at one point the leak also led to destroying our dishwasher below it. Now it also seems that it has been very inefficient indeed. We used around 10,000 kWh of gas to keep our house around 19-20degC. Now according to the Vaillant app we actually used around 6000 kWh of generated heat to keep the house around 20-21degC, so only around 60% efficient.
Assuming 75% boiler efficiency, head demand of 6000kWh per year and a SCOP of 4 (also assuming 0.309 kg CO2 per kWh electricity, and 0.185 kg CO2 per kWh gas), I calculate, we now save around 1000 kg CO2 per year!Even at our worst SCOP with the previous ASHP unit, we still saved around 700 kg CO2 emissions per year.
Cost-wise, I would very roughly estimate that in around 12 years the expensive ASHP will have overtaken any initial savings if we had gone with a new gas boiler, however I think this calculation is a bit pointless. We would have saved 2000 GBP if we had had the current BUS grant, I don’t know what a new boiler installation costs, etc. Mainly for us it was to reduce our CO2 emissions, and have a warm house with a better conscience also with regards to the war in Ukraine. Anyway, a decently efficient ASHP (SCOP 3.5) costs the same or less money to run compared to even a highly efficient a gas boiler (95%). In our case it seems we should now spend around 180 GBP less for heating per year.
Spreadsheet with my calculations (cost and CO2 emissions) attached.

COP heating



Lucia 12 January 2025 at 17:11

@jamespa
Multiple zones (with all that implies), buffer tanks/low loss headers, volumisers (which should be distinguished from buffer tanks as they are totally different beasts) all add to system cost and complexity, both for the installer and the homeowner.  All have potentially negative side effects in addition to the ‘purpose’ that they are intended to fulfil

There’s a very good short YouTube video by @UpsideDownFork  looking at the role of system volume to reduce defrosts. I talked about this with my installers – maximising volume – and we worked with this in mind.
Octopus install volumisers (not buffers) on the return precisely for this defrost reason – they spell it out – but I argued it for my increased radiator sizing too. Later, when I wanted a small radiator in a cupboard removed the plumber (who was fine with removing it) looked at me and said: ‘volume and airing cupboard’ – I kept it. It’s really useful!
Anyway, after these two subzero weeks at the end of last year and now this week just gone – I realised why my defrosts were at least two hours apart and the longest one only lasted for 16 minutes.
Ever since I switched my heat pump to ‘pure weather compensation’ – Leaving Water Temperature control in Daikin parlance – it has run like a dream. It’s been running for weeks now, without ever stopping or cycling, maintaining an inside temperature 21Âş- 22Âş (a 2Âş LWT set back at night) throughout the changing OATs.
In my Octopus/Daikin FBook group there have been numerous questions about frequent defrosts and spikes in electricity consumption (mine doesn’t do these spikes either except to a very small degree). I think the YouTube video (which gets a bit geeky 😁) explains why mine is doing so well and my defrosts are infrequent – water volume!
I was so lucky with my installers. 🙂

Toodles 12 January 2025 at 17:46

@lucia I have not attempted to tot up my volume of water but 10 radiators plus a dual fuel towel rail seem to keep the defrosts to perhaps 90 minutes apart and only 6-8 minutes in duration. I notice the first radiator in the circuit will become cool for 2-3 minutes and that’s about it really. According to the Homely Dashboard report. the whole cycle is approx 8 minutes from start to finish. (Daikin EDLA 8 kW.) Regards, Toodles.

cathodeRay 12 January 2025 at 17:46

There’s a very good short YouTube video by @UpsideDownFork  looking at the role of system volume to reduce defrosts. I talked about this with my installers – maximising volume – and we worked with this in mind.

The problem is, unless I have missed something, is he just asserts system volume ‘really helps’ with defrosts, which I take to mean it reduces duration and/or frequency. But he doesn’t explain why. And if I don’t see a why explanation, I want one! Nor does he provide any evidence, and when I see an assertion without evidence, I want to see evidence!

@jamespa will do this much better than I will, but surely the speed of frosting up, which in turn will determine defrost frequency, is a functions of how hard the heat pump is working, and ambient conditions, neither of which are directly affected by system volume. When it comes to a defrost, there does need to be enough heat stored in the house to complete the defrost, so there is a minimum system volume in an absolute sense, but the speed of the defrost is determined by how fast the heat is pumped back from the house to the heat pump, and the primary determinant ate the heat pumps operating characteristics, not the system volume.

Bottom line is once you have enough system volume, so you don’t run out of heat for the defrost, then that’s it, adding extra volume doesn’t add anything, or if it does, it only adds a small amount eg a larger system may cool slower, and therefor continue to supply warmer water for longer, and that may shorten the defrost, but only by a small amount?

I’m more asking questions here than supplying answers.



cathodeRay 12 January 2025 at 17:56

Further information: here are some defrosts from this morning, about 50 mins apart, duration 4 minutes. But the problem isn’t just the defrost, it is the slow recovery from the defrost (with the alternating pattern I’ve previously noticed). Maybe with a larger system volume (more water to reheat), the recoveries would be even slower?

