[Sticky] Solar Power Output – Let’s Compare Generation Figures

131 Posts
23 Users
77 Reactions
15.9 K Views
Transparent
(@transparent)
Illustrious Member Moderator
13410 kWhs
Joined: 3 years ago
Posts: 2345


When looking ahead over a decade, one needs to be sure that the battery doesn't depend on monitoring, signals or commands from proprietary external services.

If any management operations rely on a 'server' belonging to the supplier, then they needing checking at the outset.
The loss of communications with a remote server should still allow the battery to continue operating, albeit with some possible loss of features.

Both NESO and DESNZ are pursuing strategies which are reliant on external commands as part of the 'future grid'.

I'm not against having 'smart operation' for home-based energy products, but I think

  • the smart features should be integral to the device, not imposed by external commands
  • autonomous operation in response to data from the local area grid is a better match for the pattern of distributed generation we are moving to
  • smartness should be based on more than just price



The question to those with Powerwalls and Tesla EVs must be "what functionality remains if Tesla's data network fails?"

Save energy... recycle electrons!



ReplyQuote
JulianC
(@julianc)
Noble Member Member
1175 kWhs
Joined: 4 years ago
Posts: 317


We generated 410kWh in March from a 4kW system installed in 2012. So paid £315 or so. Sweet

Daikin Altherma 3H HT 12kWh ASHP with Mixergy h/w cylinder; 4kW solar PV with Solic 200 electric diverter; Honda e and new Hyundai Ioniq 5 N electric vehicles with Myenergi Zappi mk1 charger



ReplyQuote
Majordennisbloodnok
(@majordennisbloodnok)
Noble Member Moderator
7532 kWhs
contributor
Joined: 3 years ago
Posts: 774


Posted by: @transparent

When looking ahead over a decade, one needs to be sure that the battery doesn't depend on monitoring, signals or commands from proprietary external services.

If any management operations rely on a 'server' belonging to the supplier, then they needing checking at the outset.
The loss of communications with a remote server should still allow the battery to continue operating, albeit with some possible loss of features.

Both NESO and DESNZ are pursuing strategies which are reliant on external commands as part of the 'future grid'.

I'm not against having 'smart operation' for home-based energy products, but I think

  • the smart features should be integral to the device, not imposed by external commands
  • autonomous operation in response to data from the local area grid is a better match for the pattern of distributed generation we are moving to
  • smartness should be based on more than just price



The question to those with Powerwalls and Tesla EVs must be "what functionality remains if Tesla's data network fails?"

To be frank, I don't know of any inverters/batteries that don't have a physical console to offer the ability to change settings, so I suspect pretty much any system bought would be able to continue doing its stuff ad infinitum if, for instance, the householder's Internet line became unavailable.

That said, I'm pretty sure the average householder would find a regime of button-prodding (possibly outside in the cold rain) whilst squinting at a small LCD screen in torchlight rather too much of a faff to put up with. Since I have experienced plenty of hugely underwhelming functionality from under-performing and badly designed apps for controlling some of my kit, I can attest to the sigh of relief when I was able to connect to my inverter by a local connection and use that to manage everything. As a result, whilst I have no problem with people making use of the apps supplied I strongly agree that any kit someone buys should have at very least a port available for providing a local connection (usually RS485 for modbus) so the householder has a modicum of choice and, therefore, control.



105 m2 bungalow in South East England
Mitsubishi Ecodan 8.5 kW air source heat pump
18 x 360W solar panels
1 x 6 kW GroWatt battery and SPH5000 inverter
1 x Myenergi Zappi
1 x VW ID3
Raised beds for home-grown veg and chickens for eggs

"Semper in excretia; suus solum profundum variat"



ReplyQuote
Transparent
(@transparent)
Illustrious Member Moderator
13410 kWhs
Joined: 3 years ago
Posts: 2345


Posted by: @majordennisbloodnok

To be frank, I don't know of any inverters/batteries that don't have a physical console to offer the ability to change settings,

PowerVault.

Install8bSm400

Save energy... recycle electrons!



ReplyQuote
Majordennisbloodnok
(@majordennisbloodnok)
Noble Member Moderator
7532 kWhs
contributor
Joined: 3 years ago
Posts: 774


Wow! Seriously no buttons anywhere?

105 m2 bungalow in South East England
Mitsubishi Ecodan 8.5 kW air source heat pump
18 x 360W solar panels
1 x 6 kW GroWatt battery and SPH5000 inverter
1 x Myenergi Zappi
1 x VW ID3
Raised beds for home-grown veg and chickens for eggs

"Semper in excretia; suus solum profundum variat"



ReplyQuote
Transparent
(@transparent)
Illustrious Member Moderator
13410 kWhs
Joined: 3 years ago
Posts: 2345


PowerVault solar/battery units require a constantly 'live' internet link.
If you lose the link, then you're blind.

Their data is in the cloud and visible about 3-mins later via a web-page.

That's where you can monitor what's happening and have a small amount of control over schedules.

But you cannot, for example alter the balance of how much solar generation is stored and how much exported to the grid.
The only option is for it to first fill the battery and then export (but only up to the permitted current of course).