JamesPa 12 January 2025 at 19:41

Hummm……larger system volume would have more energy stored in the water so the bulk average water temperature reduces less when the defrost cycle happens.  I suppose the heat pump controller would then spend less time going flat out to increase the bulk average water temperature, so that should mean less ice accumulation in the fins.  Interesting!

Bob

I too have been thinking about this, not least because the only disappointment with my heat pump is that its noisy when recovering from defrost.

I think what you say above is right.  The energy needed for defrost remains the same irrespective of the system volume, but larger system volume means that the system water temp will drop less for the same energy extracted.  This (a) means that it can start putting heat back into the house earlier and (b) means the heat pump can afford to spend a bot more time ‘catching up’, which should (i) should mean less ice accumulation in the fins and (ii) means it doesn’t have to be as noisy.

Of course the recovery algorithm will not necessarily be sophisticated enough to take advantage of this opportunity, so in practice it may well be that system volume makes little difference once it is sufficient.



Lucia 12 January 2025 at 20:19

@cathoderay
The problem is, unless I have missed something, is he just asserts system volume ‘really helps’ with defrosts, which I take to mean it reduces duration and/or frequency. But he doesn’t explain why. And if I don’t see a why explanation, I want one! Nor does he provide any evidence, and when I see an assertion without evidence, I want to see evidence!

He’s data obsessed if you follow his channel. However, he points out that minimum volumes are specified in the heat pump set up manuals – he uses the 7kw Vaillant Arotherm as his example – but he’s producing his video for new users not to prove a point. He made a film outside of the kit defrosting a few months back because some new owners get a bit stressed by it.
He also uses OpenEnergyMonitor data for his films and I think he refers to this in his defrost discussion.
Octopus state very clearly in their installs that they use the volumiser tank to aid defrosts – I have a feeling it’s a warranty condition (but not sure..).
But it fascinates me because mine seem to have minimal impact (except the high pump speed for a few minutes makes my rads hiss – I should adjust the lockshield slightly ) – while others are in almost identical conditions (pump size, OAT etc.,) yet have repeated defrosts in an hour using lots of Kwhs of energy.
Dunno… just something to chew over really. 🤷🏻‍♀️

BobTSkutter 12 January 2025 at 20:45

@lucia It would be interesting to know the volume of your system and typical flow temperature.
Bob

cathodeRay 13 January 2025 at 08:47

@lucia – absence of evidence isn’t evidence of absence (of effect) and all that but still he is in effect just making an assertion. Being obsessed with data doesn’t mean the data is right, as I know you know only too well.

I don’t for a moment doubt there is a minimum system volume required, normally available in the installation manual, but as @jamespa has said, once you have that volume, how much real world benefit do you get from adding more volume? My gut feeling, which of course is not evidence, is that the law of diminishing returns applies.

What would certainly be very interesting is to look at why you have minimal defrosts while others have significant defrosts. To do this you would need to find someone with a similar heat pump (brand/size) and then look at defrost behaviour and system volume for both systems. It would be very worthwhile doing this. We have a lot of people here on the forum, most of whom say what heat pump they have, and many very willingly post their data either spontaneously or on request. Now is a good time to look, while the pain of defrosts is still sharp in people’s minds!

Judith 13 January 2025 at 09:15

Our system is open no hydraulic separation. The volume is high (18 Large K2 and can’t be bothered to add it up) but the installer still added a 26L in series volumiser. I had stopped quibbling over the details by then but way more than the minimum volume needed.
The result is a COP of 3 on these cold days, and between defrost times of ~40minutes. In warmer weather and low load the on time is ~40minutes and the mark space ratios are ~60-40. Adding more additional volume impacts the low load case most.
in defrost situations it is worst when working hardest to reach the highest LWT (you canna break the laws of physics Jim) so highest system volumes mean the larger radiators (nothing to do with volumisers) run at lower design temperatures.
So a LWT design of 55C will defrost much more than one with a design of 42C for the same outside temperature.
I posted the images of the two very different cases here https://renewableheatinghub.co.uk/forums/postid/39947

samiebon1 14 January 2025 at 11:03

Coat tailing on this thread. I’m having a 5kW Vaillant put in and our house is only 3 bed (for idea of size). The installer has said two pumps on the heating system may be needed. It doesn’t sound right to me but any help appreciated!

JamesPa 14 January 2025 at 11:43

Coat tailing on this thread. I’m having a 5kW Vaillant put in and our house is only 3 bed (for idea of size). The installer has said two pumps on the heating system may be needed. It doesn’t sound right to me but any help appreciated!

It’s unlikely you need 2 pumps, did he say why?



samiebon1 14 January 2025 at 11:55

@jamespa I think because they usually put buffers in and i’ve specified no buffers.

JamesPa 14 January 2025 at 13:26

@jamespa I think because they usually put buffers in and i’ve specified no buffers.

Well that’s not really a reason.

If he had said “because the index circuit has a resistance that is too high for the water pump" that would be a reason.

Is there any reason to suspect the resistance in your system will be high like small diameter, circuitous or extra long pipework?



samiebon1 14 January 2025 at 13:59

I think i’ll ak him about the index circuit. My own concern is the amount of 90deg elbows in my system!

JamesPa 14 January 2025 at 16:55

I think i’ll ak him about the index circuit. My own concern is the amount of 90deg elbows in my system!

Maybe best not to sound too clever, it might upset him.  You might be better first to ask why he thinks you might need 2 pumps and then, if necessary, ask a follow up eg how he is going to ensure a second pump is fitted if and only if its actually needed.

Personally I doubt many plumbers calculate the index circuit not least because it’s often not visible.  I’m sure many if not most just assume the pump will be good enough which, in reality, it usually will.

Of course putting in loads of 90 degree elbows isn’t best practice!



Mars 15 February 2025 at 14:05

For those that having the thread, here’s the latest video from our podcast series on buffer tanks:

Tim441 17 February 2025 at 13:01

I wonder how much efficiency it really costs – if there is unnecessary mixing it results in higher return temps so a “saving" on the next heating. Clearly there will be some heat & efficiency loss but perhaps not quite such a big problem?
I suspect in most cases it will not be worthwhile removing an existing buffer tank.
But on any future installation I would definitely question necessity if proposed as part of installation.


JamesPa 17 February 2025 at 13:16

I wonder how much efficiency it really costs – if there is unnecessary mixing it results in higher return temps so a “saving" on the next heating. Clearly there will be some heat & efficiency loss but perhaps not quite such a big problem?

I suspect in most cases it will not be worthwhile removing an existing buffer tank.

But on any future installation I would definitely question necessity if proposed as part of installation.



15% or more typically

The problem is not loss of energy (which as you say is small) its reduction in flow temperature to the emitters (due to the mixing) which means that the heat pump must be operated at a higher flow temperature than would otherwise be the case.



Toodles 17 February 2025 at 13:33

@jamespa There again, I have my secondary pump set to match the average flow rate from the heat pump system; this is 15 lpm. When the pump speeds up (as it does periodically) to as much as 30 lpm for a short time, my secondary pump connected to the output of the LLH does not change. Efficiency loss? Regards, Toodles.

Tim441 17 February 2025 at 13:48

I doubt I could get my weather compensation curve any lower so must conclude my buffer is not hurting me tooooo much. Certainly accept the main point that buffer tanks are likely unnecessary.
My settings:
Leaving Water temp 30/45
Outside temp -4/15
Currently outside temp 6 deg. LWT 36 deg. Indoor temp 21 deg


JamesPa 17 February 2025 at 13:56

@tim441 if you want to you can work out roughly how much it’s costing by measuring the temperature drop across the buffer flow to flow.  The cost is roughly 2-3 percent per C (more according to some, but I think the argument for more depends on deltaT flow to return being higher (than the typical 5C) on the emitter size.

It’s entirely possible to set up buffer tanks not to mix, but unfortunately most installers appear not to do so, or fit a buffer tank that is to small to stratify.  Of course some do,  @toodles has for some while reported a buffer tank that doesn’t mix to any great extent.

The real point is that they shouldn’t be fitted in the first place because they are, in almost all cases, superfluous.  Obviously once they are there it’s a different calculation.

Tim441 17 February 2025 at 14:07

@jamespa measuring with clamp-on heating pipe thermometer? I see ebay/amazon has them around ÂŁ6 or ÂŁ7 .. Good enough?

JamesPa 17 February 2025 at 14:15

@jamespa measuring with clamp-on heating pipe thermometer? I see ebay/amazon has them around ÂŁ6 or ÂŁ7 .. Good enough?

I believe so, we are looking for difference so as long as you can clamp consistently then it doesn’t matter if the figure isn’t perfect.

I stress there is absolutely no need to do this unless you want to.



Tim441 20 February 2025 at 14:32

Borrowed a clamp on thermometer.
Buffer tank:  PAW-BTANK50L-2 buffer tankOnly 48lAccording to ashp controlsleaving temp 33degReturn 31 degArr from ashp BT 34.4flow Leave BT 34.1 flowArr from house BT 33.2 returnLeave 33.8 BT return
I suspect not great test right now… as mild… so not working hardWill be better to check on cold morning.. perhaps.
Will report again once more results

Mars 20 February 2025 at 21:59

@tim441 the other thing to “check” is where the respective flow and returns are to see if your buffer has minimal distortion. Ideally, it’s plumbed like this:

buffer
Tim441 21 February 2025 at 08:32

@editor
Logically the electronic motorised valve.. I think… stops buffer being used when heating DHW/hot water tank. So will be on flow to BT?
With the pump on right on flow from BT?
Tap at bottom right … return to BT?
So same as your diagram. but I’ll try the thermometer a few times in different scenarios

20250220 135539



JamesPa 21 February 2025 at 08:53

Logically the electronic motorised valve.. I think… stops buffer being used when heating DHW/hot water tank. So will be on flow to BT?