So you can have afternoons where the battery is now full, and all generation above 3.68kW is discarded.

DiscardLosses15junB SnCr



PowerVault are not the only company which offers a 100% Managed Service.

But I don't have first-hand experience of using the others, so I'm loathe to mention them by name.

This post was modified 1 day ago by Transparent

Save energy... recycle electrons!



ReplyQuote



Mars
 Mars
(@editor)
Illustrious Member Admin
27479 kWhs
Joined: 4 years ago
Posts: 3078
Topic starter

Looks like our March numbers are echoing what the MET office has had to say:

https://www.metoffice.gov.uk/about-us/news-and-media/media-centre/weather-and-climate-news/2025/a-record-breaking-march-for-sunshine

Buy Bodge Buster – Homeowner Air Source Heat Pump Installation Guide: https://amzn.to/3NVndlU
From Zero to Heat Pump Hero: https://amzn.to/4bWkPFb

Subscribe and follow our Homeowners’ Q&A heat pump podcast



ReplyQuote
Majordennisbloodnok
(@majordennisbloodnok)
Noble Member Moderator
7532 kWhs
contributor
Joined: 3 years ago
Posts: 774


Posted by: @transparent

PowerVault solar/battery units require a constantly 'live' internet link.
If you lose the link, then you're blind.

Their data is in the cloud and visible about 3-mins later via a web-page.

That's where you can monitor what's happening and have a small amount of control over schedules.

But you cannot, for example alter the balance of how much solar generation is stored and how much exported to the grid.
The only option is for it to first fill the battery and then export (but only up to the permitted current of course).

So you can have afternoons where the battery is now full, and all generation above 3.68kW is discarded.

DiscardLosses15junB SnCr



PowerVault are not the only company which offers a 100% Managed Service.

But I don't have first-hand experience of using the others, so I'm loathe to mention them by name.

I find that sobering and not in a good way.

When we first got our Growatt inverter and battery, I was loath to experiment with telling it to charge the battery from grid since, if my Internet line went down my app wouldn't be able to tell the inverter to revert to its "load first" mode and I didn't understand the physical controls well enough. But at least even then I still had those physical controls so I wouldn't be stuck until kingdom come having to charge the battery at whatever was the going rate. I see that fallback as absolutely essential; indeed I want to have a plan B in most aspects of my life.



105 m2 bungalow in South East England
Mitsubishi Ecodan 8.5 kW air source heat pump
18 x 360W solar panels
1 x 6 kW GroWatt battery and SPH5000 inverter
1 x Myenergi Zappi
1 x VW ID3
Raised beds for home-grown veg and chickens for eggs

"Semper in excretia; suus solum profundum variat"



ReplyQuote
Toodles
(@toodles)
Famed Member Contributor
11675 kWhs
contributor
Joined: 3 years ago
Posts: 1877


@majordennisbloodnok Yeap, worry or not, the battery life may or may not last 8, 10, 12 or more years - who knows? I am just signing up for Octopus Intelligent Flux, so my battery is going to be more heavily exercised than it has in the past - I hope that almost doubling the returns on export in the summer months will make it worthwhile! Toodles.

Toodles, he heats his home with cold draughts and cooks his food with magnets.



👍
1
ReplyQuote
Transparent
(@transparent)
Illustrious Member Moderator
13410 kWhs
Joined: 3 years ago
Posts: 2345


Posted by: @majordennisbloodnok

I find that sobering and not in a good way.

Indeed.

Whilst PowerVault's intention might be to simplify the process of having a battery installed at home,
they have ended up with a product which lends itself to miss-selling by unscrupulous agents.

The concept of a 100% Managed Service initially appears to be reassuring for those who have no grasp of technology.
But how could the bill-payer know whether they have been sold a service which truly benefits them?

The reason I could tell what was happening was because I installed additional monitoring.

I also had sufficient grasp of the principles that I could correctly interpret the graph when things went wrong.
Here, for example, is a software failure just before 1pm:

DCgeneration

Even if a householder spotted that, by actively viewing the monitoring data,
how could they tell if it was a fault within their own unit, or an error in the commands being sent by PowerVault themselves?



The way in which these Managed Storage products are sold means that it's unlikely that an owner is going to pop up here on the forum.
They probably lack sufficient understanding to adequately frame a question.

This post was modified 1 day ago by Transparent

Save energy... recycle electrons!



ReplyQuote
(@old_scientist)
Reputable Member Member
1000 kWhs
Joined: 10 months ago
Posts: 139


Our March generation was 133% of our PVGIS prediction at 400kWh generated versus 300kWh predicted from our south facing 3.645kWp array.

Now winter is over, I can confidently say our solar production for the year (since installation) will exceed our ASHP consumption.

Still waiting on the outcome of our G99 application to double our solar array and add battery storage.



Samsung 12kW gen6 ASHP with 50L volumiser and all new large radiators. 3.645kWp solar (south facing), Fox ESS inverter.
Solar generation completely offsets ASHP usage annually. We no longer burn ~1600L of kerosene annually.



👍
1
ReplyQuote