Is it a 2 way valve or a 3 way diverter valve.  Normally the (3 way) diverter valve is the only motorised valve needed.

As you say taking some temperature measurements when its working harder would be good, but your initial ones are encouraging.

Tim441 21 February 2025 at 09:00

@jamespa it’s 3 way

JamesPa 21 February 2025 at 09:02

@jamespa it’s 3 way

I presume the diverter valve then, which would make sense.  As you say you would expect this to be on the inlet to the BT



Potatoman 28 April 2025 at 20:56

Hi, so if I wanted to make my system more efficient, It’s open loop 28/22/15mm ,all rads,run via a Homely is it possible to remove the buffer tank but still comply with 7-year LG warranty requiring hydraulic separation. Thanks

Mars 29 March 2025 at 22:32

@potatoman can you share LG’s official documentation that explicitly requires hydraulic separation to maintain the 7-year warranty?

If you’ve got that document, it would be extremely valuable to see it.

Potatoman 30 March 2025 at 11:09

@editor

487221638 10163211903663552 6665514382284125271 n

Regards

ASHP-BOBBA 30 March 2025 at 18:47

@potatoman Hi Potato, just contact LG and ask them, they will confirm if it will effect the warranty or not, in my experience the whole buffer no buffer thing comes from manufacturers designing them in on their schematics, if you look in most installation manuals they have them drawn in on most designs. I think there is an element of safety for the manufacturer to design them in as then all the manufacturer needs to worry about for their warranty is the buffer and minimum volume / flow is correct and is available, nothing much the house design side can then cause damage to the ASHP.
In my view check with them and don’t void the warranty on this brand as they are known for compressors and evaporator fan issues, good news is if there are any issues with the actual ASHP an LG engineer will attend to fit the parts under warranty.



Potatoman 30 March 2025 at 19:32

@ashp-bobba Thank you for some good advice, I will ring tomorrow.

JamesPa 30 March 2025 at 14:14

To me that reads as ‘Hydraulic separation optional but if present covered for 7 years if you take out the extended warranty’, as opposed to ‘Hydraulic separation mandatory’.  The very last line in the table (mag filter) would seem to confirm this.

Mars 30 March 2025 at 21:19

@bobbt9866, can you please give us some insights on the 7 year warranty being connected to an LG heat pump requiring some form of hydraulic separation?

JamesPa 30 March 2025 at 21:37

in my experience the whole buffer no buffer thing comes from manufacturers designing them in on their schematics,

I have the same impression.  They sometimes design other things in too and don’t make it clear whether its because they are needed or just illustrative to show how a system could work and where to put component X if it is included.  It seems to me that its convenient for installers who want to put buffers in not to know which!

Mars 30 March 2025 at 21:51

Hi Potato, just contact LG and ask them, they will confirm if it will effect the warranty or not,

I would love to hear the outcome of this phone call. If they’re anything like Samsung, good luck!

Mars 31 March 2025 at 17:15

@potatoman Bob (who I refer to as Mr. LG) sent me some docs (which I’ve attached) along with the following explanation: “The 7 -year warranty is not given to everyone, but the documents drawn up by LG show buffer vessels as being installed and accepted. The warranty only applies to the units themselves and not the installation of which the buffer vessel is part. So, they would not specifically refer to it in warranty paperwork."

The attached docs could prove useful.

Toodles 31 March 2025 at 17:34

@editor Perhaps I may be a sceptic but… It rather suggests to me that they mean the buffer tank and its’ installation is not covered by the warranty. That is a different kettle of fish with regards to whether the buffer tank is a required component to comply with the warranty requirements I think? Regards, Toodles.

Potatoman 1 April 2025 at 20:25

@editor Thanks for the information, I had an interesting phone call with Unitherm Heating Systems today, they seem involved with the verification process of the LG 7-year warranty process, for my installer at least. They said, to get the 7-year warranty the installer has to undergo extra LG training and among other things submit photograph evidence of hydraulic separation, either a buffer tank or a volumiser and a LLH. This information has to be sent to Unitherm Heating Systems via the installer, once they have vetted the information it is sent to LG and then if all is correct a 7-year certificate is issued from LG to the homeowner.
I did ask about removing the buffer after I received the 7-year certificate, and they firmly said if there was a problem with the heat pump and the installer found you had removed the buffer tank, regardless of what the problem was on the heat pump there would be no warranty as the buffer tank “protects " the heat pump in numerous ways.
So unfortunately It’s going to be no buffer tank for me, I just hope other manufactures are more accommodating, but also people who recommend the removal of the buffer tank on efficiency savings that can be made should also urge caution and get people to check their warranty conditions first .


Judith 1 April 2025 at 22:00


@editor Thanks for the information, I had an interesting phone call with Unitherm Heating Systems today, they seem involved with the verification process of the LG 7-year warranty process, for my installer at least. They said, to get the 7-year warranty the installer has to undergo extra LG training and among other things submit photograph evidence of hydraulic separation, either a buffer tank or a volumiser and a LLH. This information has to be sent to Unitherm Heating Systems via the installer, once they have vetted the information it is sent to LG and then if all is correct a 7-year certificate is issued from LG to the homeowner.
I did ask about removing the buffer after I received the 7-year certificate, and they firmly said if there was a problem with the heat pump and the installer found you had removed the buffer tank, regardless of what the problem was on the heat pump there would be no warranty as the buffer tank “protects " the heat pump in numerous ways.


they do allow a volumiser to be used, so the obvious question is could a 4 port buffer be configured as a volumiser and stay in warranty?


JamesPa 1 April 2025 at 20:42

people who recommend the removal of the buffer tank on efficiency savings that can be made should also urge caution and get people to check their warranty conditions first .

Agreed

However if the above is the official lg position it’s a good argument in future to avoid lg, which is disappointing.  I wonder if their quoted performance takes into account a typical buffer tank as installed.  Oh, wait a minute, I think I can guess.

Potatoman 1 April 2025 at 21:00

@jamespa surely there must be a third way to improve efficiency, not just buffer or no buffer, but to balance a buffer, especially if you are using an open loop system.

Mars 1 April 2025 at 21:07

@potatoman there’s also the option of a three port buffer, which limits distortion. Still considered hydraulic separation.

3 pipe buffer
Potatoman 1 April 2025 at 22:01

@editor That’s an interesting idea, I am not sure how they work, do you have any more details on them

Mars 1 April 2025 at 22:20
buffer

@potatoman as you already know a four-port buffer can cause heat pump inefficiencies due to uncontrolled blending of hot and cooler water, which reduces the supply temperature and forces the heat pump to work harder.

3 pipe buffer

In contrast, a three-port buffer helps maintain stratification, reduces unnecessary mixing and ensures that the heat pump isn’t cycling. This improves efficiency and keeps return temperatures lower.

volumiser

A volumiser, while not technically a hydraulic separator, can also satisfy most manufacturers’ minimum volume requirements. Its primary role is to provide thermal mass to prevent short cycling, but because it’s integrated more seamlessly into the system than a four-port buffer, it avoids distortion issues.

Ultimately, both the three-port buffer and the volumiser offer better solutions than a standard four-port buffer by reducing mixing, maintaining flow rates and ensuring the heat pump operates within its optimal parameters.

Potatoman 2 April 2025 at 19:11

@editor Thank you for the information,do you have any information or a link of how to pipe up a 3 port buffer

Mars 4 April 2025 at 08:25

@editor Thank you for the information,do you have any information or a link of how to pipe up a 3 port buffer

@heacol do you have any info to assist potatoman with this?



Heatgeek 2 May 2025 at 09:55

@potatoman As no one seems to be obliging, I attach a diagram. The idea is that only bypass flow goes through the tank when necessary so it is undisturbed by main flow. Connection to tank must be closely coupled.


3 Port Buffer Tank
ASHP-BOBBA 2 May 2025 at 10:02

@heatgeek is it that this design satisfies the manufacturers? its still (although balance by bypass) a double hydronic volumiser/buffer with 2 pumps

Heatgeek 2 May 2025 at 10:14

@ashp-bobba  I am afraid that you are talking to the wrong person about manufacturers preferences. However, as far as I can see, it functions the same as a 4 port buffer except that flow doesn’t go through the top of the tank causing mixing, therefore I would have thought that it is a perfectly acceptable alternative to a 4-port.

ASHP-BOBBA 2 May 2025 at 10:57

@heatgeek Oh agreed, its a slightly better and slightly less resistive solution, perhaps even the middle ground of no buffer V buffer.

Potatoman 2 May 2025 at 12:53

@heatgeek Thank-you for your reply, can you clarify the circulating pump situation, would you have to have 3 circulating pumps in operation, one in the heat pump and two in the design. Thanks


ASHP-BOBBA 2 May 2025 at 12:59

@potatoman hi, the scheme detailed is 2 pumps, one for the ASHP (primary) and 1 for the secondary circuits.



Heatgeek 2 May 2025 at 13:04

@potatoman  No, the installation is exactly the same as a 4 port buffer with primary and secondary pumps except that the output flow bypasses the top of tank so as not to disturb the stratification of the tank. This removes some of the inefficiency problems associated with 4 port buffer tanks, like output temperature being reduced by mixing.

JamesPa 1 April 2025 at 22:57

@jamespa surely there must be a third way to improve efficiency, not just buffer or no buffer, but to balance a buffer, especially if you are using an open loop system.

Yes there is, provided the buffer is tall and well designed so there is stratification (forget 50l buffers so commonly fitted)

With one of these you have two temperature sensors and then you can detect where the thermocline (the division between cold water at the bottom and hot at the top) is.  This information can be used to switch the secondary pump on or off to ensure its always in the middle section.

Alternatively you can attempt to do it ‘open loop’ by adjusting the pumps either side to run at the same speed.  This only works fully with heat pumps that don’t modulate the water pump speed to keep deltaT constant, unless they can modulate both water pumps, and with no valves that can switch on and off on the secondary side.  Effectively you are adjusting the pumps to operate as if the buffer tank weren’t present at all (underlining the fact that it is unnecessary!).

You can also adjust the secondary pump to be slightly slower than the primary, ensuring the thermocline is at the bottom and thus the flow to the emitters is at the same temp as the flow from the HP.

Any of these are likely to be better than doing nothing.



they do allow a volumiser to be used, so the obvious question is could a 4 port buffer be configured as a volumiser and stay in warranty?



if that is the case then re-configuring it as a volumiser is the best thing to do.  The answer to the question ‘can this be done?’ is yes.



JamesPa 24 April 2025 at 08:07

Thats a brilliant result and you must be pleased you persisted with fighting this.  Its also a good example of what I am beginning to suspect (but cant prove) namely that there is in fact absolutely nothing complicated or mysterious about getting ASHP installs to operate cost effectively for the vast majority of houses, it just needs to be simple (no buffer/LLH/PHE), right-sized, operated correctly and designed to work at a reasonably low flow temperature, none of which is particularly difficult and certainly none of which is mysterious.  I am expecting the ‘industry’ to tell me I’m smoking the wrong dope!

I’m actually a little surprised that the switch from the 7kW to the 5kW made a significant difference as, elsewhere, I have heard people comment that their oversized Vaillants cope well.  But its an important learning and makes Mitsubishi’s latest 2-compressor approach (2+6kW in the same casing) even more worth watching.

Regarding running cost, it occurred to me only a couple of days ago how odd it is that many people cheerfully spend 10-20K upgrading their bathroom or kitchen with absolute no financial benefit and little benefit in utility, but the same people then question the payback period for swapping a gas boiler for an ASHP which, done properly, massively increases comfort and is a vital step to combat climate change.  Strange things human beings!

FWIW I can now say with some confidence that my ASHP (right sized, simple system, running at FT42 @ -2) is costing ~20% less to run than my gas boiler compared like for like, and the house is much more comfortable.  Like you I didn’t do it for financial reasons, but of course its nice to have.

Thanks for reporting back, its always good to hear a success story and also that suppliers are recognising that oversized ASHPs with buffers just need to be fixed.



Judith 24 April 2025 at 09:50

@fillib what a wonderful result, both for you personally and to prove the case that the recipe for good efficiency is right-sized ashp and volumiser and never llh. Having the results to show the difference is great too!

SUNandAIR 28 April 2025 at 15:24


Assuming 75% boiler efficiency, head demand of 6000kWh per year and a SCOP of 4 (also assuming 0.309 kg CO2 per kWh electricity, and 0.185 kg CO2 per kWh gas), I calculate, we now save around 1000 kg CO2 per year!Even at our worst SCOP with the previous ASHP unit, we still saved around 700 kg CO2 emissions per year.

This is very impressive. I would not have expected the cop to increase to the extent of your graph as the ambient readings had dropped between esp between 10c and 3c…. Great result.
Further there’s another story,   even if only for the environmental impact.
Your numbers potentially suggest that oversizing should be eliminated at all costs. With an estimated reduction of carbon emissions of upwards of 30%. Just by sizing correctly.
Thanks for a great post.

Spreadsheet with calculations (cost and CO2 emissions) attached.

Heat Pump cost use estimates.xlsx




JamesPa 28 April 2025 at 17:31

@fillib  It would be very interesting indeed to determine your actual house loss by plotting ASHP heat delivered vs OAT (eg on a daily basis).  I looked in the spreadsheet but couldn’t find the figures needed to do this.

The reason this would be interesting is to understand how oversized the 7kW model was.  Based on 10MWh/yr gas consumption I would estimate your house loss to be 3.5-4kW, so perhaps as much as a factor of 2 oversized (more if your boiler is very inefficient) given that the 7kW model can actually do 8kW at typical FT and design OAT.  I have heard others say that the Vaillant machines are reasonably good at coping with oversizing, but maybe not by a factor of 2!  This plot from a John Cantor video illustrates the problem that heat pump designers have to grapple with:



Screenshot 2025 04 28 173013

It occurs to me that the fact that the heat pump was oversized may possibly have reduced the negative effect of the buffer.  My understanding is that, by default, Vaillant heat pumps run mostly at fixed water pump speed which is adjusted at commissioning time (by the heat pump controller) according to the heat pump capacity.  So yours will likely be running to achieve DT of ~5 at 7kW, but as your peak load is half this your DT will likely be in the 2-3 range even at peak load or less at a more normal load.  This will reduce the temperature loss across the buffer due to mixing, thereby reducing its negative effect on COP.  All of course assuming (amongst other things) that the Vaillant water pump does what it appears to do on my machine and what some others have said it does.

iantelescope 29 April 2025 at 11:04

For me, the Questions are here:
1) Does a Volumiser tank needlessly consume more energy?
2) Does a Volumiser tank reduce wear by reducing cycling?
3) Does the COP vary with Water Flow rate?

To answer these questions I have recorded the performance of my heat pump when altering :
a) The primary water volume by switching in/out a 50 litre volumizer tank.
b) Altering the Water flow rates by applying  a variable Pulse width Modulated , PWM Signal , to the primary  Heat Pump inputs to  my Heat Exchanger.
c) Altering the Water flow rates by applying  a variable Pulse width Modulated , PWM Signal , to the secondary output from my Heat exchanger.

The Effects of altering the water volume, Primary and Secondary Heat Exchanger Water flow rate are shown in the following Cross Correlation graphs

A) ENERGY LOSS AND VOLUMIZER

BUFFERXREAL

The COP and the REAL_COP are shown to be Negatively Correlated with the use of the VOLUMIZER.
This implies that apply the buffer REDUCES BOTH the COP and the REAL COP.
This further implies that the VOLUMIZER wastes energy.

B) COP versus HEAT PUMP WATER FLOW RATE ( PWM)

REALCOPXPWMRADIATOR

  The COP is here shown to be Positively Correlated with the RADIATOR WATER FLOW RATE.
  This implies that increasing the Radiator PWM , hence, Reducing the Radiator Flow rate INCREASES the COP .

C) REAL_COP versus RADIATOR WATER FLOW RATE (PWM)

REALCOPXPWMRADIATOR

  The REAL_COP is here shown to be NEGATIVELY Correlated with the HEAT PUMP OUTPUT WATER FLOW RATE.
  This implies that increasing the HEAT PUMP PWM , Reducing the HEAT PUMP  Flow rate,  REDUCES  the REAL_COP .

D) CYCLE AND RUN TIME Versus   USE OF Volumizer TANK.

BUFFXCYCLERUN

  The Cycle Time is POSITIVELY Correlated with use of the Volumiser tank.
  Using a Volumizing tank INCREASES the   CYCLE TIME.
  The RUN TIME is NEGATIVELY Correlated with the use of a Volumizing tank.
  Using a Volumizing tank REDUCES the   RUN TIME.

  CONCLUSIONS:
  1) A Volumizing tank increases energy loss.
  2) A Volumising tank Increases CYCLE TIME and REDUCES Wear and tear.
  3) Reducing the HEAT PUMP WATER FLOW RATE , Increasing the HEAT PUMP MOTOR PWM ,  Reduces the REAL_COP.
   4) Reducing the Radiator WATER FLOW RATE , Increasing the Radiator MOTOR PWM ,  Increases the REAL_COP.

   By Experiment my Heat Pump PWM is now set to 192 ms ( ~14 lpm)  while my Radiator PWM is now set to 86 ms ( ~7 lpm) .







cathodeRay 30 April 2025 at 19:05

@iantelescope – I do appreciate I am becoming something of a harridan on your shoulder, but once again these graphs are impossible to interpret as posted, and even if I could make sense of them, the use of ‘cross correlation’ or even plain common or garden correlation to prove something is problematic because of the effects of uncontrolled variables.

On a positive note, you do state your research questions at the outset. But these questions are very difficult to answer in the real world. Take the first question: does a system with a volumiser use more energy than one without a volumiser? You can certainly make observations of both running states, and compare them, but the problem invariably is that the other variables don’t stay constant. Imagine, for example, that the volumiser days happened more often to be cold days, with higher energy use and lower COPs, while the no volumiser days were warmer, with lower energy use and better COPs. In this entirely plausible example, you might conclude the volumiser uses more energy and impairs efficiency, when in fact the real explanation for what you observe is the differing OATs. To deal with this, you have to collect OAT data as well, and compare like with like, ie with/without volumiser on cold days, ditto for warm days etc etc. Even then, other factors can bias your results.

In many ways the underlying question here is the same as my setback vs no setback question: does changing a system running state affect energy use, where the change is a binary one, something is either on (with setback, with volumiser) or off (no setback, no volumiser). You could start by doing something similar to what I do: plot daily energy use against mean daily OAT for two series, in your case one with volumiser, one without, on the same chart. Here is a plot I did for setbacks in R, but the same thing can also be done in any spreadsheet. If you then see (as I did on this chart) what appears to be two samples from different populations (ie there appears to be a difference) then you can start asking whether it is real or not.

Rplot04
Mars 2 May 2025 at 08:38

In light of the recent buffer tank/warranty comments in this topic, I’ve written this piece below. It’s a 10 minute read, but I think it warrants a dedicated video/podcast, because there’s a lot of ambiguity and grey areas here that need clarification.

https://renewableheatinghub.co.uk/fact-or-fiction-are-buffer-tanks-really-necessary-to-protect-your-heat-pump-warranty/

Heatgeek 2 May 2025 at 13:35

Note a key point here though. The primary pump is connected in the return pipe while the secondary pump is connected in the flow pipe after the buffer tank to provide good hydronic separation between the primary and secondary pumps.

JamesPa 2 May 2025 at 14:56

Note a key point here though. The primary pump is connected in the return pipe while the secondary pump is connected in the flow pipe after the buffer tank to provide good hydronic separation between the primary and secondary pumps.

That all sounds very believable.  Presumably mixing of return water with flow water to the emitters (and thus a reduction of ft to emitters) will however still occur if the primary pump throughput is less than the secondary, so the requirement to set up properly remains albeit that it is less sensitive than a 4 port.



Heatgeek 2 May 2025 at 13:48

Only the difference in flow between the heat pump and the emitters passes through the tank. This lower flow helps to preserve the stratification of the tank so that dilution of temperature to the emitters is minimised.

Heatgeek 2 May 2025 at 13:59

Apologies. Poor choice of words. Delete “dilution of temperature to emitters is minimised".

Heatgeek 3 May 2025 at 10:06


Presumably mixing of return water with flow water to the emitters (and thus a reduction of ft to emitters) will however still occur if the primary pump throughput is less than the secondary,

This could be mitigated by putting a one way check valve on the top input so that flow is only downwards. Can’t think of any detrimental effects.

JamesPa 3 May 2025 at 13:08

This could be mitigated by putting a one way check valve on the top input so that flow is only downwards. Can’t think of any detrimental effects

Or of course not having a buffer at all!

Would an installer that wants to fit a buffer unnecessarily because ‘thats what we do’ or because of warranty reasons be prepared to fit a three way buffer with a one way check valve.  I suspect this would be a tiny minority!

It’s ab interesting thought experiment though.

SUNandAIR 3 May 2025 at 14:41






@heatgeek I kind of get it… but aren’t you still in the same situation of having excess flow temp water at the bypass entering the buffer at circa 23 LPM.
In so doing, raising the return temp and narrowing the DT… ergo prompting a raising of the flow temp and inducing the cycling.?
Only now there are 2 pumps?
(It isn’t like it’s just trickling into the buffer, is it? And the return pump will want to maintain the flow rate, for sure!)
Also on 4 port systems I’m not convinced that PWM pumps can cope with matching actual water flow rates, at variable speeds on either side of the hydronic circuits – since there is already believed to be a compromise or resistance to flow on the emitter side. Yet that’s possibly the very reason why buffers are being proposed.
Is there a proper definition as to why buffer tanks are being specified and what exact problem is expected to be overcome?




Johnmo 4 May 2025 at 14:47


buffer tanks are being specified

A buffer is a legacy issue, they were never used on gas boiler systems, but generally specified when fixed output heat pump came along. So unlike today’s heat pump which modulates they had a fixed kW output and generally a fixed flow temp. Add to this a UK liking for zones, the heat pump didn’t stand a chance of running well without one.
Today people are still obsessed with zones – so it’s the easy choice for manufacturers and installers to add one. Plus more product to install and sell, more profit.

SUNandAIR 5 May 2025 at 10:38

@johnmo yes I can believe that. It seems to be human nature to keep dong what we did before.

Mars 2 September 2025 at 15:05

I’m really pleased to see that we’re starting to have a positive impact on homeowners who are getting smart about their systems. I received this email today from a homeowner, and based on our content they’ve declined an installer who was hell bent on fitting a buffer tank.

Here’s what they wrote:

“I’ve been watching your videos on YouTube, I have learnt so much!

We are moving house in the next couple of months and have an ideal opportunity to install a new heating system from scratch.

I have had a site visit and quote from an installer but they are telling me I will need a buffer in the system. When questioned why they replied:

‘Your research seems very very high! We fit systems with buffers or a low loss header, never without either. The reason is because to keep a heat pump running efficiently, we need a higher flow rate than most heating systems require, so the heat pump satisfies the buffer and the buffer satisfies the space heating system. This stops the heat pump short cycling, short cycling is bad for efficiency and the life expectancy of the heat pump compressor will be compromised.'"

This kind of explanation should set off alarm bells for consumers everywhere. If the default answer from an installer is “we never fit a system without a buffer or LLH,” it usually means they’re designing to their own convenience (or they’re just incompetent) rather than what’s best for the homeowner.

It’s fantastic to see homeowners pushing back and questioning these decisions!

JamesPa 2 September 2025 at 21:45

‘We fit systems with buffers or a low loss header, never without either.

@mars That response surely deserves a nomination for Turkey of The Year, for the company itself not for the specific installation.  It shows a company which either consistently does the wrong thing, or lies to its customers.  Either way it doesn’t deserve to be in business unless it changes radically.

Leave a Comment

Click to access the login or register cheese
x  Powerful Protection for WordPress, from Shield Security
This Site Is Protected By
ShieldPRO
